IP CAMERA SERIES OPERATION GUIDE Please read instructions thoroughly before operation and retain it for future reference. 459a(h)_359a(h)_552a(h)_837_403_565a_561(h)_561f_552b(h)_459b(h)_458(h)_358(h)_552c_459c_807c_552f_561e_305a_V1.8...
Page 3
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device mat not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 4
The codes are provided on the FTP site, and please download them from the following site or you can refer to your distributor: Model 1, 2, 3 & 4: http://download.dvrtw.com.tw/GPL/IPCAM/F-Seriers/linux.tar.gz Model 5: http://download.dvrtw.com.tw/GPL/IPCAM/A-Seriers/linux.tar.gz...
Below shows you how to connect an external device to this camera. 1.5 Insert a Micro SD card (For selected models only) For local video recording, a micro SD card slot can be found on the camera. The camera doesn’t support hot-swapping.
network environment is not wireless. 2.1 Camera Login Step1: Open your web browser, and key in http://ipaddress:portnum in the URL address box. For example, for the IP address 60.121.46.236 and port No. 888, please key in ”http://60.121.46.236:888” into the URL address box, and press “Enter”.
Page 10
Switch to the system configuration page, and the functions available for “Supervisor” and “Power User” are different. Config. Supervisor / Power User For details, please refer to “3.1 System configuration menu” at page 8. Media Type* Supervisor / Power User Select the image player from the drop-down list: / Normal User / Guest ...
Page 11
Function Icon User Level Description Supervisor / Power User Live View Size: / Normal User Click to display the image in full screen. To exit the full screen mode, press “Esc” on your keyboard. Full Screen This icon appears only when the selected resolution is HD1080P, SXGA or HD720P &...
2.3 Digital PTZ (DPTZ) Operations This camera has PTZ capability, i.e. digital PTZ (hereafter called “DPTZ”), for wide area monitoring. STEP1: Click “DPTZ” to show the DPTZ control panel. Type A: Type B: FUNCTION ICON DESCRIPTION When is selected, the moving control panel will be shown to move the picture after zoom-in is Moving panel performed.
STEP2: Select the functions when needed: FUNCTION ICON DESCRIPTION Resolution Select the video resolution for the DPTZ function. Only “VGA” and “QVGA” are available. Click to take a snapshot of the current view on a new window. Right click on the picture and re-save it to the Take snapshots location you want.
3. CAMERA CONFIGURATIONS Users can further configure this network camera by accessing via Internet Explorer. 3.1 System configuration menu Click “Config.” to enter the configuration page. The functions are categorized into seven menus: Network, Camera, VA, Record, Storage, Trigger and General.
Page 15
Server Log Check the system event logs. Online Check the current online user(s). 1. Create a new user account with different access privilege. Account 2. Modify or delete an existing user account. Google Maps Allow you to know where the network camera is.
3.2 Network 3.2.1 Network You can set the network configuration of the network camera depending on your network type. For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/ .swf. m359a 3.2.2 QoS QoS, Quality of Service, is the ability to control the data flow for real-time streaming. This function is important if your network bandwidth is insufficient and you have other devices to share the network bandwidth.
3.2.5 FTP Enter the detailed FTP information and click “Save” to confirm. The information you set here will be applied when “FTP” is selected in “Trigger” → “Trigger”. 3.2.6 MAIL Enter the detailed e-mail information and click “Save” to confirm. The information you set here will be applied when “Email”...
3.2.7 SMS Note: Before using this function, you need to apply an account and get an API ID from the mobile messaging company, such as Clickatell and EVERY8D. For details, please refer to “APPENDIX 4 API ID APPLICATION FOR SMS MESSAGING” at page 43. Enter the detailed information needed for text messaging, and click “Save”...
3.2.8 Filter Choose to permit or block the IP address(es) which can access this camera, and click “Save” to confirm. Function Description Filter Configuration Error Count Set the maximum count for login failure. When the maximum count is reached, the IP address trying to access the network camera will be locked.
Double-click it to quickly open the web browser for camera access. Port Mapping (Available only in UPnP) This function can eliminate the need to additionally access the router for port forwarding. For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/m359a.swf. Note: Before using this function, make sure your router supports UPnP, and this function is enabled.
Page 21
The port for multicast must be an even number. Time to Live (TTL) The range of Time to Live of the package is between 1 ~ 255. As soon as Time to Live of the package is 0, it will be dropped.
3.2.11 SNMP (For selected models only) SNMP, Simple Network Management Protocol, is used to facilitate the exchange of management information between network-attached devices, and network administrators could use it to monitor those devices. The SNMP consists of three basic components: Network-management systems (NMSs) to monitor and control the managed devices.
