ABOUT MANUAL

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

07022012

Table of Contents

Need help?

Do you have a question about the AB-2316IR and is the answer not in the manual?

Questions and answers

Summary of Contents for CLEBO-HD AB-2316IR

Page 1 Megapixel HD-SDI Outdoor Bullet IR Camera CLEBO-HD AB-2316IR ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference. 07022012...
Page 2 PRECAUTIONS Do not open or modify. Do not open the case except during maintenence and installation, for it may be dangerous and can cause damages. Do not put objects into the unit. Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages.
Page 3: Table Of Contents
Table of Contents Introduction Features Parts and Descriptions Dimensions Installation Included Accessories Installation Connecting to Monitor Camera OSD Menu and Glossary 12-23 Troubleshooting Specifications...
Page 4: Features
FEATURES* Sony 1/2.8” CMOS Sensor Highest Resolution 2.1 Megapixels 720P / 1080P Mode selectable 100ft IR Distance Double Shutter WDR (Wide Dynamic Range) at 15fps Settings True Day and Night AGC / BLC / AWB 3D DNR (3D Digital Noise Reduction) D-Zoom (1~112 level) HL Mask (High Light Masking) Mirror Image Control...
Page 5: Parts And Descriptions
PARTS & DESCRIPTIONS* Front Case Control Board Power Input Connector DC 12V only Sunshield Con Cap Assembly Screw Lens Double Arm Bracket Fixing Screw Rear Case BNC Jack Set Screw...
Page 6: Dimensions
DIMENSIONS * BNC JACK VIDEO(Yellow) POWER IN VCC(Red)
Page 7: Included Accessories
INCLUDED ACCESSORIES * 1. User Manual 5. Tool 2. Mounting Template 6. L-Wrench 3. Four(4) Screw and Four(4) Dry Wall Anchors 4. 2nd Video Jack...
Page 8: Installation
SURFACE MOUNT INSTALLATION *...
Page 9: Connecting To Monitor
CONNECTING TO MONITOR* Power DC12V Video - BNC HDMI CONVERTER HDMI MONITOR HD-SDI MONITOR...
Page 10 CONTROL BOARD & ADJUSTING LENS* Adjusting Auto Focus Lens DOWN If pushing the OSD joystick to ‘UP’, the lens will start zoom-in. If pushing the OSD joystick to ‘DOWN’, the lens will start zoom-out. If you keep pushing the joystick, zoom in/out will be continuously operated.
Page 11 CAMERA SETTING ANGLE*...
Page 12 MODULE OSD MAP * PROPERTY EXPOSURE LENS BRIGHTNESS LENS TYPE CAMERA ID 0~20 MANUAL, DC, AF 0~255 SHUTTER MODE TITLE AUTO, MANUAL(Indoor, Deblur120, OUTDOOR,INDOOR/FLK,Deblur120,Deblur240 OPTIC ZOOM Deblur240, Outdoor) TELE, WIDE DISPLAY FOCUS MODE MANUAL, AUTO NON, ID,, TITLE OFF, x2, x3, x4 FOCUSING FAR, NEAR PROTOCOL...
Page 13 PROPERTY CAMERA ID 1 PROPERTY 0~255 You can define the camera ID no. from 0~255 CAMERA ID TITLE TITLE(1-) DISPLAY NONE (1-) After setting the camera ID, you also can make the title PROTOCOL PELCO-D for each camera ID no. Title is total 8 figures with BAUDRATE 9600 BPS RETURN...
Page 14 EXPOSURE BRIGHTNESS 2 EXPOSURE 0~20 You can adjust the brightness. Higher number means brighter images. The default is 10. BRIGHTNESS SHUTTER AUTO SHUTTER RETURN AUTO It’s a defualt. Shutter speed is adjusted properly. MANUAL Shutter speed is selectable from 1/30 ~ 1/60000 but it’s related to the menu LENS-MODE.
Page 15: Lens Type
LENS LENS TYPE 3 LENS AF mode is supported for Auto Focus Lens. AF LENS DC mode is supported for Auto-iris Varifocal lens. DC LENS LENS TYHPE AF LENS Manual mode is supported for Manual iris or Fixed MANUAL MODE DEBLUR120 board lens.
