User Manual DVR-HSD4000 Series DVR-HSD4000 Series This document contains preliminary information and s ubject to change w ithout notice.
Page 2
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. NOTE: This equipment has been t ested and f ound to com ply w ith t he limits for a class digital device, pursuant t o p art 15 o f the F CC Rul es.
Table of Cont ents CHAPTER 1 PACKING DETAIL AND INSTALLATION _____________________ 5 1-1 PACKING__________________________________________________ 5 1-2 Hard Disk Installation _______________________________________ 6 CHAPTER 2 PANEL LOCATION _______________________________________ 7 2-1 FRONT PANEL CONTROLS __________________________________ 7 2-2 4CH REAR PANEL CONNECTORS ____________________________ 8 CHAPTER 3 LIVE, PLAYBACK AND PTZ OPERATIONS __________________ 9 3-1 LIVE Mode ________________________________________________ 9 3-2 PLAYBACK Mode _________________________________________ 12...
Page 4
CHAPTER 6 Rempte So ftware Installation and Set up____________________ 42 6-1 AP Software Installation and instruction ______________________ 42 6-2 How to do remote monitoring through IE ____________________ 44 6-3 AP Software Operation _____________________________________ 46 CHAPTER 7 SPECIFICAITONS _____________________________________ 47 CHAPTER 8 MOBILE APPLICATION INSTALLATION AND USAG E _________ 49 8-1 Mobile Application Installation and Operation for Symbian System49 8-1.1 Mobile Application Installation __________________________ 49 8-1.2 Mobile Application Operation ___________________________ 50...
CHAPTER 1 PACKING DETAIL AND INSTALLATION 1-1 PACKING 1. DVR 2. Quick Start 3. IR Remote Control 4.Batteries x2 5. CD 6. Hard Disk Mount x2 7.Screws x8 Mouse 8. Power Adaptor 9. SATA Cord x 1 Cat-5 Network Patch Cable Note: Standard shipping products do not include HDD...
1-2 Hard Disk Installation Step 1) Fi x th e HDD to rack mou nt wi th the screw s as i ndicated. Step 2) P lace the HDD on the HDD plate and screw it as in dicated. Step 3) Connect the power and the SATA cables as indicated. Note: After installation, please initialize Hard Disk before starting to r ecord.
CHAPTER 2 PANEL LOCATION 2-1 FRONT PANEL CONTROLS Start or stop recording. Play back in normal speed. PLAY Display the search menu. T-SRH Port for USB external devices. USB 2.0 Port Power: Power is on. HDD: Hard disk is in use. LED Display LAN: Connected to the internet (in red): Remote user logged in.
2-2 4CH REAR PANEL CONNECTORS VGA port Socket for a DC 12V input. DC 12V BNC port to display full screen image of all installed cameras in SPOT monitor sequence. MAIN monitor BNC port for the main monitor. VIDEO IN BNC input ports for cameras, 4 in total.
CHAPTER 3 LIVE, PLAYBACK AND PTZ OPERATIONS The IR remote control and mouse operate differently under each mode; this chapt er describes the functions of them under three different modes: LIVE, PLAYBACK and PTZ. 3-1 LIVE Mode You can monitor all the channels, listen to audio signal and have some related operations under LIVE m ode.
Page 10
Table 3-1.2 Graphical icons that will display after right-clicking your mouse under LIVE mode. Icon Description Resting the cursor on this icon will bring up the following four menu icons. Main menu. Search menu. Backup menu. PTZ mode. Turn on/off recording. Playback.
Page 11
Table 3-1.3 Description of on screen graphical icons in LIVE mode Icon Description Recording is on Live Audio is on Live Audio is off Motion detected on the channel Sensor triggered on the channel Video loss detected on the channel USB device detected DVD burner is detected Connected to the LAN cable.
3-2 PLAYBACK Mode Switch t o PLAYBACK mode by pressing “PLAY” under t he LIVE m ode, the graphical i con will show up on the upper center of the screen and the operation panel ( see below picture) will show up at right lower corner of the screen.
Page 13
Table 3-2.2 The mouse operation under the PLAYBACK mode. Icon Description Fast rewind Fast forward Play/pause / SLOW slow playback stop playback Playback channel by channel with snap shot display Full screen display Quad display Zoom-in display...
3-3 PTZ Mode Switch t o the PTZ m ode by pressing “PTZ” button under the LIVE m ode. The PTZ icon will appear on upper left side of screen and the control panel will appear on the down right side of screen.