3.2.12 IEEE 802.1X (For selected models only) The settings here enable the camera to access a network protected by 802.1X/EAPOL (Extensible Authentication Protocol Over LAN). Note: For authentication to work properly, it's important to synchronize the time in the camera with an NTP server.
“Max Bit Rate” is the maximum limitation of data transmission in the selected image format and resolution. Take 2 megapixel model as an example below. For 1.3 megapixel model, please refer to its actual display. Note: QQVGA is for mobile surveillance only.
Type A: Type B: 3.3.3 ROI (For selected models only) ROI, Region of Interest, is used to reinforce the image quality of the selected area(s). Users could specify two areas in the camera view.
3.3.4 Color Adjust the color performance from Brightness, Contract, Saturation, and Hue (for selected models only). Click and drag the slider to preview the color change on the right side of this page and adjust the image color. To restore the default values, click “Back to Default”. 3.3.5 Advanced Adjust the camera parameters if necessary.
Item Description White Balance Process the current image to retain color balance over a color temperature range. The options are: Auto, 2500K, 3200K, 4200K, 5800K & 9500K. Sharpness Sharpness enhances the clarity of image detail by adjusting the aperture and sharpening the edges in the pictures. Hold and drag the slider to adjust the level of sharpness.
3.4 VA (For selected models only) 3.4.1 TA TA, tampering alarm, should be used with the mini-guard control switch for alarm system integration. For more details, please check with your distributor or installer. 3.4.2 DIS DIS, digital image stabilization, is used to reduce blurring associated with the motion of a camera during exposure.
3.6 Storage 3.6.1 Memory In “Memory”, you can check the remaining capacity for recording, or clear all recorded data saved if needed. Note: The recorded data will be removed also when you reset or reboot this camera. Note: To know how and where to insert a micro SD card, please refer to the installation guide. To know the compatible list of micro SD cards, please refer to “APPENDIX 7 MICRO SD CARD COMPATIBLE...
Page 30
Then, click the title “E-Mail” (in blue) to configure the media type (H264 / JPEG / MPEG4), file format (AVC / AVI), and record time (1 ~ 5 seconds) for the event video clip. The camera will send the captured video clip to the E-mail address(s) you assigned in “Network” “Mail” once the selected event type occurs.
3.7.2 Push Video (For selected models only) “Push Video” is an active notification system integrated with smart phones. Users are able to receive alarm notifications within 5 seconds after event occurrence, check what happened with video playback, and take actions immediately. Note: For Push Video to work properly, make sure the record function is on in “Record”...
3.8 General 3.8.1 General To change the language of UI interface, select from the drop-down list in “Language”. To lock camera access when it’s not used after the specified time, select “5 MIN”, “15 MIN” or “30 MIN” from the drop-down list of “Auto Lock Time”, or select “NEVER”...
3.8.2 Time Set daylight saving time and the current time, and click “Save” to confirm. Function Description Time Configuration Set the current date. Date Set the current time. Time Daylight Saving Time Configuration Specify whether to use daylight saving time (Enable / Disable). Daylight Saving Time If this function is enabled, set the time period (Start Time / End Time), and adjust the daylight saving time in hours (Adjust Time).
Life Time Select how long this account is allowed to stay online (1 MIN / 5 MIN / 10 MIN / 1 HOUR / 1 DAY / INFINITE) Step2: Then, click “Save” to save your setting and create a new account.
3.8.6 Google Maps This function is used to let you know where the network camera is. The system will prompt you to apply a Google Maps Key if your access is denied. Please follow the instructions below when you’re denied: Step1: Click “Sign up for a Google Maps key”...
Page 36
Step2: Select “Upgrade” to start system upgrading. Note: You’ll be prompted to keep current configurations. It’s recommended to keep them, or all configurations will be restored to default values after upgrade. Note: It takes a few minutes to finish the upgrade process. Do not disconnect the power during firmware upgrade, or the upgrade may be failed.
4 (H.264, MJPEG, MPEG4) ▓ General Image Sensor 1/2.9" SONY CMOS image sensor 1/4" SONY CMOS image sensor Min Illumination 1 Lux / F1.4, 0 Lux (LED ON) S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/2 to 1/10,000 sec Lens f2.8 ~ 12mm / F1.4 ~ F2.8...
