Casio ANA(3H3E-1) Operation Manual

MA1101-EA
Operation Guide ANA(3H3E-1)
• Your watch may differ somewhat from the one shown in the
illustration.
Notes
• Some water resistant models are equipped
with a screw lock crown.
• With such models, you must unscrew the
crown in the direction noted in the illustration
to loosen it before you can pull it out. Do not
pull too forcibly on such crowns.
• Also note that such watches are not water
resistant while their crowns are loosened. Be
sure to screw the crowns back in as far as
they will go after making any setting.

Setting the Time and Day

To set the day

1. Pull the crown out to
Click 1.
2. Rotate the crown to set
the day.
Avoid changing the day
setting between 9:00 p.m.
and 1:00 a.m. (If you do,
the day indication may
not change at midnight).
3. Push the crown back in to
the normal position.
To set the day of the
week and time
1. Pull the crown out to
Click 2 when the second
hand is at 12 o'clock. The
second hand will stop.
2. Set the hands by rotating
the crown. As you do, the
day of the week changes
accordingly.
3. After setting the day
of the week, rotate the
crown to set the time.
Make sure to distinguish
between AM and PM.
4. On a time signal, push
the crown back in to the
normal position.

24-Hour Hand

The 24-Hour Hand indicates
the current hour of the day.
It makes one complete
rotation every 24 hours.

For watch with the elapsed time bezel

■
Rotate the elapsed time bezel to align the
mark with the minute hand.
After certain amount of time elapsed, read the
graduation on the elapsed time bezel which the
minute hand points to.
The elapsed time is indicated.
Module No.
1343
1794/2364
5071/5072
5224
Module 1343/2364/5071
Crown
(Normal position)
Click 1
(Day setting)
Click 2
(Time and
day of week
setting)
Day
24-Hour Hand
Day of the week
Module 1794/5072
Crown
(Normal position)
Day
Click 1
(Day setting)
Click 2
(Time and
day of week
setting)
24-Hour Hand
Day of the week
Module 5224
Crown
(Normal position)
Day of the week
Click 1
(Day setting)
Click 2
(Time and
day of week
setting)
Day
24-Hour Hand
Elapsed time bezel

Specifications

Accuracy at normal
Battery type Battery life
temperature
±20 seconds per month SR916SW Approx. 3 years
±20 seconds per month SR621SW Approx. 2 years
±20 seconds per month SR621SW Approx. 3 years
±20 seconds per month SR920SW Approx. 3 years
1