Page 15
Table 3-3.2 Mouse operation under the PTZ mode Icon Description Leave PTZ Mode back t o t he LIVE m ode Pre-set num ber N. (0~255) Go t o pre- set number N. Set current PTZ l ocation at pre-set num ber N. TOUR press to act ivate pre- set tour Set cur rent PTZ l ocation as the start of line-scan.
CHAPTER 4 MAIN MENU SETUP To enter the main menu and set up DVR, log-in account and user password are required. The default password of the administrator is “ 123456”. Please chec k t he “A ccount Setup” for related setup of other log-in users. Table 4-0.1 Some definition of virtual keyboard.
Table 4-0.2 The operation of remote control under the setting menu Item Description Switch t o differ ent options under one i tem Switch to diff erent i tems MENU Save setup and bac k t o LI VE mode Back t o Upper level of m enu w ithout saving ENTER Enter the menu, or display v irtual keyboard...
Item Description Motion Setup Enter to set up motion detection Sensor Setup Enter to set up sensor detection 4-2.1 MOTION SETUP Item Description Check the box to Enable/Disable popup screen function for all Motion Popup channels. W hen m otion is det ected in LIVE mode, the detected channel image will pop up in full screen display.
4-2.1.1 MOTION AREA SETUP The m otion detec tion has been di vided i nto 16x 12 grids. T he d efault det ection ar ea i s full scre en a s i t m arked i n transparent for l ocal DVR and purple f or rem ote acc ess. Areas desel ected f or motion det ection are m arked in red for both l ocal and rem ote site.
Item Description Sensor Popup Check the box to Enabl e/Disable popup screen f unction for all channels. W hen S ensor is detec ted i n L IVE m ode, t he det ected channel image will pop up in full screen display. All Off Set all sensor off All Low...
4-3.1 Schedule Record Setup Click on the t ime on the l eft si de. T he setup m enu will be di splayed. You ca n h ave detail setup by dat es, Time and e vent. 4-3.2 Holiday Setup Since holi days are di fferent by d ifferent country and regi on, you c an s etup t he hol iday of your location acc ordingly.
4-4 CAMERA SETUP Item Description You can setup independently for each channel. Mask Check the box to Enable/Disable mask function for LIVE mode Drag the bar or press to adjust Sharpness of your camera from Sharpness value 1 to 255. The default value is 1. Drag the bar or press to adjust Brightness of your camera from Brightness...
4-5 ACCOUNT SETUP The Ac count Setup m enu is used t o prov ide role-based perm ission i ndependently setting for each user (maximum of 4 users) to access DVR ov er network. The default admin account and password i s “a dmin” and “123456” The default password rem ains the sam e after firmware upgrade, however, it requires 8-digits for password length when you setup a new one Item...
4-5.1 Permission Setup The Account Setup is set to provide individual user (maximum of 4 users) role-based permissions, including access to Setup menu, Network operation, PTZ function, Playback, Utility, Backup, Password expiry date and Mask on specific channels while playing back. 4-5.2 User Picture Setup User can select picture w ished to be c hanged to f rom hard driv e.
4-6 NETWORKING SETUP Item Description Connect type Setup mode for network connection: (DHCP LAN ADSL). HTTP Setup Enter to set up HTTP DDNS Setup Enter to set up DDNS Mail Setup Enter to set up mail 4-6.1 NETWORKING SETUP There are three ways to connect to the network as followed. 4-6.1.1 DHCP When DHCP is selected, IP address will be assigned by DHCP server automatically.
4-6.1.2 LAN Select LAN for network connection, the following information is required. Item Description IP Address Enter IP address provided by ISP Subnet Mask Enter IP address of Subnet Mask provided by ISP Gateway Enter IP address of Gate way provided by ISP Enter DNS address provided by ISP.
4-6.2 HTTP Setup Item Description Enable HTTP Check to enabl e HT TP server. Users can r emotely access i nto t he Server DVR over the network if the HTTP function is activated. Port Enter a valid port value from 1 up to 65000. The default value is 80. Auto Assign each channel with its maxima accessible fps Chanel number...
Item Description Enable DDNS Enable/disable DDNS function. Enter the registered SMTP Server: DDNS Server ez-dn I-DVR.NET DYNDNS.ORG NO-IP.ORG 3322.ORG SMTP Server Enter the completed registered SMTP Server. (Including username + Server) If the user nam e is h.264 and y ou choose i-dvr as your server, you should enter: h.264.i-dvr.net User Name...
Item Description Enable E-mail Notification Check the box to enable/disable E-mal Notification function. Enter t o s et up SMTP Serv er na me. SMTP Server (V aries accordi ng t o the user) User Name Enter to set up User Name. Password Enter to set up Password.