Page 38
Image Sensor 1/2.8” CMOS image sensor 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux Min Illumination 1 Lux / F1.4, 0 Lux (IR LED ON) (LED ON) (IR LED ON) S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/10,000 ~ 1/7.5 (Slow shutter)
Page 39
1X: 58.8° (Horizontal) x 34.2° (Vertical) 1X: 47.3° (Horizontal) x 27.5° (Vertical) x 53.5° (Diagonal) x 66° (Diagonal) Viewing Angle 10X: 5.3° (Horizontal) x 3.0° (Vertical) x 6.1° (Diagonal) 10X: 6.35° (Horizontal) x 3.6° (Vertical) x 7.25° (Diagonal) IR LED...
Page 40
Multiple Video Streaming 4 (H.264, MJPEG) ▓ General Image Sensor 1/2.8” CMOS image sensor Min Illumination 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux (IR LED ON) S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/10,000 ~ 1/7.5 (Slow shutter) Lens f2.8 ~ 12mm / F1.4 ~ F2.8...
Page 41
1/2.9" CMOS image sensor 1/ 3" SONY CMOS image sensor Min Illumination 1 Lux / F1.4, 0 Lux (IR LED ON) 0.1 Lux / F1.5, 0 Lux (IR LED ON) 1 Lux / F1.5, 0 Lux (IR LED ON) S/N Ratio...
Page 42
1/ 3" SONY CMOS image sensor 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux Min Illumination (IR LED ON) 1 Lux / F1.4, 0 Lux (IR LED ON) 1 Lux / F1.5, 0 Lux (IR LED ON) Shutter Speed 1/10,000 ~ 1/7.5 (Slow shutter)
Page 43
Multiple Video Streaming 4 (H.264, MJPEG) ▓ General Image Sensor 1/2.8” CMOS image sensor Min Illumination 0.1 Lux / F1.4(Wide)~F2.8(Tele), 0 Lux (IR LED ON) S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/10,000 ~ 1/7.5 (Slow shutter) Lens f2.8 ~ 12mm / F1.4 ~ F2.8...
Page 44
Multiple Video Streaming 4 (H.264, MJPEG) ▓ General Image Sensor 1/2.8" SONY CMOS image sensor Min Illumination 0.1 Lux / F1.8(Wide)~F3.2(Tele), 0 Lux (IR LED ON) Shutter Speed 1/10,000 ~ 1/7.5 (Slow shutter) S/N Ratio More than 48dB (AGC off) Lens f5.0~50mm / F1.8 ~ 3.2...
Page 45
Multiple Video Streaming 4 (H.264, MJPEG, MPEG4) ▓ General Image Sensor 1/ 3” SONY CMOS image sensor Min Illumination 1 Lux / F1.5, 0 Lux (IR LED ON) Shutter Speed 1/2 to 1/10,000 sec S/N Ratio More than 48dB (AGC off) Lens f3.8mm / F1.5...
APPENDIX 2 BIT RATE TABLE FOR REFERENCE The data below is for reference only. The bit rates listed here may vary depending on the resolution, image quality & frame rate you choose, the complexity of your monitoring area, and how often the moving objects show in your monitoring area. Testing Environment ...
Page 47
Resolution Quality Frame Rate (Dynamic) kbps (Static) kbps SXGA Best 1/15 High Normal Basic Best High Normal Basic QVGA Best High Normal Basic...
APPENDIX 3 POE CONNECTION This device supports PoE (Power-over-Ethernet), developed by the IEEE802.3af or IEEE802.3at task force, and power can be supplied over the same network (Ethernet) cable as the one used to connect to Internet. No power cable is needed. Below shows two examples of POE application for reference. ...
APPENDIX 4 API ID APPLICATION FOR SMS MESSAGING To allow the camera automatically sending a text message when an event happens, you need to apply an API ID from a mobile messaging company first, such as Clickatell or EVERY8D. Below shows an example of how to get an API ID from Clickatell. Note: The SMS messaging may not be totally free.
Page 50
Step4: In your account, find “Connection Status” and create a connection (API ID). Step5: Select “HTTP/S”. Give a meaning name for this connection, and click “Submit and Get API ID”. Step5: An API ID will be generated as follows. Note: Note down the API ID for SMS notification setting later.
APPENDIX 5 Q&A For more details about Q&A, please visit our official website: www.eagleeyescctv.com Question Answer I can connect to this camera in my You didn’t configure this camera to Internet, but only in LAN. house or office where it’s installed Please follow the steps in the advanced network setup guide with wireless network.
Monitoring area: 1.5 meters away from the camera Alarm trigger conditions: (1) One person walks by the monitoring area and leaves immediately. (2) Two persons walk by the monitoring area. One goes away immediately, and the other one stays a while and goes away.
