VTC Pro Audio V62 Service Manual

Type ys6020
Hide thumbs

Advertisement

Quick Links

Download this manual
CANADA
Yorkville Sound
550 Granite Court
Pickering, Ontario
L1W-3Y8 CANADA
Voice: (905) 837-8481
Fax: (905) 837-8746
www.vtcproaudio.com
U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: (716) 297-2920
Fax: (716) 297-3689
V62
Power
V 6 2
Protect
Push to
Reset
POWER AMPLIFIER
Power

Service Manual

Channel A
-15
Channel B
-15
-18
-18
-12
-12
-21
-9
-21
-9
Clip
Clip
-6
-6
Signal
-30
-3
Signal
-30
-3
-0 0
-0 0
0
0
-00
-00
0
0
dB
dB
MODEL TYPE: YS6020
Manual-Service-VTC-V62-00-1v0.pdf

Advertisement

loading
Need help?

Need help?

Do you have a question about the V62 and is the answer not in the manual?

Questions and answers

Related Manuals for VTC Pro Audio V62

Summary of Contents for VTC Pro Audio V62

  • Page 1: Service Manual

    Channel A Channel B Voice: (905) 837-8481 Voice: (716) 297-2920 V 6 2 Protect Clip Clip Push to Fax: (905) 837-8746 Fax: (716) 297-3689 Reset POWER AMPLIFIER Power Signal Signal -0 0 -0 0 Service Manual MODEL TYPE: YS6020 www.vtcproaudio.com Manual-Service-VTC-V62-00-1v0.pdf...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance.
  • Page 3 VTC V62 Parts List 5/13/2010 YS # Description Qty. YS # Description Qty. YS # Description Qty. YS # Description Qty. 5906 RED 3MM LED 1V9 20MA.4SPCER T&R 2444 25.00 AMP CIRCUIT BREAKER 6124 1/4W 3K 5%MINI T&R RES 3587 DPDT ROKR SW QUIK 250"AC/PWR ON 5908 GRN 3MM LED 1V9 20MA.4SPCER T&R...
  • Page 4 TO92 5101 6874 5.0W BAV21 TO126 TO92 D34B M1370 / M1176 / M1178 Database History R123B C30B D33B MR854 MODEL(S):- AM4CE / AP6020 / V62 1/2W 220N 250V D32A D34A D33A MR854 DATE VER# DESCRIPTION OF CHANGE D32B MR854 R123A...
  • Page 5 TO-92 AP6020 {Watts} 6478 {Function} M1176 M1178 AS35FN RefDes Value/YSpart# Value/YSpart# 14K7 14K7 W7:A W7:B 220P 100V 3696 3696 W7:C 4148 1/4W 10K0 W7:D MINI These parts are not K1:B stuffed on M1370. W7:E NE5532N K1:A W7:F 1/4W NE5532N 14K7 MINI U1:C 1/4W...
  • Page 6 BC560C ZD2C 1N750ARL 5102 TO92 BC560C R50C 1/4W 1/4W 5102 4148 MINI TO92 R60C1 1/4W R04C MINI 1/4W 330P 100V C40C R45C C26C C17C 1/4W 100V 100P 4K12 R35C MPSA13 1/4W 10K0 C21C MINI 1/4W 220N R44C 5105 100K 1/4W MC33078P TO92 MINI...
  • Page 7 470P BC560C R49C R50C 1/2W R48C R04C 22V0 X8002 C11B C12B R51B D10B BC560C R50B R52B SOCKET AP6020 / AM4CE / V62 470R 4148 4K99 X63C R47C V9.00 4148 100R0 470K SOCKET UPSIDE DOWN 4007 220P 100R0 LD5C 4148 100R0...
  • Page 8 SEE LAYOUT DIAGRAM PRODUCTION NOTES 6. MOUNTING HARDWARE FOR TO3 OUTPUTS M1370/M1370A/M1176/M1176A/ M1178/M1178A #8761 BOLT 1. MOUNTING DETAILS FOR 5W ADD #8629 SPACERS ONLY ON 5 WATT RESISTORS R130A, R130B AND R131B. TO-3 TRANSISTOR 4. MOUNTING HARDWARE FOR Q17B AND Q18B. #3915 THERMAL PAD 2.
  • Page 9 SEE LAYOUT DIAGRAM M1370 / M1176 / M1178 Database History M1370 / M1176 / M1178 Database History MODEL(S):- MODEL(S):- AM4CE / AP6020 / V62 AM4CE / AP6020 / V62 DATE VER# DESCRIPTION OF CHANGE DATE VER# DESCRIPTION OF CHANGE PIN CONFIGURATION...
  • Page 10 BC560C R49C R50C 1/2W R48C R04C 22V0 X8002 C11B C12B R51B D10B BC560C R50B R52B SOCKET 470R AP6020 / AM4CE / V62 4148 4K99 X63C R47C V9.00 4148 100R0 470K SOCKET UPSIDE DOWN 4007 220P 100R0 LD5C 4148 100R0 LD6C...
  • Page 11 SEE LAYOUT DIAGRAM PRODUCTION NOTES 6. MOUNTING HARDWARE FOR TO3 OUTPUTS M1370/M1370A/M1176/M1176A/ M1178/M1178A #8761 BOLT 1. MOUNTING DETAILS FOR 5W ADD #8629 SPACERS ONLY ON 5 WATT RESISTORS R130A, R130B AND R131B. TO-3 TRANSISTOR 4. MOUNTING HARDWARE FOR Q17B AND Q18B. #3915 THERMAL PAD 2.
  • Page 12 SEE LAYOUT DIAGRAM M1370 / M1176 / M1178 Database History M1370 / M1176 / M1178 Database History MODEL(S):- MODEL(S):- AM4CE / AP6020 / V62 AM4CE / AP6020 / V62 DATE VER# DESCRIPTION OF CHANGE DATE VER# DESCRIPTION OF CHANGE PIN CONFIGURATION...
  • Page 13 Delete AILS routing. 5101 MBS4992 TO92 220K 09-JUN-2009 10.00 ADDED MODEL V62 AND CHANGED DBL HDR RIBBON TO92 1/4W CABLES TO PATCH CABLES. 12C CHANGED TO 2329 AND 14C CHANGED TO 2330 Indicated 2 jumpers for AM4CE WC17E instead of Limiter Swiitch. See PC#7732...
  • Page 14 Choose the correct graphic for the part#. Choose the correct graphic for the part#. AP6020 / V62 M1177 B OUTPUT Pcb Mech A OUTPUT Banana Jacks Banana Jacks X8003 !!!!! DO NOT DISCARD !!!!! BlankSize - 15000x10000 !!!!! DO NOT DISCARD !!!!!
  • Page 15 SEE LAYOUT DIAGRAM PRODUCTION NOTES M1177 AP6020 / M1371 AM4CE MOUNTING DETAILS FOR Q30 TRIAC USE #8799 TO MOUNT TRIAC Q30 IMPORTANT! AFTER MOUNTING DEVICE DO NOT CUT LEGS #2 OR #3 BEND LEGS IN DIRECTION SHOWN IT IS IMPERATIVE THAT LEGS MARKED 2 AND 3 ARE BENT FLAT 1/4"...
  • Page 16 Split nets across X81 so W17:10 connects to X104. *PLACE IMPLEMENTED CHANGES INTO BOARD HISTORY Delete AILS routing. 09-JUN-2009 10.00 ADDED MODEL V62 AND CHANGED DBL HDR RIBBON MCR100-6 MPSA06 BC550C CABLES TO PATCH CABLES. 12C CHANGED TO 2329 MBS4992...