4-8 SYSTEM SETUP Item Description DVR Name The name of DVR will be shown when users login from remote access. DVR Location The location of DVR will be shown when users login from remote access Click or p ress to select O SD language from English, Traditional Language Chinese, Simplified Chinese, Japanese, Greek, Portuguese Default ID is 0.
4-8.1 DISPLAY SETUP Item Description Auto-Seq Interval Set up duration time in seconds for the interval between channels under Auto-Seq mode. Show OSD Turn On / Off OSD display Show DVR Status Turn On / Off DVR illustration and record status display Show Date/Time Turn On / Off date and time display Show Channel Name...
Item Description Hour Format 12HOURS/ 24HOURS Date Format MM-DD-YY/DD-MM-YY/YY-MM-DD Date/Time Position Choose the position of Time and Date display Change Date & Time Setup time and date of DVR Time Zone Setup Set up GMT and Daylight Saving Time. Internet Time Setup Setup automatic synchronization with internet server 4-8.2.1 CHANGE DATE &...
Item Description Select Time Zone Enter to modify GMT from GMT- 13 to GMT+ 13 Daylight Saving Time Turn on/ off Daylight Saving Time 4-8.2.3 INTERNET TIME SETUP Synchronize your DVR time with internet time server. Item Description Check to enable DVR autom atic synchr onization function. Automatic Effective by this option s elected, DVR will...
Item Description Key Tone Enable/Disable keystrokes. Enable/Disable buzz er operat ion when t he al arm i s triggered f or Buzzer HDD Error, Video Loss, Motion and Sensor. Enable/Disable the signal to be sent t o the RELAY OUT b locks Relay when the alarm is triggered for HDD Error, Video Loss, Motion and Sensor.
Item Description Channels display in spot for three different modes: MANUAL: select channels to display manually. SPOT MODE SEQUENCE: Auto-sequence for all channels in order. EVENT: Display channels with event occurred. The durat ion tim e in seconds for t he i nterval between channel s under Interval (Seconds) SPOT mode.
4-10 DIAGNOSTIC Item Description Version The current firmware version of DVR The connec ted I P address of DVR. If disconnected f rom network, t he s creen will display” NE TWORK DISCONNECT”. MAC Address of DVR HDD Status HDD num ber Volume HDD Cap acity Used...
CHAPTER 5 BACKUP & SEARCH 5-1 BACKUP SETUP User can backup any segment of recorded data in a specified time frame. To do so, either a CD R/W or stor age de vice, li ke US B, must be connected t o the DVR. Rec orded data c an a lso backup i nto NB/PC thr ough our remote access software: DVRemoteDesktop.exe and be...
5-2 SEARCH SETUP Item Description Event Search Event search menu Time Search Enter time search menu 5-2.1 EVENT SEARCH The DVR automatically records events with type, time and channel information included. If there is recor ding data for an e vent, a yellow signal will be shown on t he left s ide o f time information.
Item Description Criteria Setup conditions of event search Page Switch between pages of events Date/Time Date/time when event occurred. Event ty pe, defined as following MOTION Motion Detected SENSOR Sensor Detected Video Loss Video Loss Remote Login user log-in over the network Event Type Remote Logout user log-out over the network...
5-2.2 TIME SEARCH TIME SEARCH can search for the specific time of recording data to playback. Press “Enter” or left click on the desired date to playback. Note that dates with recording data are marked with a red square “ “System will start playing back accordi ng t o the date you sel ected.
CHAPTER 6 Remote Software Installation and Setup 6-1 AP Software Installation and instruction AP software: DVR Remote Desktop can allow you to remotely access and control the DVR from PC. p.s. Op eration system cu rrently suppo rts W indows X P SP2 and abo ve , Windows V ista , W indows 7 Step One Enter the IP address of DVR in IE browser Step Two: Windows as below will show up.
Page 43
Step Four: Run or Save our AP software. Step Five: If you choose to run the software, Start window will be shown up. Please enter information of login DVR: IP, Port, Username and Password, or choose “Play Recorded File” to open backup files in your PC. Step Six: You’ve logged into the DVR...
6-2 How to do remote monitoring through IE Step One Enter the IP address of DVR in IE browser. The address appeared in this image is only for demonstration. Actual address is depending on the setup of on-site DVR. Step Two: Windows as below will show up. Please enter the user name and password. Default user name and password is admin/123456.
6-3 AP Software Operation Open t he file “DVRemoteDesktop.exe”; ent er the information o f DVR “IP address”, “Port” “Username” and “Password” and click “OK”. You should be able to login DVR successfully and start to use the software. The default username and password is admin/ 123456 “DVRemoteDesktop.exe”...
