- Page 1 2.4” Video MP3 Player with 1.3 MP Camera 1GB Item Number: 11009924B User’s Manual * Important Notice: Please read this manual carefully All brand names and trademarks are the property of their respective owners...
-
Page 2: Fcc Compliance Statement
FCC Norm This equipment has been tested and complies with limits for Class B digital devices pursuant to Part 15 of Federal Communications Commission (FCC) rules. FCC Compliance Statement These limits are designed to provide reasonable protection against frequency interference in residential installations. - Page 3 Important Information 1. Any disconnection of the unit in the process of formatting, uploading or downloading will lead to program errors. 2. Remove the battery if the unit is not used for a long period of time to avoid any damage which may be caused by battery leakage.
-
Page 4: Getting Started
Getting Started Step 1: Set up the software: If your computer is running Windows 98, you should install the Windows 98 driver from the CD software included with your MP3 Player. To do this insert the CD in your CD-ROM drive and follow the steps below: Double-click the ”My Computer”... -
Page 5: Understanding The Display Screen
Understanding the Display Screen Charging and Battery Level “ ” Indicates that the power of Battery is full. When power runs out, Indicator will become blank, at this time you will need to re-charge your MP3 player. Charging: Charge the battery by connecting to your PC via the USB cable connector Please turn on the player before charging. -
Page 6: Basic Functions
Basic Functions Volume adjust On “Music” mode, press “ button then the speaker on screen turns red, then press “VOL+” “VOL-“ button to decrease or increase volume. Turning the unit on Press the “Power on/off” for 5 seconds to turn on the player, then you can press the“ (Prev/next), “... - Page 7 Music How to play music: 1. Plug the earbuds provided with the player into earphone jack. 3. Turn power on, press “ or “ / ” or “OK” or “M” button to enter into the master menu, press “ or “ / ”...
- Page 8 4.8. Delete Delete the file you want, press “ / ” to confirm if you want to delete, Press “OK” to confirm. 4.9 Delete All to delete all the songs Delete all the files you want, press “ / ” to confirm if you want to delete, Press “OK” to confirm. 5.
- Page 9 Note: You must plug the earphones while listening to the radio. The earphones work as the antenna. Without plugging in the earphones, the player may receive no FM signal. This player can save 30 stations. On main menu, press “ ”or “...
- Page 10 Stop Radio & Exit If you choose this option, then the player will stop from radio mode and return to main menu. Or you may exit the Radio mode by pressing “OK” firmly under Radio display mode. Display the radio favorite channel Enter the “FM Radio”...
- Page 11 3.1. You can set “Background color” and “Foreground color” of the text, “Focus Background color” and “Focus Fore color” of the bookmark. –3 different colors by different grade selectable 3.2. Focus When you stop reading on specific paragraph, you may press “M” and select “ Focus” mode, Select “On”...
-
Page 12: File Explorer
2.2. Press “OK” to start recording video, press “OK” again to stop and save the video. Then you can press “Power On/Off” to turn back to “Movie” menu, and watch the recorded videos in the folder “RECORD”. 3. Audio Recorder On “Multi Rec.”... - Page 13 Explorer is available for the files in Nandflash and MicroSD card, the functions including: 1. You can choose the folder and file you want to view, Press “OK “ to play it. 2. Delete file: Choose the file you want to delete, then press ”M”, then you can choose “Delete” , then press “OK “, then choose yes, press “OK”...
- Page 14 If you choose “Auto”, then you can listen to the music with earphone or unplug the earphone, with speaker. If you choose “Always On”, then you just can hear the voice from the speaker. If you choose “Always Off”, the speaker will turn off; you must plug the earphone to listen to the music, or there is no voice.
- Page 15 Alarm”, by pressing “OK” button to confirm your choice. microSD Memory Card function This MP3 player has a slot in the bottom which can accept microSD cards up to 1GB in order to increase the total memory size. AVI Files conversion software You can download the conversion software from the CD included with your unit and set it up.
-
Page 16: Specifications
Specifications Screen 2.4” LCD Screen with 262K colors Connecting to PC USB2.0 Built-in Memory Micro SD memory card maximum capacity Video format AVI ( any format should first converted by AVI Convert tool) Photo format JPEG, GIF Language English, Spanish Music format MP3, WMA Record format... -
Page 17: Customer Service
1. Make sure volume is not set to “0” position and the connection to earphone is valid. No Sound 2. Please make sure the earphone is clean. 3.Damaged MP3 files may have noise and even cannot be played. Make sure the video is converted correctly by the soft provided the driver Can’t play the video 1. -
Page 18: Warranty
For information regarding the return or exchange of this item within 14 days of purchase , please visit your Inkstop store location or go to www.inkstop.net to read the instructions regarding customer service returns procedures. Click on the Satisfaction Guaranteed icon on the website. For technical support in regards to operation and installation of this item please call the toll free number below to obtain assistance. - Page 19 90 Days Limited Warranty This product is warranted to be free from defects in material and workmanship for a period of 90 days. Warranty obligations are limited to replacement or repair of defective parts and components, at the option of the manufacturer. If the original model is no longer available, we will substitute with a model of equal or better value than the original item.
