Sonichi S7000-DVD Owner's Manual

3" lcd widescreen dvd player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S7000-DVD and is the answer not in the manual?

Questions and answers

Summary of Contents for Sonichi S7000-DVD

  • Page 2: Safety Precautions

    Safety Precautions 1. Only connect the unit to a 12-volt power supply with negative 5. Never expose this unit, amplifier, and speakers to moisture or grounding. water for preventing electric sparks or fires. 2. Never install this unit where the operation & condition for safety 6.

  • Page 3: Table Of Contents

    Safety Information Contents Warning Safety Precautions..........1 Safety Information..........2 For correct operation of the unit, please read and understand the enclosed user Panel Controls ............3 manual before use. Remote Controls ..........4-5 Getting Started............6 Caution USB/SD/MMC/MP3 Playback ........7 This product is a CLASS 1 LASER PRODUCT. Use of controls or adjustments General Operation ..........8 or performance of procedures other than those specified herein may result in Rotary Knob Menu ...........

  • Page 4: Panel Controls

    Panel Controls Power On/Off: Press to turn on/off the unit. 1 Panel open 2 Display switch/Time adjust 3 - Radio - Disc (when disc inserted) - USB (when USB inserted) - Card (when SD/MMC inserted) - AV-in 4 - Rotate the knob to adjust volume level. - Push to select BASS/TREBLE/BALANCE/FADER, and rotate the knob to adjust level.

  • Page 5: Remote Controls

    Remote Controls Power on/off: Press to turn on/off the unit. 1 Zoom (DVD/VCD only) 14 - Radio 2 Title (DVD only) - Disc (when disc inserted) 3 Power on/off - USB (when USB inserted) 4 Setup - Card (when SD/MMC inserted) 5 Menu cursor - AV-in 6 Enter...

  • Page 6: Remote Controls

    Remote Controls Replacing the lithium battery of remote control Remote control operating range unit. The remote control can operate within a distance of 3~5m. When the range of the operation of the card remote control becomes short or stops functioning, replace the battery with a new lithium battery.

  • Page 7: Getting Started

    Getting Started Press the button to open the panel and press to eject the disc. Note: Pressing the RESET button Light up when you slide the panel down; flashes when by inserting a pointed tool such as you remove the panel. the end of an unbent paper clip.

  • Page 8: Usb/Sd/Mmc/Mp3 Playback

    USB/SD/MMC/MP Playback USB/SD/MMC Notes . Load SD/MMC card Open the panel and insert the SD/MMC card into the slot. Close the USB functions (flash memory type) MP3 music play panel, the unit will read the file of the card automatically. 1.

  • Page 9: General Operation

    General Operation Switching on and off 1. Press to turn on the unit. 2. Press SRC once or more to select your desired function: DISC, Tuner (Radio), USB & SD/MMC, AV-in. to power off (press more than 2 seconds). 3. Press 4.

  • Page 10: Rotary Knob Menu

    Rotary Knob Menu Press the knob more than 2 seconds to enter menu mode, then EQ mode each press changes the mode as follows: Rotate the knob to select EQ sound effect: EQ MODE LOUD BEEP CAMERA 12 /24 MODE ROCK - POP - CLASSIC - FLAT - EQ OFF TA MODE RETUNE...
  • Page 11 Rotary Knob Menu BEEP ON/OFF mode / mode Rotate the knob to choose button beep sound on or off. Select 12 hours mode or 24 hours mode. HOURS HOURS CAMERA TA mode Rotate the knob to turn rear camera on or off. While unit enter Rotate the knob to choose TA ALARM or TA SEEK mode.
  • Page 12 Rotary Knob Menu RETUNE mode MIRROR IMAGE mode Rotate the control to choose RETUNE-S or RETUNE-L. Rotate the knob to choose MIRROR IMAGE mode on or off. While RETUNE-S or RETUNE-L is time length selection of TA SEEK enter MIRROR IMAGE ON mode, the video of camera is mirror retune interval.
  • Page 13 Rotary Knob Menu VOL - MODE SUBWOOFER Rotate knob to choose VOL LAST, the turn-on volume level is the Rotate the knob to choose SUBWOOFER frequency: 80Hz, 120Hz, volume level of latest power off. 160Hz. Rotate knob to choose VOL ADJ, then rotate the knob to set the turn-on volume level.

  • Page 14: Radio

    Radio Band Tune Radio tune by step manually: to power on, then press SRC once or more to select 1. Press Press less than 2 tuner. seconds. 2. Press BAND once or more to select FM1 R a d i o s e e k a u t o m a t i c a l l y : MW2.

  • Page 15: Dvd & Av In Mode

    DVD & AV IN Mode Radio and Clock DVD Mode AMS: Auto Memory Store Press SRC button to select DVD mode (when disc is inserted, and unit is reading Press AMS briefly to scan the preset station 1 - 6 disc), then press the DISP button.

  • Page 16: Rds (Radio Data System)

    RDS (Radio Data System) RDS service availability varies with areas. Please understand if RDS service is not available in your area, the following service is not available. RDS Basics AF(Alternative Frequency): When the radio signal strength is poor, enabling the AF function will allow the unit to automatically search another station with the same PI (program identification) as the current station but with stronger signal strength.
  • Page 17 RDS (Radio Data System) PTY Reception (Program Type) RDS FM stations provide a program type identification signal. Example: news, rock, info, sport, etc. PTY Mode: Press PTY to turn on the Program Type reception, the previous PTY type is shown. Press PTY once again to enter the MUSIC type or press twice to enter the SPEECH type, then use buttons 1 - 6 to select the desired program type.

