USER MANUAL
OF
MULTIcell FIX TO CELLULAR GATEWAY
1
®
USER MANUAL
OF
MULTIcell FIX TO CELLULAR GATEWAY
Thank you for selecting Multicell FCT device
This user manual presents the detailed features of Multicell so you are able to
get the best performance from your device.
Please note that the product, their specification and the information appearing in
this document are subject to change by Multitek without notice.
MULTITEK Elektronik San.ve Tic. Ltd.
Wwww.multitek.com.tr
info@multitek.com.tr
Tel: + 90 216 420 38 38
Fax: +90 216 415 79 18
Doc.multicell.04-020106
2
®
Advertisement
Related Manuals for Multitek MULTIcell FCT
Summary of Contents for Multitek MULTIcell FCT
- Page 1 This user manual presents the detailed features of Multicell so you are able to get the best performance from your device. Please note that the product, their specification and the information appearing in this document are subject to change by Multitek without notice. MULTITEK Elektronik San.ve Tic. Ltd. Wwww.multitek.com.tr info@multitek.com.tr...
- Page 2 1. General Dudullu/Ümraniye 81250 ÝSTANBUL TURKEY 2. The place to install the device 3. Installation THE PRODUCT : MULTITEK FIX TO CELLULAR TERMINAL (FCT) 4. Connections, LEDs and their MODEL NAME : MULTICELL FCT explanation 5. Start up of the device Conforms with the essential requirements of the Radio&Telecommunications...
-
Page 3: Installation
3.1 By using the installation holes template,install the device with the screws and fixings provided. 1. GENERAL: Antenna socket General Description of Multicell FCT: Multicell allows to make GSM calls through a standard telephone or a PBX exchange. In practice, PTSN to GSM calls are more expensive than GSM to GSM calls. Multicell enables to make GSM to GSM call through the fix telephones. -
Page 4: Start Up The Device
LEDs Meanings Stable or 3.5 Connect the one side of the line cord to the device and the other to the telephone or PBX external line. SIM card not in PIN code asked During conversation 3.6 Insert the adapter jack to the device power socket and than connect the adapter to the 220 VAC line. Multicell will start operating in 5 seconds and it will search to establish the operator connection. - Page 5 b) Programming the charging pulse period : 8. MULTIcell PROGRAMMING To program the Multicell device one should enter the programming code to the device as follows ; 06 XXX XXX: 006-999 (Default is 60 corresponding to 6 seconds) -If a telephone is connected to the FCT,hooh-off the phone and hear the dial tone and dial 07447. -If an external line of a PBX is connected to the FCT , seize the external line and then dial the XXX is the duration between two charge pulses in units of 100 miliseconds.
- Page 6 8.10 Restriction of calling some numbers (or operators) All numbers may be called(Default). 13 (code1.) # (code2.) # ... * Only entered prefixes may be called The codes that may be allowed to call are entered sequencially one by one and at the end,* is entered.It is possible to enter up to 35 characters code.Please do not forget # between the codes.