CHAPTER 7 SPECIFICAITONS 1. VIDEO Input Level 1.0 Vp-p±10% Composite, 75 Balanced NTSC 120fps(4CH) Display Speed 100fps(4CH) NTSC 720(H) X 480(V) Display Resolution 704(H) X 576(V) Monitor Output 2Vp-p Composite, 75 Balanced 2. RECORDING Compression Method H.264 Recording Speed Refer to table 7-1 NTSC 720 X 480, 720 X 240, 360 X 240 Recording Resolution...
Page 48
8. PHYSICAL Dimension 225(W) x 264(D) x 47(H) mm 1.3 KG not including HD Weight 9. BACKUP USB St ick Video D ata, Aud io BACKUP Network Video Data, Audio 10. SEARCHING & PLAYBACK Searching Type Event/ Time Playback speed 120 FPS 11.
CHAPTER 8 MOBILE APPLICATION INSTALLATION AND USAGE You can remotely monitor all channels of DVR through your mobile device. The required mobile application is from DVR manufacturer and it supports mobile OS for both Windows mobile 5.0 above and Symbian. Please confirm network function of DVR has been activated before mobile connection: Main m enu Net work Setup...
8-1.2 Mobile Application Operation After the installation, enter the Program Files menu in your mobile device to run a file called “DVRH264”. Select “Menu” at the right l ower corner of your mobile screen, 4 commands, Login Add Modify and Delete, will show up.
8-1.2.3 Modify the Login Information of DVR You can use the “Modify” command to change the login information of DVR. The dialogue i s identical to that of the “Add” command. 8-1.2.4 Delete the Login Information of DVR “Delete” command can be used t o remove the DVR information if it i s no longer useful. Select the DVR on the name list then choose “Delete”...
8-1.3.1 Scroll the Image You can use the keypad on your mobile device to scroll the image if it’s oversized. Action Scroll Up Scroll Left Scroll Right Scroll Down 8-1.3.2 Image Quality Setup Select “Quality” under the “Menu” There will be 5 levels for your to choose: Low Normal Middle High and Highest.
8-1.3.4 Size of Image The screen siz e of different mobile de vice can be d ifferent. You can s elect “ Size” under t he “Menu” to choose from “Original” or “Fit Screen” to resize the display image. Item Description Original The image will...
8-2 Mobile Application Installation and Operation for Windows Mobile System There are tw o ki nds o f applications for Window Mobile OS: JPEG compression and H .264 compression. The one for H.264 compression can transfer both audio and video signal to your mobile device.
8-2.2 Mobile Application Operation After t he i nstallation, enter t he Pr ogram F iles m enu i n your mobile device t o run fil es nam ed “Jrviewer” and “H264Pocket”. This appli cation allows you t o remotely l ogon and monitor DVR. Pr ess “ OK” to bring up the operation menu, see below chart to further information.
8-2.3 Operation under the LIVE monitoring. After succe ssful logon the DVR, press “ View” t o b ring up operation m enu. Y ou can choose the c hannel, r esize t he i mage, c hoose th e quality, and t urn on/ off t he s tatus bar, al arm, full screen di splay….etc Item Function...
CHAPTER 9 CMS INSTALLATION AND USAGE GUIDE 9-1 CMS Installation System Requirement: Intel Pentium 4 processor or equivalent. Microsoft Windows Vista Windows XP Windows 2003 Server. Besides OS and other required APs, there will be 512MB remaining memory needed or above. 512MB memory above.(500M requested for group DVR connection and 180M for single DVR) 20MB HD space.
Page 58
5.”Confirm Installatio n” window s hows. Select ‘Next’ t hen t he installation st arts. 6. Select ‘Close’ t o finish i nstallation w hen t he “ Installation Complete” w indow s hows.
Page 59
Instruction for Log-in Failure to CMS After Upgrade Log i n to CMS w ith the de fault account and p assword after CMS upgrade. If an err or message occurs as shown in the image, please follow the instruction to solve the error. Step 1: Please enter file manager to enter folder, “Windows”...
9-2 CMS LOGIN AND ENVIRONMENT To ent er CM S, t he ad ministrator’s us er nam e and p assword ar e requi red. The def aults are ‘admin’ and ‘123456’. After successful login, the following image shows on your screen: DVRs, Groups &...
9-3 DVRs, Groups & Events Icon Description View list of logged in DVR G roup. View Logs: list all the event information of DVR 9-3.1 View DVR Group List Single left c lick on ‘DVR’ or ‘Group’ will expand/collapse t he ent ire DVRs and groups list.
