Summary of Contents for MI-Audio Soldano X88R
- Page 1 Soldano X88R Pre-amp User Manual Created By Stuart Duncan - 9/10/2007 Page: 1...
- Page 2 Soldano X88R Summary Congratulations on acquiring one of MI-Audio’s hand made pre-amps. Essentially this pre-amp has three separate channels each voiced to match classic amplifiers that are no longer in production, which are… Channel 1 – American Clean Channel 2 – UK Crunch like older JCM800’s Channel 3 –...
- Page 3 Soldano X88R X88R Front Panel Explained Ch 1 Ch 2 Ch 3 1. Guitar ¼” line input socket. 2. Channel 1 - boost switch, boosts treble or gain depending on your amps specifications. 3. Channel 2 - boost switch, boosts treble.
- Page 4 Soldano X88R X88R Rear Panel Explained Fuse 20. 240 Mains Fuse 250V/0.50amp Slow Blow 21. 240 Volt Mains On/Off Switch 22. Earth Loop switch, may be effective to eliminate or minimize any earth loop hum 23. 6 Button Footswitch socket 24.
