SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS

SERVICE MANUAL

Indoor unit
[Model names]
[Service Ref.]
PCA-RP50KAQ
PCA-RP50KAQ
PCA-RP60KAQ
PCA-RP60KAQ
PCA-RP71KAQ
PCA-RP71KAQ
PCA-RP100KAQ
PCA-RP100KAQ
PCA-RP125KAQ
PCA-RP125KAQ
PCA-RP140KAQ
PCA-RP140KAQ
INDOOR UNIT
ON/OFF
TEMP
WIRELESS REMOTE
CONTROLLER
(Option)
indication
TEMP.
ON/OFF
WIRED REMOTE
CONTROLLER
(Option)
CONTENTS
1. REFERENCE MANUAL ................................... 2
2. SAFETY PRECAUTION ................................... 3
3. PART NAMES AND FUNCTIONS .................... 4
4. SPECIFICATIONS ............................................ 7
5. NOISE CRITERION CURVES ...................... 10
6. OUTLINES AND DIMENSIONS ..................... 12
7. WIRING DIAGRAM ............................................. 15
9. TROUBLESHOOTING ................................... 17
10. SPECIAL FUNCTION ..................................... 32
11. DISASSEMBLY PROCEDURE ....................... 35
PARTS CATALOG (OCB491)
December 2010
No. OCH491
NOTE:
• This manual describes only
service data of the indoor
units.
• RoHS compliant products
have <G> mark on the
spec name plate.
