OPERATING INSTRUCTIONS
MODEL : L-10D ELF
BEFORE USING TELEVISION RECEIVER,
READ AND OBSERVE ALL OF THIS OWNER'S MANUAL
Part No. 11907343A
I
mportant safety instructions
1)
Read these instructions.
2)
Keep these instructions.
3)
Heed all warnings.
4)
Follow all instructions.
5)
Do not use this apparatus near water.
6)
Clean only with dry cloth.
7)
Do not block any ventilation openings. Install in accordance with the manufacturer s
instructions.
8)
Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9)
Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your outlet.
Consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, table or wall mounted arm
specified by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of
time.
14) Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as if the
power-supply cord or plug is damaged, if liquid has been spilled on the
TV, the TV does not operate normally, or has been dropped.
15) The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
Owner's Manual
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L-10D and is the answer not in the manual?

Questions and answers

Summary of Contents for ELF L-10D

  • Page 1 11) Only use attachments/accessories specified by the manufacturer. MODEL : L-10D ELF 12) Use only with the cart, stand, tripod, bracket, table or wall mounted arm specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
  • Page 2 "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric Please read through this guide carefully, with a L-10D ELF TV in front of you, as you begin the shock to persons.

  • Page 3: Table Of Contents

    L-10D ELF television THE CONTENTS The L-10D ELF is a 10 inch, QAM, VSB television, designed specifically for use in hospitals. It provides for six service levels: Free, Locked, Basic Unpaid, Basic Paid, Premium 1, Premium 2.

  • Page 4: A Bout The L-10D Elf Television A

    ENTER/CC button all possible selections can be made. the panel, become active when the L-10D ELF TV is operated as part of a While on a Digital channel the possible modes are are Service 1, Service 2, computerized system.

  • Page 5: A Bout Service Levels

    bout service levels bout service levels TV's are generally programmed for the required service levels before they are 3. Basic Unpaid Service Level installed in a hospital. When you replace TV's or when channel numbers change, When a patient "self rents", the TV automatically goes to the Basic Unpaid reprogramming is needed.

  • Page 6: H Ow To Use Self Rent Feature H

    Rental: Free to In addition to the 6 Channel Maps the L-10D ELF contains a Master Map. The to cancel. Master Map contains a list of all Analog and Digital TV channels which were found Rental: Basic Unpaid.

  • Page 7: A Bout The Infrared Hand Unit A

    L-10D . The TV Make the selection on the infrared hand unit by pressing and releasing the representative can perform all the patients' functions and can also select and button(s) quickly.

  • Page 8: A Bout Programming The L-10D Elf

    Programming is the process of selecting options from the special features of the 1. Press SETUP on the infrared hand unit. SETUP MENU Ver : x.x.x L-10D ELF TV. Programming includes selecting entertainment channels, as well 2. Press CH to select Rental: service level...

  • Page 9: H Ow Do I Select A Tv Service Level

    ow do I select a TV service level? ow do I adjust the TV picture? Locked To adjust the quality of the TV picture ... - Choose VOL Locked Service SETUP MENU Ver : x.x.x Level or simply press the LOCKED button on 1.

  • Page 10: H Ow Do I Adjust The Tv Picture

    ow do I adjust the TV picture? ow do I adjust the TV sound? Contrast To adjust the quality of the TV sound ... - Select CH Contrast to adjust the overall contrast of the picture. SETUP MENU Ver : x.x.x Hold down the VOL+ button to increase or the VOL- button to reduce contrast.

  • Page 11: H Ow Do I Set What Channels The User May View

    Note: The TV must be configured for the TV channels being supplied to it by If the L-10D ELF is set to STEREO and no stereo signal is being broadcast, a using Auto scan. This must be done before the individual channel Maps are MONO signal will automatically be received.
  • Page 12 ow do I Set What Channels the User May view. ow do I Set What Channels the User May view. To assign a channel map ... Remove Scrambled Select CH Assign channel maps to program the channel selection with Select CH Remove Scrambled to automatically remove scrambled the appropriate level of service.

