EZ Smart 606 User Manual

About the EZ Smart-606 Meter
The FRONT The BACK
8
1
2
9
2
4
3
5. Battery Cover
1. Display Your test results are displayed here.
6. Unit Switch Switch for mmol/l or mg/dL.
The large, easy to read screen guides you
7. Label
through the test by using numbers and
8. Reset Button Press this button to re-set
symbols.
the system.
2. M Button
9. Glucode Chip Insert the Glucode Chip for
3. S Button
coding.
4. Test port This is where you insert the Test
Strip into the Meter.

Installing/Replacing the battery

The EZ Smart-606 Meter uses one 3-Volt lithium battery (CR-2032).
When to Replace the Battery
When the battery is low, the Meter will show a warning signal. When this
display appears, it is time to replace a new battery. When the low battery
warning signal is shown, the EZ Smart-606 Meter will provide accurate results
for approximately 50 more measurements.
How to Replace the Battery
1. From the back of the Meter, gently slide and remove the battery cover.
2. Insert a 3-Volt lithium battery (CR-2032) with the “+” side facing up.
3. Slide battery cover back into place.

Setting Up the Meter

To turn the Meter on, first pull the plastic tab out from the battery chamber, then press the reset button
located at the back of the Meter and proceed with the following instructions.
Code Setting and Unit Selection
1. Select unit, mg/dL or mmol/l on the back.
2. Plug the Glucode Chip into the Glucode Chip slot for strip coding.
4. After the “S ” symbol appears, press the M button for 3 sec to switch the
“ctl” symbol. The “ctl” symbol indicates that the Meter will mark your current
test as a Control Solution test. Now you are ready to apply the Control Solution.
5. Discard the first drop of Control Solution and apply a small drop of Control
Solution onto your fingertip. Then, place this drop of Control Solution onto the
target well area.
6. As soon as enough solution has been drawn into the Confirmation Window, the
EZ Smart-606 Meter will beep and begin counting down from 8 to 1 and the
Control Solution test result will appear.
Caution: Please remember that in order to prevent contamination, follow
the above instructions for preforming the Control Solution test.
Comparing Control Solution Results
The EZ Smart-606 is functioning properly if the result falls inside the specified range printed on the Test
Strip vial. If the test result falls outside the specified range, repeat the test.
Results falling outside the specified range may be caused by:
v Error in performing the test
v Expired or contaminated Control Solution
v Expired or contaminated EZ Smart-606 Test Strips
v Improper coding of the EZ Smart-606 Meter
v EZ Smart-606 Meter malfunction
Note: The result will not be stored into the memory and will not be incorporated
into the average in the “ctl” mode.
DO NOT use the system if the problem persists. Please call Tyson Bioresearch, Inc., Customer Services
at +886-37-585-998 or website of www.tysonbio.com
Table of Contents

Introduction..........................................................................................................................

About the Product.............................................................................................................

About the EZ Smart-606 Meter....................................................................................
About the EZ Smart-606 Test Strips..............................................................................
About the EZ Smart-606 Test Strip vial..........................................................................

About the Glucode Chip.........................................................................................

Installing/Replacing the battery.....................................................................................
Setting up the Meter............................................................................................................
Coding your EZ Smart-606 Meter...........................................................................................

The Control Solution Test...........................................................................................................

