Intelligent Lighting Controller (ILC-4ch) is an electronic controller designed
specifically to operate the lighting circuits used in homebuilt aircraft. ILC
provides control of up to 4 lighting circuits plus dimmable control of up to 3
channels of instrument and cabin lights. The 4 lighting circuits may be used to
control landing lights, taxi lights, strobe lights and navigation lights. Each
channel is independently powered and controlled.
function between two of the lighting circuits.
to 10 amps of load. The 3 channels of dimmable lighting may be independently
controlled. Each dimmable channel may include incandescent or LED lighting
up to 1 amp.
ILC-4ch utilizes a remote mounted power electronics module that
communicates to instrument panel mounted switches and potentiometers. This
system allows for considerably less wiring behind the aircraft instrument panel.
The remote mounted power electronic module may be mounted in the aft area of
the aircraft allowing for short wire runs for the power wiring between the aircraft
power bus and lighting loads. The ILC works with any standard switches and
supports both backlighting and switch indicator lighting. Additionally, ergonomic,
environmentally sealed, back-lit switches are available for use with the ILC
system as well as other electrical loads. A single multi-conductor cable may be
used to link the switches and potentiometers on the instrument panel to the
power electronics module. The switches are operated at very low power levels,
thereby providing extremely long service life.
The power electronics module contains no relays and each lighting circuit
is independent from the other thereby providing very high reliability.
dimming channel is independently controlled and is over temperature and over
current protected. ILC-4ch also contains a wig-wag function for improved aircraft
visibility. Lighting circuits 1 and 2 (typically connected to the landing light and
taxi light) may be alternated flashed at a 150 cycle per minute interval providing
additional collision avoidance for the aircraft.
independently controlled, however, is overridden by the selection of the landing
light or the taxi light. Additionally, the wig-wag function provides a 1 minute
start-up delay.
Intelligent Lighting Controller
Model: ILC- 4ch
1
ILC also provides a wig-wag
Each lighting circuit may control up
The wig-wag function is
Each

Advertisement

loading

Summary of Contents for TCW Technologies ILC- 4ch

  • Page 1 Intelligent Lighting Controller Model: ILC- 4ch Intelligent Lighting Controller (ILC-4ch) is an electronic controller designed specifically to operate the lighting circuits used in homebuilt aircraft. ILC provides control of up to 4 lighting circuits plus dimmable control of up to 3 channels of instrument and cabin lights.
  • Page 2: Installation Instructions

    ILC-4ch must be installed using the current aircraft standards and practices. Refer to AC 43.13-2A/1B. The installer/builder is solely responsible for determining the suitability of the installation and use of this product. Installation instructions: 1. Mount the lighting switches in the instrument panel in a suitable location, route a 13 conductor cable (shielding not required) to the mounting area for the power electronics control module.
  • Page 3: Product Operation

    Dim1 channel also controls the back lighting for the switches on the switch panel. It is recommended to use Inst 1 channel to control the backlighting on other switches on the instrument panel. TCW Technologies, LLC. 2955 Main Road East Emmaus, PA 18049 610-928-3420 www.tcwtech.com...
  • Page 4 Intelligent Lighting Controller LANDING TAXI STROBE INST-1 INST-2 INST-3 WIG-WAG Intelligent Lighting Controller Model: ILC-4ch Input: 10-30 volts DC TCW Technologies Output: 10 amps /ch Dimmer: 1 amp /ch www.tcwtech.com Output Output Input Power Switched Dimmed Loads Loads 2 3 4...
  • Page 5 Switch power landing taxi wig-wag 13 conductor cable strobe back-lighting all switches Potentiometer power 15 pin Female Dsub Inst 1 Inst 2 Inst 3 15 pin D-sub Female on harness ground Pin # Function Potentiometer + power Potentiometer - ground Backlighting + power Pot #1 signal Pot #2 signal...
  • Page 6 ILC-4ch Wiring diagram Switch power Switch connections- alternate version landing wig-wag 13 conductor cable strobe back-lighting all switches Potentiometer power 15 pin Female Dsub Inst 1 Inst 2 Inst 3 15 pin D-sub Female on harness ground Pin # Function Potentiometer + power Potentiometer - ground Backlighting + power...
  • Page 7 During the first 24 months from the date of purchase and subject to the conditions hereinafter set forth, TCW Technologies, LLC. (TCW) will repair or replace to the original user or consumer any portion of your new TCW product which proves defective due to defective materials or workmanship of TCW.
