- Page 1 U.S.A. inc. MASONRY 350F Sawing machine Model - 1188792 MANUAL INSTRUCTION PARTS LIST Manual Part. number 3210296 - 05/2002 Write in the serial n° of your machine here Machine serial N°...
- Page 2 IMER INTERNATIONAL S.p.A. MASONRY 350 F Thank-you for purchasing a Masonry 350F from an Imer U.S.A. dealer. Your decision is an intelligent one. There is no other sawing machine in the world which delivers the benefits and features of the Masonry 350F: - Extremely rigid, mig welded bar steel frame.
- Page 3 IMER INTERNATIONAL S.p.A. MASONRY 350 F Dear Customer, 4. CUTTING SPECIFICATIONS Congratulations on your choice of purchase: this IMER saw, the This saw model has been specially designed for cutting stone, result of years of experience, is a fully reliable machine and is ceramics, marble, granite, concrete and similar materials.
-
Page 4: Maintenance
IMER INTERNATIONAL S.p.A. MASONRY 350 F - Ensure correct installation of all protective devices. - Turn off the engine before topping up the tank with petrol. - Before starting work, fill the water tank. Top up during operation Saws with endothermic engines must be used in the open air. If whenever necessary: N.B. -
Page 5: Troubleshooting
IMER INTERNATIONAL S.p.A. MASONRY 350 F 16. TROUBLESHOOTING 15.2 TANK REMOVAL (Ref.Fig.7). - Lift the tank (ref.1) to detach it from its supports (ref.2) and - WARNING. . Stop the saw and turn off the remove it from the side indicated by the arrow. endothermic engine before... - Page 6 IMER INTERNATIONAL S.p.A. MASONRY 350 F Fig. 2 Fig. 4 5° MAX Fig. 5 Fig. 7 Fig. 9 Fig. 8 Fig. 10 UNSCREW...
- Page 7 IMER INTERNATIONAL S.p.A. MASONRY 350 F TAV. 1 TAV.1 - ASSEMBLY OF MOTOR RIF. COD. NOTE 3210291 MOTOR HONDA GX 160 BELTS INTERNAL 3210139 COVER BELTS EXTERNAL 3210148 COVER 3210185 BELT 3210159 PULLEY 2224190 WASHER 8X32 Z 2222076 BOLT M8X25 Z 2222176 BOLT M8X50 Z...
- Page 8 IMER INTERNATIONAL S.p.A. MASONRY 350 F TAV. 4 TAV. 4 - M AC H IN E S T R U C T U R E TAV. 4 - M ACHINE ST RUCT URE R IF. C OD . N OT E RIF.
-
Page 9: One Year Warranty
ONE YEAR WARRANTY We warrant to the original purchaser that the IMER equipment described herein (the "equipment") shall be free from defects in material and workmanship under normal use and service for which it was intended for a period of one (1) year from the date of purchase by the original purchaser. - Page 10 This is a contact addendum to our manuals Imer USA East 221 Westhampton Pl Capitol Heights, MD 20743 Phone: 301-336-3700 Fax: 301-336-6687 Order Fax:301-336-5811 Imer USA West 3654 Enterprise Ave Hayward, CA 94545 www.imerusa.com 800-275-5463...