Testing Your Blood Glucose Level...........................................................................................
Preparing The Test Strip...................................................................................................
Obtaining A Blood Sample....................................................................................
Applying Blood Sample To The Ez Smart-606 Test Strip.........................................................
Memory Features..............................................................................................................
Care And Storage.............................................................................................................
Display Messages.........................................................................................................
Specifications....................................................................................................
Limitations Of The Procedure...........................................................................................
Service And Warranty.......................................................................................................
Customer Service............................................................................................................................
About the EZ Smart-606 Test Strip
3
5
5
6
7
1
2
The EZ Smart-606 Test Strip is used to perform the blood glucose test in conjunction with the EZ
Smart-606 Meter. Each strip can be used only once.
The EZ Smart-606 Test Strip consists of the following parts:
1.Confirmation Window This is where you can confirm that enough blood has been applied to
the target area.
2.Target Area This is where blood is drawn into the EZ Smart-606 Test Strip.
3.Contact Bar This end of the EZ Smart-606 Test Strip is inserted into the Test Port to activate the
EZ Smart-606 Meter. (white side face up)
P. 3
Coding your EZ Smart-606 Meter
Each batch of EZ Smart-606 Test Strip is encoded with a number that must match one of the code
numbers stored in the EZ Smart-606 Meter. In order to ensure an accurate result, the code number
on the display must also match the code number found on the EZ Smart-606 Test Strip vial.
P. 6
Testing your Blood Glucose Level
Before testing blood glucose, you need the following items:
1. EZ Smart-606 Meter
2. EZ Smart-606 Test Strip
3. Adjustable Automatic Lancing Device
4. Sterile Lancet
5. Glucode Chip
Caution: To reduce the chances of infection:
v Never share a lancing device and lancet with another person.
v Always use a new and sterile lancet. Lancets are for single use only.
v Always use a new EZ Smart-606 Test Strip. Test Strips are for single use only.
v Do not get lotion, oil, dirt or debris in or on the lancet and lancing device.
Preparing the Test Strip
1.Wash hands using
s o ap an d w a r m
water.Rinse and
dry thoroughly.
4. A beep will sound and the code number will appear followed by a flashing “S”
symbol. Now you are ready to obtain a blood sample.
Reminder:
number displayed on the Test Strip vial. If the code number on the display does
not match the code number on the Test Strip vial, code the Meter by using
Glucode Chip, accordingly.( See page 7)
P. 9
3
1
1. Insert the EZ Smart-606 Glucode Chip into the Glucode Chip slot.
The EZ Smart-606 Meter will automatically be encoded.
Note: Code the EZ Smart-606 Meter whenever you start a new
Test Strip vial.
2. All segments of the LCD display will appear indicating that the EZ
Smart-606 Meter is functioning properly. Then a beep will sound,
followed by the code number.
3. Match the code number on the EZ Smart-606 Meter display with
the code number on the EZ Smart-606 Test Strip vial. If the code
matches, you may begin to test.
3.Insert the Test
2.Pull out an EZ
Smart-606 Test Strip white side
Strip from the vial face up, into the
and re-cap the
test port.
vial immediately.
Make sure that the code number on the display matches the code
Introduction
Congratulations on choosing the EZ Smart-606 System, the latest advancement in biosensor
2
technology. Adopted for its ease of use and quick response time, the EZ Smart-606 has the ability
2
to process accurate results utilizing only a small volume of blood for in vitro diagnostics. The EZ
3
Smart-606 System’s intended use is to provide a convenient and safe monitoring system for
4
diabetic individuals. This is an over the counter(OTC) product.
5
Technically, blood glucose is oxidized enzymatically when the electrical current generated by
5
glucose oxidation is measured. The advantage of using the System comes from the EZ Smart-
6
606 Test Strips, which is specially designed to allow the monitoring of your blood glucose level
6
quickly and easily. What makes the EZ Smart -606 Test Strip so special is on how blood samples
7
are drawn. Our unique design allows you to use a small amount of blood to produce results in only
8
a short time.
10
10
About the Product
11
Your EZ Smart-606 System is made up of several components. This booklet is designed to guide
11
13 you through the operation of the system with detailed directions and pictures.
14 Your EZ Smart-606 System contains:
15
vEZ Smart- Meter
606
20
vOne vial of EZ Smart- Test Strips (10 strips)
606
21
vOne Glucode Chip (outside the strip vial)
22
vOne Lancing Device (Optional for compact kit)
23
vTen Lancets (Optional for compact kit)
vOne carrying case
P. 1 Note: 25, 50 test strips vial can be purchased individually.
About the EZ Smart-606 Test Strip Vial
Code Number Exp. Date
EZ Smart-606 Control Solution Range
About the Glucode Chip
The Glucode Chip is used to ensure that your EZ Smart-606 Meter provides you with accurate
results. Before performing the blood glucose test or starting a new strip vial, please check your
EZ Smart-606 Meter with the Glucode Chip to ensure proper performance (further instructions
for use of the Glucode Chip is provided on page 7). After checking your Meter, the Glucode Chip
is also used to code setting.
v Note: Always use the Glucode Chip to ensure your EZ Smart-606 Meter is performing properly.
v DO NOT misplace your Glucode Chip.
P. 4
The Control Solution Test
The Control Solution is used to check and ensure that the EZ Smart-606 Meter and EZ Smart-606
Test Strip are working together properly and that you are performing the test correctly. For an
accurate reading, check the system with the EZ Smart-606 Control Solution on a routine basis
(approximately once a week).
NOTE :
1. Control Solutions are required but not supplied.
2. There are three EZ Smart-606 Control Solutions at different desired range of aqueous
glucose (Low, Normal or High). For more information about the EZ Smart-606 Control Solution,
Please read your EZ Smart-606 Control Solution package insert. Two sets of control solution
should be used, a high level and a low level control solution of your choice.
To perform a Control Solution test:
1. Insert a EZ Smart-606 Test Strip,
white side face up, Contact Bar’s
end first, into the test port. The
EZ Smart-606 Meter will auto-
matically turn on.
3. A beep will sound and the code number will appear followed by a flashing “S”
symbol. Be sure the code number on the display matches the code number on the
EZ Smart-606 Test Strip vial. If the code numbers do not match, code the EZ
Smart-606 Meter by using Glucode Chip, accordingly.
P. 7
Obtaining a Blood Sample
SAMPLE MAY BE OBTAINED FROM FINGER
For further instructions please see the insert provided with lancing device.
1. Unscrew and remove the endcap of lancing device.
2. Insert the lancet into the lancet holder.
3. Twist and remove the protective lancet cover to expose the sterile needle tip.
4. Recapping and unscrewing the endcap to the body of the lancing device.
5. Pull back on the cocking mechanism until it comes to a stop.
6. Place the lancing device firmly against the finger tip and press the release button.
PERFORM THE TEST
7. After sampling, remove the endcap containing the used lancet carefully.
8. Remove the lancet from the lancing device. Discard the used lancet properly in accordance with
local, state, and federal law.
Applying blood sample to the EZ Smart-606 Test Strip
1. After obtaining a blood
sample, place the drop onto
the test well of
the EZ Smart- Test
606
Strip.
P. 10
v
vLog book (Optional for compact kit)
vQuick Reference Guide
vOne vial of Control Solution (Optional for
compact kit)
P. 2
Lot Number
CODE Number
P. 5
2. All segments of the LCD dis-
play will appear, indicating
that the EZ Smart-606 Meter
is functioning properly.
P. 8
2. Blood is automatically
drawn into the EZ
Smart- Test Strip.
606
P. 11