Page 16: Focus Mode
LENS FOCUS MODE When using Auto Focus Lens, Focus can be adjusted automatically. AUTO Also, you can set-up the TIMER to repeat the automatic focusing after finishing the installation. TIMER is OFF and from 1 ~ 10min. If you want to adjust the focus manually, select MANUAL mode. MANUAL In this case, TIMER menu will be changed to FOCUSING and you can adjust the focus Far / Near.
Page 17 FUNCTION DZOOM 0~112 Digital Zoom function (Level 0~112) 4 FUNCTION DZOOM AUTO AUTO White Balance is automatically adjusted. PRIVACY MIDDLE AUTO_H White Balance is automatically adjusted in the MOTION condition of Color temperature is high. RETURN White Balance is automatically adjusted in the AUTO_L condition of Color temperature is low.
Page 18 FUNCTION PRIVACY You can hide some parts of the screen for privacy masking. Total 30 different privacy OFF / ON zone maskings are available. PRIVACY ZONE NO 30 different privacy masking zones are available. ZONE OP Zone Display. ON/OFF ZONE NO 0~29 X-POS X-Position (0~57)
Page 19 IMAGE CHROMA 5 IMAGE 0~20 It’s color chroma level 0~20. The default is 7. SHARPNESS CHROMA SHARPNESS 0~10 It’s to make the image sharper. MIRROR FLIP High number means sharper image. The default is 10. E-Edge HLMASK MIRROR CONTRAST NORMAL COLOR SET COLOR1 ON/OFF...
Page 20 IMAGE CONTRAST NORMAL/ HIGH/ HIGHEST You can adjust the contrast level - Normal, High, and Highest. COLOR Color 1 is the default. If the color reproduction on the monitor is not satisfied, try COLOR 1,2,3 other modes - Color 2 or 3. There are total 3 different color display Color 1,2, and 3.
Page 21 WDR / BLC MAX-DR OFF/ ON MAX Dynamic Range provides clear images 6 WDR/BLC even when strong backlighting is present. Select MAX-DR ON or OFF. MAX DR MODE MODE WDR_WGT BLC OSD OFF/ BLC/ WDR BLC POS-X BLC - Back Light Compensation Mode BLC POS-Y WDR - Wide Dynamic Range (15fps Only) BLC SIZ-X...
Page 22 DA & NIGHT TDN MODE 7 DAY&NIGHT AUTO The camera switches between day and night COLOR automatically depending on the certain light level. BW to C C to BW COLOR The camera always stays at day mode. CDS SET BW LOW RETURN The camera always stays at night mode.
Page 23: Factory Set
SETUP DEFECT DET OFF / ON Dead Pixel Cancellation automatically removes 8 SETUP defective pixels. Note : It’s not recommand to use from the customer side. DEFECT DET 2.0M MODE 2.0M MODE 1080P 720P MODE 60/50FPS 1080P / 720P 1080P is the default. If you want to have low resolution LANGUAGE TDN TEST TEST OFF...
Page 24 TROUBLESHOOTING Before sending your camera for repai r, check the following or contact one of our technical specialists. No VIDEO Check the coaxial cable and make sure it is connected securel y . Check the osd menu setup of the camera. Check the power supply and make sure the camera ha s the proper voltage and current.
Page 25 SPECIFICATION * MODEL CLEBO-HD AB-2316IR GENERAL SPEC CMOS TYPE 1/2.8" 2.0M Pixels Color Pixels 2000 (H) x 1241(V) 1920x1030 pixels (at COLOR) 30fps Resolution 1920x1030 pixels (at TDN-BW) 30fps Min illumination 0.1Lux [(F1.6, 30IRE), (at COLOR)] (F1.6, 30IRE) 0.01Lux [(F1.6, 30IRE), (at TDN(B/W)]...
