- Page 1 RangeStud Professional Grade FM Transmitter Package Contents: 1-20W RangeStud FM Transmitter 1-12V 4 A Power Adapter 1-Power Cord 1-Amateur Grade Tunable ¼ Wave FM Antenna + 30’ Amateur Grade BNC Male x BNC Male Cable...
-
Page 2: Troubleshooting
7. Always ensure that proper antenna tuning methods were used. Be resourceful, this Instruction Manual is only a guide… FM Radio Transmission is a very tedious task and many variables factor into how clear your signal gets. DAGCO Electronics has done the best they can to make this unit as “Plug and Play”... - Page 3 New Adjustable Output Level Feature: To adjust from High to Low Output Mode From „OFF‟ press and hold the Power Toggle / Adjustable Output (E) „H‟ or „L‟ will appear on the screen Press the Frequency Toggles (F) to toggle between H-High 20 Watt and L- Low 1 Watt Mode Press Power Toggle / Adjustable Output to Exit Press Power Toggle / Adjustable Output (E) to Power Unit On To view Internal Temperature...
-
Page 4: Enlarged View
Tuning your FM Antenna DAGCO Electronics has done its best to simplify this unit to be tuned as easy as possible. Improper tuning MAY DAMAGE your transmitter and will void warranty. FM radio transmission is a very tedious task! Please note that RF Engineers have designed and... - Page 5 Tuning Your FM Antenna (continued) V e rt ic a l R a dia l V e rt ic a l R a dia l V e rt ic a l R a dia l V e rt ic a l R a dia l F re que nc y F re que nc y...
- Page 6 A brief introduction to the rules of the FCC and your FM Transmitter It is the policy of DAGCO Electronics, that knowing and observing the lawful use of all transmitters is a first responsibility of our end users. We do not endorse any unlawful use of any of our transmitters, and we try to give you as much common sense help about normal and lawful use as we can.
