FDC 5i Taper Installation And Operating Instructions Manual

5 kw nominal output with patented tti air system inset stove
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FDC 5i Taper INSET STOVE
Installation and Operating
Please hand these instructions to the stove user when the installation is complete.
Leave the stove ready for operation and instruct the user in the correct use of the
Important: – These products must be installed by a suitably
The FDC 5i Taper stove has been exempted under the Clean Air Act 1993 to burn seasoned
wood logs in designated smokeless zones in the UK. This is subject to the correct fitting of
the air control plate (the part and fitting instructions are supplied separately) maintaining the
air wash control above a minimum setting at all times. Instructions for wood burning MUST
be followed in order to ensure compliance at all times.
T: 01722 716 161
5 kW Nominal Output
TTi
With Patented
Instructions
appliance and operation of controls.
qualified installer.
DEFRA Clean Air Act Exemption
FDC (UK) LIMITED
Unit C4, Dinton Business Park
Catherine Ford Road
Dinton, Salisbury
WILTSHIRE
SP3 5HZ
F: 01722 716 162
Air System
e:
sales@fdcsalisbury.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5i Taper and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FDC 5i Taper

Summary of Contents for FDC 5i Taper

  • Page 1 DEFRA Clean Air Act Exemption The FDC 5i Taper stove has been exempted under the Clean Air Act 1993 to burn seasoned wood logs in designated smokeless zones in the UK. This is subject to the correct fitting of the air control plate (the part and fitting instructions are supplied separately) maintaining the air wash control above a minimum setting at all times.

  • Page 2: Table Of Contents

    PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. FDC cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation. TABLE OF CONTENTS Section Page No 1.

  • Page 3: List Of Components

    2. Component Identification and Preparations for Installation Fig 2 – FDC 5i Taper Stove Assembly and controls Your stove comes packed in a plywood crate. Carefully remove the straps and lift off the upper crate. Remove any plastic packaging, open the door and remove all the contents.

  • Page 4: Installation Instructions

    2.5 To remove the door first release the 8 screws behind the door holding the metal wrap around trim to the firebox. When the trim is free the door can be lifted off its pins and placed out of the way. 2.6 Remove the metal outer trim to expose the firebox itself.

  • Page 5: Installation Information

    3.1.5 Fuels Only use recommended fuels which are seasoned (or kiln dried) wood logs or smokeless briquetted fuels. The appliance can be damaged by burning petroleum coke, liquid fuels or general rubbish and this will invalidate your warranty and risk your personal safety.

  • Page 6: Ventilation

    If you have any doubts about the suitability of your chimney, consult your local dealer/stockist or chimney specialist. If there is no existing chimney then either a solid fuel compatible prefabricated block chimney or a twin-walled insulated stainless steel flue to BS 1856 can be used. These chimneys must be fitted in accordance with the manufacturer’s instructions and Building Regulations.

  • Page 7: Material Clearances

    4.7 Hearths: All FDC Taper inset stoves require a 125mm thick non-combustible constructional hearth beneath them to protect the building; this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided.
  • Page 8 Advise the customer not to run the stove at full output for at 3 – 4 days. Explain that the stoves can provide much more or less than their rated heat outputs depending upon how they are burnt and fuels and fuel loads used. Warn the customer that using excessive air (having the air controls open too wide for too long) can over-fire and irreparably damage the stove.

  • Page 9: Technical Data & Declaration Of Perfomance (Dop)

    5.0 Technical Data & declaration of Performance (DoP) Manufacturers authorised Representative: FDC UK Ltd, Dinton Business Park, Dinton, Salisbury, SP3 5HZ. Manufactured By: Charlton & Jenrick Ltd, Telford, TF3 3AR Range Designation: FDC Taper Inset Stove Range Models: FDC 5 Inset Taper with nominal output of 5kW.

  • Page 10: Operating Instructions

    Order made and signed by the Secretary of State or Minister in the devolved administrations. The FDC 5i Taper stove has been recommended as suitable for use in smoke control areas when burning wood logs. This is conditional upon fitting the supplied secondary air control (air wash) limiters and following the wood burning instructions precisely.

  • Page 11: Cleaning

    Secondary Air (Air Wash) FDC Taper stoves are provided with a sophisticated patented “air wash” system. This secondary air supply to the stove is controlled through a slider assembly located on the top right hand side of the stove.

  • Page 12: Fuels

    Baffle: It is essential to check the top of the baffle for build up of soot and ash regularly when in use and after a long period of no use. From time to time remove the baffle if necessary to ensure that the flue way entrance is clear. 6.4 Fuels The appliance is fitted with a versatile multifuel grate and the appliance has been tested and approved burning dry, well-seasoned logs or Ancit smokeless fuel.

  • Page 13: Notes On Smokeless Fuel (Ancit) Burning

    6.5.4 Primary Air left open Operation with the primary air controls left open can cause excess smoke. The appliance must not be operated with air controls or door left open. 6.6 Notes on Smokeless Fuel (Ancit) burning Ancit, smokeless and coal type fuels require very different burning conditions to log burning.

  • Page 14: Shutting Down

    Loading 3 to 4 medium sized logs will produce a good output with reasonable burn time, generally small logs will burn up quicker producing a high output for a short time and a large log will take longer to burn and produce less output over a given time. These appliances are approved for intermittent operation on wood (0.75 to 1.5 hour burn cycles) although much longer burn times can be achieved by fully loading the firebox, getting the fuel burning well and then shutting the air controls right down (see below).

  • Page 15: Safety Notes For Your Guidance

    7.0 Safety Notes for your guidance FIRES CAN BE DANGEROUS – Always use a fireguard to BS 8423:2002 Fireguards for use with solid fuel appliances in the presence of children, the elderly or the infirm. DO NOT perform modifications to the appliance as this could seriously compromise safety in operation.

  • Page 16: Dimensions

    8.0 FDC 5i Taper Stove Dimensions FDCiT Issue 03 10/14...
  • Page 17 Blank Page FDCiT Issue 03 10/14...
  • Page 18 Blank Page FDCiT Issue 03 10/14...
  • Page 19 Blank Page FDCiT Issue 03 10/14...

  • Page 20: Frequently Asked Questions

    6 Where can I get spare parts? Your local stove retailer will be usually supply spare parts and to provide any other information you require. Alternatively contact FDC direct. 7 Can the doors be left open while burning? For safety and heat efficiency the doors should remain closed.
