Trust TV-1800 Product Information

TV-1800 PCTV Tuner
Product information
Connections
Connection
VGA IN
PC AUDIO IN
VGA OUT
STEREO OUT
TV OUT
ANTENNA
DC-IN
AUDIO-L IN
AUDIO-R IN
VIDEO IN
S-VIDEO IN
Control Panel
CH+/UP
CH-/DOWN
VOL-
VOL+/ENTER
MENU/ESC
FINE TUNE
POP SOUND
SEL
POP
SOURCE
POWER
Installation
Buttons described in the instruction manual correspond to buttons on the remote control.
Other buttons are detailed below.
1 Open the battery case by pressing on the cover and sliding it down and insert the batteries as indicated.
2 Switch off the computer.
Description
Connection from computer (VGA card).
Connection from sound card.
Connection to the monitor.
Connection for the speakers.
Connection for the output (to the TV) video signal (yellow).
Aerial connection.
Power adapter connection (12VDC/1A/12VA).
Connection for the AUDIO signal input (left).
Connection for the AUDIO signal input (right).
Connection for VIDEO input signal.
Connection for S-VIDEO input signal.
Description
Channel up/Menu up.
Channel down/Menu down.
Decrease volume.
Increase volume/Menu confirmation.
Opens the menu.
Fine tuning.
Selects the sound source (Computer sound or sound from the POP windows).
Note: This function only works if the POP window has been activated.
- Picture On Picture mode.
- Activates the POP window.
- Alters the size of the POP window when this is active.
Source (PC/TV/VIDEO/S-VIDEO).
Turns the device on/off.