  • Page 18: Disc Playback

    Disc Playback Disc Playable Disc Load / Eject File type supported Load: Press Audio file: MP3(*.mp3), WMA(*.wma) button to flip down the panel. Insert the disc into Video file: MP4(*.avi, DIVX3.11/4.0/5.0/6.0 /7.0) the slot. MPEG 2(*.vob) Eject: Press button to flip down the panel. Press to eject MPEG 1(*.dat) the disc.

  • Page 19: Audio/Video/Picture File Playback

    Audio/Video/Picture File Playback When AUDIO/PICTURE/VIDEO file is played, Category/Folder/File list will be displayed on the screen, and file/folder name being played will be displayed on top. Current selected item will be [ \ ]:MP3 SOND: FOLDER highlighted. Category Select to select AUDIO PICTURE VIDEO...

  • Page 20: Track Playback

    Track Playback Select desired track Repeat During playback, press RPT once or more. - Press to skip to the next track. - Use 1-9 and 0, 10+ buttons on the remote control to select - RPT icon will appear on the display. desired track number.

  • Page 21: Track Playback

    Track Playback Pause Program - Press PROG to enter program list. Use - During playback, press to pause playback. cursor and - The sound will be muted. digit button to enter number. - Display "PAUSE" in the TV screen, display and For DVD and File disc, select title and chapter number.

  • Page 22: Dvd Playback

    DVD Playback DVD Audio Select DVD Angle Select Press AUDIO or R/L to select audio language to listen if the DVD Press ANGLE to select different angle to view if the DVD has has multiple audio languages. multiple-angle views. ZOOM VCD Audio Select Press ZOOM button, the picture will be zoomed accordingly.

  • Page 23: Dvd Setup

    DVD Setup DVD System Setup TV System Press SETUP to display setup menu on the screen. to select setup items: Select the TV system in the setting menu. SYSTEM LANGUAGE AUDIO VIDEO DIGITAL to select and ENTER to confirm. SYSTEM LANGUAGE AUDIO VIDEO...
  • Page 24 DVD System Setup Setting TV type Setting Rating The rating of the disc is from 1 to 8: Select TV type to watch wide screen movies. 4:3 Pan Scan: For 4:3 TV, left and right edges will be cut. (1) with the most limit when playing. 4:3 Letter Box: For 4:3 TV, black bars will appear on top and (8) with the least limit when playing.

  • Page 25: Dvd Language Setup

    DVD Language Setup OSD Language Subtitle Language Select on screen display language of the DVD. Select subtitle language of the DVD from which are contained in the DVD. HUNGARIAN CZECH HUNGARIAN CZECH Audio Language Menu Language Select audio language of the DVD from which are contained in the Select menu language of the DVD from which are contained in the DVD.

  • Page 26: Dvd Audio Setup

    DVD Audio Setup Setting Volume Setup the volume with the buttons.

  • Page 27: Dvd Video Setup

    DVD Video Setup Brightness Saturation Set the brightness of the video output with Set the saturation of the video output with Sharpness Contrast Set the sharpness of the video output with Set the contrast of the video output with Set the hue of the video output with...

  • Page 28: Dvd Digital Setup

    DVD Digital Setup Output Mode Dual Mono Select the output mode: Select the audio channel from STEREO, MONO L, MONO R and LINE OUT: Compress the input signal. The volume is small. MIX MONO. RF REMOD: The volume is large. Dynamic Range When you select the compressed mode as "line out", select it to adjust the compression proportion and get the different compressed...

  • Page 29: Electrical Connections

    Electrical Connections Wiring Diagram (Yellow) Video-out 1 Video-out 2 (Yellow) Antenna Camera-in (Yellow) Subwoofer out Fuse 15A (Blue) Connector Reverse (Pink) R(Red) (Active high level input) Rear Line-out(Gray) Amplifier Parking SW L(White) (Green/ (Active low level input) White) R(Red) Front Line-out(Brown) L(White) ISO Connector...
  • Page 30 Electrical Connections Using the ISO Connector 1. If your car is equipped with the ISO connector, then connect the ISO connectors as illustrated. 2. For connections without the ISO connectors, check the wiring in the vehicle carefully before connecting, incorrect connection may cause serious damage to this unit. Cut the connector, connect the colored leads of the power cord to the car battery, as shown in the colour code table below for speaker and power cable connections.

  • Page 31: Installation Guide

    Installation Guide Installation Procedures Important: First complete the electrical connections, and then check for Remove these two screws before installation. Otherwise, correctness. the DVD player will not work. Reset Press button to flip down the panel. Then press the RESET button with a pointed object to reset the unit to the original status.

  • Page 32: Anti-Theft System

    Anti-Theft System This unit is equipped with a flip-down detachable panel. Panel can be detached and taken with you, helping to deter theft. Remove the panel . Press button to switch off the power of the unit. . Press button to flip down the panel. .

  • Page 33: Troubleshooting

    Troubleshooting If you suspect something is wrong, immediately switch power off. Do not use the unit in abnormal condition, for example without sound, or with smoke or foul smell, can cause fire or electric shock. Immediately stop using it and call the store where you purchased it. Never try to repair the unit yourself because it is dangerous to do so.

  • Page 34: Specifications

    Specifications General AM(MW) Radio Power supply 12V DC(11V-16V) Frequency range 522-1620 KHz(Europe) Test voltage 14.4V, negative ground 530-1710 KHz(America) Maximum power output 45Wx4 channels Usable sensitivity(S/N=20dB) 30 dBμ Continuous power output 25Wx4 channels (4 10% T.H.D.) Disc Player Suitable speaker impedance 4-8 ohm Pre-Amp output voltage 2.0V(CD play mode: 1KHz, 0dB,...
  • Page 35 P.N.: 127075011486...