9-3.2 View Event Logs Under t his page, all the e vents of a DVR c an be ex panded/collapsed i n t he order of Re mote i n/Remote out , V ideo Lo ss, M otion, Sensor, Others (Po wer Re set, Key Lock, Key Unlock, HD Full ).
9-5 Main Display The main display area is where t he l ive image of DVR is s hown. You can dr ag to change t he location of screen for each channel and turn on/off audio signal with mouse-click. 9-5.1 Audio Control In liv e mode, you c an t urn on/ off t he audi o signal of Ch1~Ch4: Audio s ignal i s On...
9-5.2 eMAP Display In Liv e mode, press ing w ill bring t he e-M AP drag -down m enu. If t he channel has been set up t o use e-MA P, the menu w ill show al l t he e-M AP titl es that have been entitled t o this channel ;...
9-5.3 PTZ Control In t he main di splay, ri ght click on t he channel will bri ng up PTZ control panel as below . Icon Description 8 di rection key Rotate t he PTZ ZOOM+ Zoom in ZOOM : Z oom out Setup t he PT Z spot as pre-set FOCUS+ : Focus in FOCUS- Focus out...
9-6 Operation Bar 10 O perations to be li sted as below: Table 9-6.1 des cription o f 10 operat ions: Icon Description User Adm inistration. Please s ee “8- 6.1 User adm inistration” DVR A dministration. Please s ee “8- 6.2 DVR A dministration” Group A dministration.
9-6.1 User administration Before the CMS can be used o n a PC, user accounts should be a dded with proper authority. Each user should also be assigned a password and op tionally a description. If a user does not have certain authority assigned, he/she will not be able to operate the corresponding function on the Operation Bar.
9-6.3 Group Administration A ‘Group’ means a s et of v ideo channel s from one o r m any DV Rs, w hich m eans, user c an organize channels from different DVRs to be set in a group. This function allows you to monitor and manager channels from multiple DVRs easily and flexible.
9-6.4 eMap Administration If geographical l ocations are relev ant, or if it is desir ed t o use a pict ure as t he background, eMap can be u sed f or t he purpose. W ith eMap, t he background pi cture can be pi cked by t he user and channels from multiple DVRs can be placed and dragged around on the picture.
9-6.5 Remote Play Video images recor ded on a D VR can be di splayed on a remote CMS. With Remote Play function, select a DVR and a di splay mode on t op of the screen. After the recorded segments are listed below, double click on one to show its image on the right.
9-6.6 HDD Playback You can di rectly play the recording data in the HDD t hat’s uninstalled from DVR by CMS . See the picture below, the left part of screen is recording data in list that’s separated by hour and the right p art i s main displ ay.
9-6.8 Event Playback Event recordings on the DVR can be played back in CMS. Steps to follow: 1. Select a DVR and a display mode. 2. Select a date. 3. Double click an event and play back the images on the right. Use buttons at the bottom to control the playback.
9-6.10 Recording Data It can pl ay all t he recording files you’v e recorded in l ine i n “Recording Data”. You can pl ay or delete them here. Steps to follow: 1. Choose the recording time at upper left corner, it w ill be played on the main display. 2.
APPENDIX I I -DVR.NET REGISTRATION DDNS Registration on I-DVR.NET In t he p ackage of each DV R, you will f ind a stick er sho ws account information i ncluding username and password that allows users to login I-DVR.NET for registration. To register DDNS on I-DVR.NET, please follow the steps as shown.
Page 75
Step 4. Enter DVR Main Menu Network Setup DDNS. Activate DDNS functions and input related information.
APPENDIX II Remote Monitoring IE ActiveX Control Installation Instruction When usi ng I E for remote monitoring for the first time, IE ActiveX Contr ol i s needed t o be downloaded. 1. When remote monitoring on IE for the first time, an alert message occurs “Install ActiveX control”...
Page 77
4. After installation, IE remote monitoring image appears. 5. If message, “Your security Settings do not allow web sites to use ActiveX controls installed on your computer.” pops on when logging in, please follow the next instruction. 6. First select “Tools” on the tool bar and then select “Internet Options”...
Page 78
7. Select Security Trusted Sites Sites 8. Enter DVR address (This address is only for demonstration. P lease use the address depends on the setup of on-site DVR.) i nto the bl anks shown i n pi cture, and t hen press “add.”...
Page 79
9. Newly added website will appear at the trusted web sites list. Press close. 10. Go back to IE window, press refresh button or F5.
