- Page 1 TECUMSEH Basic Troubleshooting and Service Information...
-
Page 2: Table Of Contents
General Safety Precautions ........................1 General Information ..........................2 Reviewing The Engine ID Label ......................3 Model Numbering Identification for Tecumseh's Full Engine Line ............4 Spark Plug Replacement (4-Cycle) ......................5 Spark Plug Replacement (2-Cycle and Europa) ..................6 Fuel Recommendations ........................7-8... -
Page 3: Safety Definitions
The information in this guide is intended to assist individuals who are knowledgeable in basic engine repair and maintenance. If you are unfamiliar with two and four cycle engine operation and maintenance, DO NOT attempt any maintenance or repairs. Contact your local Tecumseh Servicing Dealer for assistance. -
Page 4: General Safety Precautions
General Safety Precautions store and dispense fuel. Tecumseh recommends purchasing gasoline in containers with a capacity A. Avoid Carbon Monoxide Poisoning of 2.5 gallons or less. Small containers are easier to handle and help eliminate spillage during All engine exhaust contains refueling. -
Page 5: General Information
The following information is being provided to assist you in locating and recording your engine model and specification numbers. This information will be needed to use this book or obtain parts from a local Tecumseh dealer. Model Numbering System for Tecumseh’s Full Engine Line... -
Page 6: Reviewing The Engine Id Label
Model Numbering System for Current Tecumseh’s Full Engine Line Reviewing The Engine ID Label Effective with the 2004 Model Year, we have changes to the engine I.D. label on our products. The following pages will explain the information contained on the label dependent on the age of your product. -
Page 7: Model Numbering Identification For Tecumseh's Full Engine Line
Model Numbering Identification for Tecumseh’s Full Engine Line CURRENT CODE (effective 2004 production) Prior to 2004 Model Number Conversion Chart 1st Space - Valve Orientation T = Two Cycle O = Overhead Valve 4-Cycle L = L-Head LEV90 OHH60 - LV148EA... -
Page 8: Spark Plug Replacement (4-Cycle)
* OVXL models with specification nos. 202700, 203000 and Using an incorrect spark plug can cause severe engine up, use RN4C. damage or poor performance. Tecumseh uses all three of the reaches shown. OHM120 models with specification nos. 224000 and up, †... -
Page 9: Spark Plug Replacement (2-Cycle And Europa)
Not all spark plugs have the same heat range or reach. Using an incorrect spark plug can cause severe engine damage or poor performance. Tecumseh uses all three of the reaches shown. Note: If you need assistance locating your engine model numbers please check page 3 or 4. -
Page 10: Fuel Recommendations
GASOLINE Tecumseh Power Company strongly recommends the use of fresh, clean, unleaded regular gasoline in all Tecumseh engines. Unleaded gasoline burns cleaner, extends engine life, and promotes good starting by reducing the build-up of combustion chamber deposits. Leaded gasoline, gasohol containing no more... - Page 11 NEVER leave the engine unattended when it is running and NEVER run engine in enclosed areas. FUEL ADDITIVES Only fuel additives such as Tecumseh’s fuel stabilizer Part No. 730245A or liquid varieties can be used when mixed properly. For winter applications, Isopropyl alcohol fuel dryers may be used in the fuel system but must be mixed at the proper ratio recommended by the manufacturer.
-
Page 12: Tecumseh 4-Cycle Lubrication Requirements
TECUMSEH 4-CYCLE LUBRICATION REQUIREMENTS Tecumseh recommends the use of a high quality, brand impurities from the engine and maximize engine life. name oil with a minimum classification of SL/SJ. Very Consult the operator's or repair manual for the oil few air cooled engines have any type of oil filtration... -
