V2110
Operator Control Keyboard
Installation/Operation Instruction
This manual describes the installation and operation procedures for V2110 operator control keyboard. The
V2110 keyboard can work with all Infinova series matrix switching systems to control a specific monitor
or all monitors by changing the settings of DIP switch.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V2110 and is the answer not in the manual?

Questions and answers

Summary of Contents for Infinova V2110

  • Page 1 This manual describes the installation and operation procedures for V2110 operator control keyboard. The V2110 keyboard can work with all Infinova series matrix switching systems to control a specific monitor or all monitors by changing the settings of DIP switch.

  • Page 3: Copyright Statement

    This device must accept any interference received, including interference that may cause undesired operation. The V2110 keyboard has been tested and found to comply with the limits for Class A digital device, pursuant to Part 15 of the FCC rules.
  • Page 4 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. Unplug the power supply when the device is not to be used for an extended period of time.

  • Page 5: Table Of Contents

    Table of Contents 3.4 Calling Presets ..............4 Chapter I General Description ............. 1 1.1 Description................1 3.5 Running System Tours............4 1.2 Features................. 1 3.6 Auxiliary Control ..............5 1.3 Keyboard Layout ..............1 3.7 Alarm Acknowledgment ............5 3.8 Monitor tour programming ...........

  • Page 7: Chapter I General Description

    Chapter I General Description 1.3 Keyboard Layout 1.1 Description The V2110 operator control keyboard is designed to work with all ENTER Infinova series matrix switching systems, and it can provide camera LENS Infinova call-up, and sequence programming functions when used with MONITOR suitable accessories.

  • Page 8: Chapter Ii Hardware Connections And Setup

    Setup 0=OFF, 1=ON Control 2.1 Connections The V2110 keyboard is supplied with the following equipments: One AC adapter (230VAC/6VAC or 120VAC/6VAC) One 8-pin modular cable (The 8-pin modular format is commonly referred to as a RJ-45) One 8-pin terminal box The Terminal Box shown below is for RS-232 connections.
  • Page 9 0=OFF, 1=ON 0=OFF, 1=ON Control Control All MON...

  • Page 10: Chapter Iii Keyboard Operations

    2. Press the MON key. The monitor number will appear in the operators can manually control P/T by using V2110 joystick. After MONITOR display. the camera has been positioned appropriately, release the joystick.

  • Page 11: Auxiliary Control

    Use the auxiliary ON/OFF keys on the When a monitor is armed, and the alarm is activated, the camera V2110 keyboard to control either type. video associated with an alarm appears on that monitor. A momentary auxiliary remains active as long as its control key is To arm a monitor, pressed.

  • Page 12: Appendix I Specifications

    Appendix I Specifications General Auxiliary Keys Control of auxiliary (Off and On) Monitors Up to 127 monitors Shot (Preset) Call pre-defined scenes for suitably Cameras Up to 9999 cameras equipped pan/tilts and domes Keyboard display Monitor ID and Camera ID Data Port Keyboard Control RS232...

  • Page 13: Appendix Ii Typical Connections

    Appendix II Typical Connections 1. Connect V2110 to V2011A...
  • Page 14 2. Connect V2110 to V2020A...

  • Page 15: Appendix Iii Cable Diameter Calculation And Lightning & Surge Protection

    Appendix III Cable Diameter Calculation and Lightning & Surge Protection Relation between 24VAC Cable Diameter and Transmission Distance In general, the maximum allowable voltage loss rate is 10% for AC-powered devices. The table below shows the relationship between transmission power and maximum transmission distance under a certain specified cable diameter, on condition that the 24VAC voltage loss rate is below 10%.
  • Page 16 Lightning & Surge Protection The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
  • Page 18 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V2.1 1306...
