- Page 1 12 CHANNEL HI-LEVEL TO RCA SUMMING CONVERTOR BLUELINE FLATLINE II...
-
Page 3: Specifications
BLUELINE/FLATLINE II INTRODUCTION Thank you for purchasing the MASSIVE BLUELINE/FLATLINE II, A twelve- channel high performance audio signal processor. These unique products will accept two, four, six, eight or twelve channels of Speaker Hi-Level signal from an OEM source unit and will convert it to a high-quality, Low noise pre-amp signal. -
Page 4: Dimensions And Installation
BLUELINE/FLATLINE II 4. DIMENSIONS AND INSTALLATION 227.0 mm/8.94" 4x15mm / 0,16”x0.59”... - Page 5 BLUELINE/FLATLINE II 5. FUNCTIONS Connection interface function 5B 4 Pin Terminals: Connect to the OEM source unit high level signal output terminals. 3 Pin Terminals: Connect 12V car batteries + and – terminals (remote out is the BLULINE/FLATLINEII's remote control output terminal.) 4 Pin Terminal Wiring Diagram 3 Pin Terminal Wiring Diagram...
- Page 6 BLUELINE/FLATLINE II (2c)REMOTE OUT : Connect to the amplifier's remote in for turn ON/OFF Control. You can also connect the remote out terminal to other devices. When there's an input audio signal from an audio source device 'such as a bluetooth® device or OEM source unit' the BLUELINE/FLATLINE II will turn on automatically and then will turn on other devices at the same time through remote out 12 volt output.
- Page 7 BLUELINE/FLATLINE II 5h Signal summing instructions ( for high-level input ) 2-Way mode (As shown in the following Figure ) LOW - Pass(woofer) High - Pass(mid/tweeter) “INPUT A” “INPUT B” OR “INPUT C” 20Hz 50Hz 200Hz 1KHz 2KHz 10KHz 20KHz (a) Low-frequency signal is connected to input “A”...
- Page 8 BLUELINE/FLATLINE II 6. POWER SUPPLY AND REMOTE OUTPUT CONNECTION DIAGRAM BLUELINE/FLATLINE II REMOTE Output Ground 16 AWG Battery Ground 7. SIGNAL INPUT CONNECTION DIAGRAM 7A Bluetooth® wireless signal input (BLUELINE) 7B High-level signal input “A/B/C Channel” 3 - Way mode (ex ample)
- Page 9 BLUELINE/FLATLINE II BLUELINE/FLATLINE II 8. SIGNAL OUTPUT CONNECTION DIAGRAM 8A Bluetooth mode (BLUELINE) 8B 12 Channels High To Low Signal Summing Connection Mode (BLUELINE/FLATLINE II) 8C “A/B/C Channel” 3 - Way mode (ex ample) Bandpass Full Range Stereo High- Pass Low Level Signal Output The switch of B/C is at the status "ON"...
- Page 10 30 days of purchase. Except as provided herein, Massive Audio, Inc. makes no warranties or representations, express or implied, including any warranty implied by law, whether for merchantability or fitness for a particular purpose and shall be effective only for the period that this express warranty is effective.
- Page 12 V.112813...