APPENDIX 7 MICRO SD CARD COMPATIBLE LIST Manufacturer Capacity Class Manufacturer Capacity Class ADATA Transcend Class 6 Class 2 Apacer Class 4 Class 4 Class 6 SanDisk Class 6 Class 4 16GB Class 10 Class 4 Kingston 16GB Class 4 Class 4 32GB Class 4...
APPENDIX 8 ENABLE PUSH VIDEO A8.1 What’s Push Video “Push Video” is an active notification system, different from traditional FTP & Email notification methods. It’s more active and stable, but also easier to be affected by your network bandwidth. When “Push Video” is enabled and any alarm event occurs, you’ll be able to receive notifications on your iPhone / iPad / Android mobile device within 5 seconds.
“Push Video” is an active notification system, different from traditional FTP & Email notification methods. It’s more active and stable, but also easier to be affected by your network bandwidth. A9.1 Check PC IP Address Note: The instructions below are taking Windows 7 and 8 for an example.
Step2: Set a user name, and choose “Administrator” for this account. Then, click “Create Account”. Step3: Set the password, and click “Create Account”. A9.3 Share Folder Note: The instructions below are taking Windows 7 and 8 for an example. Step1: Right-click the folder you want to use to save snapshots for “Network Share”, and choose “Properties”. Step2: In “Share Properties”, select the tab of “Sharing”, and choose “Share…”.
Page 58
Step3: Choose the account you want to share with, and click “Share” to save.
Page 59
IP カメラ・シリーズ 操作ガイド 今後ご参考のため、この取扱説明書をよくお読みになった上、よく保管してください。 459a_359a_459ah_359ah_552a_552ah_565a_561_561h_552b_552bh_459b_459bh_552C_553_V1.5...
Page 60
本装置は、FCC 基準パート 15 に準ずる Class A のデジタル電子機器の制限事項に準拠しています。これら の制限事項は、商業地域で使用した場合に生じる可能性のある電磁障害を規制するために制定されたもので す。本装置は高周波エネルギーを生成し使用しています。また、高周波エネルギーを放射する可能性がある ため、指示に従って正しく設置しなかった場合は、無線通信に障害を及ぼす可能性があります。本装置を住 宅地域で使用した場合無線通信に障害を及ぼす可能性があるため、ユーザーは自費でこれらの障害を修正す る必要があります。 本デバイスは、FCC 基準パート 15 に準じています。操作は次の 2 つの条件に従うものとします。 (1) 本装置により障害を発生させることはできません、また、 (2) 誤動作の原因となる電波障害を含む、受信されたすべての電波障害に対して正常に動作すること。 商標に関するご注意 iPad®および iPhone®は Apple Inc.の登録商標です。 Android™ は Google Inc. の商標です。本商標の使用には Google の許可が必要です。 Microsoft®、Windows®および Internet Explorer®は米国および/または各国において Microsoft Corporation の 登録商標です。...
イベント発生時に、カメラが自動的にテキスト・メッセージを送信可能にするには、Clickatell と EVERY8D などモバイル・メッセージング会社からの API ID を最初に適用する必要があります。 以下は、Clickatell から API ID を取得する方法の例を示します。 SMS メッセージは、完全に無料ではありません。お使いのメッセージング・サービスの課 注意: 金ポリシーをご確認下さい。 注意: 以下の手順は参考情報として記載され、Clickatell の公式サイトが更新されると異なる場合 があります。 アプリケーションについて、次の手順に従って下さい。 ステップ 1: http://www.clickatell.com/login.php に移動します。 最初にアカウントにサインアップします。 クリックしてアカウントを作成します。 ステップ 2: 「Developers Central (開発者中心) 」 を選択し、 このサービスを利用する場所を選択し、 アカウントを作成するため情報を入力します。 開発者中心 どれが適しているかを確認します。 情報を入力します 。 アカウントの作成...
Page 97
ここにアクティベーション・コードを入力します ステップ 4: アカウント内で「Connection Status(接続ステータス) 」を確認し、接続(API ID)を 作成します。 ここをクリックします ステップ 5: 「HTTP/S」を選択します。 「HTTP/S」をクリックします。 この接続に対して分かりやすい名前を付け、 「Submit and Get API ID (送信し API ID を取得) 」 をクリックします。 この接続に対して名 前を付けます クリック ステップ 5: API ID が次のように作成されます。 後で SMS 通知設定を行うため、API ID をメモします。 注意: SMS に使用する API ID...
