ASROCK Z87M OC Formula User Manual page 91

Z87M OC Formula
Render Standby
Power down the render unit when the GPU is idle for lower power consumption.
Onboard HD Audio
Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and
automatically disable it when a sound card is installed.
Front Panel
Enable/disable front panel HD audio.
Onboard HDMI HD Audio
Enable audio for the onboard digital outputs.
Onboard LAN
Enable or disable the onboard network interface controller.
Deep Sleep
Conigure deep sleep mode for power saving when the computer is shut down.
Restore on AC/Power Loss
Select the power state ater a power failure. If [Power Of] is selected, the power will
remain of when the power recovers. If [Power On] is selected, the system will start
to boot up when the power recovers.
Good Night LED
By enabling Good Night LED, the Power/HDD LEDs will be switched of when the
system is on. It will also automatically switch of the Power and Keyboard LEDs
when the system enters into Standby/Hibernation mode.
Onboard Debug Port LED
Enable/disable the onboard Dr. Debug LED.
SATA_1/eSATA1 RX Value
Try selecting a diferent value if the SATA_1/eSATA1 port encounters HDD
compatibility issues.
SATA_4/mSATA RX Value
Try selecting a diferent value if the SATA_4/mSATA port encounters HDD
compatibility issues.
85