  • Page 13: Dtv Menu

    ow do I Set What Channels the User May view. ow do I set What Channels the User May view Note: If the Remove Scrambled scan has been performed since the TV was Auto Scanned then one additional line will be displayed on the ADD/DELETE The previous contents of the Master Map are CHANNELS screen.

  • Page 14: Video Mode

    ow do I set What Channels the User May view ow do I set What Channels the User May view Fine Tune channel Pressing the Vol+ button repeatedly will cycle the TV through the three possible settings as shown. If a dashed line or no color appears, the screen is unstable, therefore try Pressing Vol- will cycle through the modes in the reverse order.

  • Page 15: H Ow Do I Change The Features Of The Tv

    ow do I change the features of the TV? ow do I change the features of the TV? To change the Features of the TV Speaker 1. Press SETUP on the infrared hand unit. When the speaker is turned off, viewers can hear the TV only with an 2.
  • Page 16 Digital or Analog will change both modes to OFF. If CCD is disabled then both CCD modes will be set to OFF and pressing the ENTER/CC button will not The L-10D ELF Television can be programmed and controlled by a computer cause the CCD mode to be displayed or changed.

  • Page 17: H Ow Do I Operate The V-Chip

    ow do I operate the V-chip? ow do I operate the V-chip? CALLING UP THE BLOCKING MENU MOTION PICTURE RATING. 1. Press SETUP on the infrared hand unit. RATING REMARKS 2. Press CH to select Blocking. N/A (No rating) Not rated or not applicable program movie 3.
  • Page 18 ow do I operate the V-chip? ow do I operate the V-chip? NONE: Not rated or not applicable program. TV PARENTAL GUIDE RATING Important note: You have the ability to block all programs which are not rated, but you should be aware that such blocking may This procedure allows parents to block programs which contain TV Parental guide have unintended consequences.
  • Page 19 ow do I operate the V-chip? ow do I operate the V-chip? TV-Y7 (FV;Directed to older children): This program is designed for children age 7 and TV-G (General audience): Most parents would find this rating suitable for all ages. above. Although this rating does not signify a program designed specifically for children, most parents may let younger children watch TV-G programs unattended.
  • Page 20 ow do I operate the V-chip? ow do I operate the V-chip? TV-14 (D/L/S/V: Parental caution recommended): This rating contains some CONTENT LABELS material that many parents would find unsuitable for children under 14 years of age. TV Parental Guidelines may have one or more letters added to the basic rating to let Parents are strongly urged to exercise great care in monitoring the programs and parents know when a show contains higher levels of potentially, offensive material.
  • Page 21 ow do I operate the V-chip? ow do I operate the V-chip? CANADIAN ENGLISH RATING TO ACTIVATE V-CHIP FUNCTION BLOCKING MOTION PICTURE BLOCK CANADIAN ENGLISH RATING TV PARENTAL GUIDE 1. Press SETUP on the infrared hand unit. CANADIAN ENGLISH RATING REMARKS 2.

  • Page 22: H Ow Do I Change The Language

    ow do I change the language? hat if To select either English, Spanish or French in the The "self rent" feature is not available . SETUP MENU programming screens and rental instructions ... Make sure that Rental: Free is the selected rental service level. Rental: Free Picture Select CH...

  • Page 23: S Afeguards S

    AFEGUARDS AFEGUARDS 9. This television receiver should be operated only from the type of power CAUTION source indicated on the marking label. 10. Follow all warnings and instructions marked on the television receiver. PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS CONTAINED 11.
  • Page 24 V MAINTENANCE Your ELF television requires little maintenance in order to provide many years of trouble free service. Each television has been individually inspected on the production line to ensure safe and reliable operation. However, there is the potential for the...
