- Page 1 SET TOP BOX Digital receiver Latte OWNER'S MANUAL English Read this manual before installation and use.
-
Page 2: Important Safeguards
SAFETY INFORMATION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. CAUTION The apparatus shall not be exposed to dripping or splashing and no objects : To reduce the filled with liquids ,such as vases shall be placed on the apparatus. risk of fire and electric shock, do Caution: Maintain electrical safety. -
Page 3: Table Of Contents
CONTENTS SAFETY INFORMATION INTRODUCTION Front panel Rear panel Remote control SYSTEM CONNECTION General Connecting the TV GETTING STARTED Welcome Main Menu Installation OPERATION Changing channels Access the Electronic Programme Guide(EPG) EDIT CHANNEL Edit Channel menu TV Channel list Radio Channel list Delete All SYSTEM SETUP System setup menu... -
Page 4: Introduction
INTRODUCTION Front panel Channel Up/Down Remote sensor Menu Power Volume -/+ OK button Rear panel LNB IN DC mains Connect a satellite Composite Video antenna cable USB port Down Mix Audio 2 Channel L/R English... -
Page 5: Remote Control
INTRODUCTION Remote control (Open the Favorite list) INFO (Press for current channel information/ Operation guide ) VOL+/-( Volume Up and Down) OK button (Confirm a selection within a menu) Cursor/CH+, -/VOL+,- (Cursor: Navigation buttons used to navigate menu's items) (CH+/-: Channel Up and Down) (VOL+/-: Volume Up and Down) EXIT (Exit from menu) RED/GREEN/YELLOW/BLUE Buttons... -
Page 6: System Connection
SYSTEM CONNECTION General There are many different types of TV and other equipment that you can connect to the STB. In this manual you will see some of the most common ways to connect your equipment. Connecting the TV Antenna RF cable DC adapter English... -
Page 7: Getting Started
GETTING STARTED Main Menu If you use the STB for the first time, you can watch the TV directly, thenpress "MENU"button, the main menu appears. Press cursor button to select your desired item, then pree System Setup Edit Channel Installation "OK"... -
Page 8: Main Menu
GETTING STARTED Installation Manual Scan Manual Scan [LNB1] PalapaD Select "Manual Scan", press the "OK" button to enter the XXXXX XXXXXX XXXXX XXXXXX Manual Scan menu. XXXXX XXXXXX Press "LEFT" or "RIGHT" button to select a satellite, press "UP" XXXXX XXXXXX XXXXX XXXXXX... -
Page 9: Edit Channel
EDIT CHANNEL Edit Channel menu Edit Channel Press the "MENU" button to enter main menu. Press cursor button to highlight "Edit Channel". TV Channel List Radio Channel List Please input the default password "0000" as requested. Delete All Press "UP" or "DOWN" cursor button to highlight the desired item and press "OK"... -
Page 10: Tv System
SYSTEM SETUP System setup menu System setup menu allows us to set Language, TV System, Local Time System Setup Setting, Timer Setting, Parental Lock, OSD Setting, Favorite, PVR Language Storage Information, PVR Setting and Other. TV System Display Setting Press the "MENU" button to enter main menu. Local Time Setting Timer Setting Press cursor button to highlight "System Setup", press "OK"... -
Page 11: Local Time Setting
SYSTEM SETUP Local Time Setting This menu allows you to set the region and time. Local Time Setting Mode: The options are: Manual/Auto Mode Auto Region Medan Region: This menu is used for changing the region setting. Time Zone UTC+01:00 Summer Time Time Zone: This menu is valid only when selected "Manual"... -
Page 12: Favorite 9
SYSTEM SETUP OSD Setting This menu allows you to set Channel List Timeout, Banner Timeout and OSD Setting OSD Transparency . Channel List Timeout Bannel Timeout Channel List Timeout: 1-15 OSD Transparency Banner Timeout: 1-15 OSD Transparency: To set the OSD transparency to Off/10%/20%/30%/ 40%. -
Page 13: Pvr Setting
SYSTEM SETUP PVR Setting This menu allows us to set the PVR Setting. PVR Setting Press "UP" or "DOWN" cursor button to select desired item, Timeshift press "LEFT" or "RIGHT" cursor button to change the setting. Jump 30sec TimeShift ON/OFF Jump 30sec/1min/5min/10min/30min Other... -
Page 14: Tools Tools Main Menu
TOOLS Tools main menu Tools Press the "MENU" button to enter main menu. Information Press cursor button to highlight "Tools". Then press "OK" button. Factory Setting S/W Upgrade by OTA Please enter the default password "0000" when requested. Upgrade By USB Press "UP"... -
Page 15: Multimedia Multimedia Main Menu
Multimedia Multimedia main menu Press the "MENU" button to enter main menu. Multimedia Press "UP"or "DOWN" button to highlight "REC". Video Please enter the default password "0000" when requested. Music Image Press "UP" or "DOWN" cursor button to highlight the desired item Game and press "OK"button to enter the sub-menu. -
Page 16: Game
Record: "BLUE" button: Press "Blue" button to open rename window. "GREEN" button: Move the highlight to the program which you want to lock. Pressing "Green" button, it will ask you to input password. Default password is "0000". After input correct password, the program is locked. If you want to unlock the program, press the "Green"... -
Page 17: Ca Information Ca Information Main Menu
CA Information CA Information main menu The menu allows the following operations: CA Information Operator Info Opertator Info Maturity Rating Maturity Rating PinCode CAS Info Pin Code Mail Info CAS Info Advanced Security Info Mail Info Advanced Security Info Press the "MENU" button to enter main menu. Press "UP"or "DOWN"... -
Page 18: Timeshift/Record
TIMESHIFT/RECORD Plugging an external Mass Storage Device on the USB port gives you access to Time Shift/Record a broadcast programme. Pause a broadcast programme and continue watching it later (Time Shift ) Record a broadcast programme. When the space available on the Mass Storage Device runs out, recording operation of broadcast will stop. -
Page 19: Troubleshooting
TROUBLESHOOTING In some region, the digital terrestrial signal may be weak. So you'd better use the antenna in which the booster was built, for watching the weak signal channels. Problem Possible cause What to do Mains lead unplugged Standby light not lit Check mains lead Mains fuse blown Check fuse... - Page 20 SPECIFICATIONS TUNER & CHANNEL RF INPUT CONNECTOR x1 (F-TYPE, IEC169-24, FEMALE) FREQUENCY RANGE: 950MHz~2150MHz SIGNAL LEVEL: -25 ~ -78 dBm FEATURES Video decoder MPEG-2 MP@HL, MPEG-4 SP, DIVX13.11, 4.X, 6.X, FLV Format, H.264, MP@HL, AP@L3,RM&RMVB Audio decoder MPEG-1,MPEG-2 (Layer I/II),MP3,AAC-LC VIDEO FORMATS 4:3/16:9 VIDEO OUTPUT...
