X-keys
P.I. Engineering, Inc.
101 Innovation Parkway
Williamston, Michigan 48895-1663
517•655•5523
FAX 517•655•4926
e-mail: info@ymouse.com
www.xkeys.com
October, 02
®
PS/2 Programmable Keyboards by
P.I. Engineering, Inc.
Product Manual
®
X-keys
Pro
(58 keys)
®
X-keys
Desktop
(20 keys)
®
X-keys
Stick
(16 keys)
®
X-keys
Foot Pedal
(3 keys)
Advertisement
Table of Contents
Related Manuals for P.I. Engineering X-keys Pro
Summary of Contents for P.I. Engineering X-keys Pro
- Page 1 ® X-keys PS/2 Programmable Keyboards by P.I. Engineering, Inc. ® X-keys (58 keys) ® X-keys Desktop (20 keys) ® X-keys Stick (16 keys) ® X-keys Foot Pedal (3 keys) Product Manual P.I. Engineering, Inc. 101 Innovation Parkway Williamston, Michigan 48895-1663 517•655•5523...
- Page 2 X-keys PS/2 Programmable Keyboards - Quick Start Compatibility: The PS/2 X-keys will work on any system with a PS/2 keyboard port. This includes the vast majority of Windows based PCs as well as some Unix based systems. How to Install Your PS/2 X-keys Device: 1.
- Page 3 0.575" wide and 0.5" high (14.6mm x 12.7mm). Horizontal and Vertical Double-keys: Horizontal and/or vertical double-keys can replace two single keys on the X-keys Pro and/or X-keys Desktop. Remove two adjacent keys, with the provided key-puller by positioning the key-puller teeth under the key and pulling straight up on the key cap.
-
Page 4: Special Programming Features
Special Programming Features: All special programming features on the X-keys are accessed by the same steps: 1. Slide the programming switch to put the X-keys into programming mode (the layer indicator will blink). 2. Tap the key that you want to program (the layer indicator will double-blink). 3. - Page 5 Single key Special Programming Features: All numbers referred to in combination with the Esc key are number keys on the alpha-numeric section of the keyboard (NOT the Num Pad). Programming a Layer-toggle Key (Esc + 2): Assigning one key as a layer toggle or layer shift, doubles the capability of the remaining keys. Each key may now have one set of commands programmed on the green layer of the X-keys, and a second set of commands programmed on the red layer.
- Page 6 Erasing a Key (Esc Esc Esc): Reprogramming a key on the X-keys automatically erases the previously saved keystrokes. When using a double keycap, it is necessary to leave one of the keys blank so that the X-keys does not send an extra set of commands when the key is pressed.
-
Page 7: Programming Errors
If you think you have exceeded the memory capacity, contact our tech support department for tips to conserve memory on the X-keys. Box Contents Additional Accessories** • X-keys Pro, X-keys Desktop, X-keys • Basic Accessory Pack: Two vertical double-keys... -
Page 8: Fcc Declaration Of Conformity
RIGHTS, AND YOU MAY ALSO HAVE OTHER LEGAL RIGHTS WHICH VARY FROM STATE TO STATE. In the event that the above limitations are held unenforceable, P.I. Engineering’s liability for any damages to you or to any party shall not exceed the purchase price you paid, regardless of the form of any claim. - Page 9 Products from P.I. Engineering Visit our web site (www.xkeys.com) for detailed descriptions Y-mouse ® Dual Mouse Adapter: • Use a mouse and a trackball simultaneously on a single port (PS/2 or Serial) • Great for adding an alternative pointing device to your system Y-key key ®...
