RLH Industries RLH 24V 300 Watt User Manual

USER GUIDE
RLH 24V 300 Watt
Solar Power Supply
Solar power system with 150AH backup
battery in NEMA-4X Cabinet
Overview
The RLH 300W solar power supply is a fully integrated solution
provide remote powering for industrial equipment. RLH solar
power supplies are engineered with durable and highly efficient
solar electric panels to ensure reliable operation in any
geographical region.
The charge controller continuously maintains the correct 24V
charge level on the 150Ah battery pack, and ensures a seamless
power transition to battery power when needed. The charge
controller allows maximum array current to flow into the batteries,
and the temperature sensor adjusts the charging current based
on ambient conditions. A digital LCD display shows battery
voltage, solar amps, equipment amps, and battery level.
The gel batteries are sealed and maintenance free, and are field
replaceable. The system includes a NEMA-4X outdoor rated,
aluminum cabinet to house the batteries, charge controller and
related equipment. The cabinet may wall or pole mounted (pole
mount kit optional), and includes mounting hardware.
The cabinet comes pre-wired and includes a fuse to protect the
system. The panels and charge controller are covered by our
Exclusive Unconditional Lifetime Warranty.
RLH Industries, Inc.
RLH Industries, Inc. • Tel. 866-DO-FIBER • Fax 714 532-1885 • www.fiberopticlink.com
300W 24V Solar Power Supply w/150Ah Battery Pack
Standard Features
Complete solar power system with panels, charge controller
and sealed batteries in a steel pedestal
Cabinet is outdoor rated and includes padlock ring and
recessed hex latches
Includes fuse holder and screw down connection terminals
Solar panels include flexible mounting hardware for easy
mounting onto poles or structures
Sealed 24V 150Ah battery array, field replaceable
Batteries are warranted for 10 years
Built-in battery test function
Convenient LCD display shows battery voltage, solar amps,
equipment amps, and battery level
Solar panels and charge controller are covered by our
Exclusive Unconditional Lifetime Warranty
