POSMicro POS-X EVO-TP4 Pro User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QUESTIONS?
Ask the experts at POSMicro.com.
1.800.241.6264
Live Chat Now
support@POSMicro.com
Monday - Friday 6 AM to 5 PM Pacific Time
1.800.241.6264
POS-X EVO-TP4 Pro
Manual
More information available at
BULk DISCOUNTS
FREE SHIPPING*
*Free ground shipping to the continental USa on orders over $100.
For Help Call
POSMicro.com
SE HaBLa
ESpañOL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POS-X EVO-TP4 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for POSMicro POS-X EVO-TP4 Pro

  • Page 1 POS-X EVO-TP4 Pro Manual More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time *Free ground shipping to the continental USa on orders over $100.
  • Page 2 USER MANUAL VERSION 1.1 November 2011 EVO-TP4 Hardware System...

  • Page 3: Important Safety Instructions

    Copyright 2011 All Rights Reserved Manual Version 1.1 Part Number: 3LMPP4850211 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 4 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 5: Legislation And Weee Symbol

    LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.

  • Page 6: Revision History

    Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release November 2010 • C68 MB added November 2011...

  • Page 7: Table Of Contents

    Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........2 2. System View ......3 2-1. Front & Side View ............3 2-2. Rear View with stand ..........3 2-3. I/O Ports View ............4 2-4. System Dimension ...........5 3.
  • Page 8 6. Jumper Setting ......19 6-1. C48 Motherboard ............19 6-1-1. Motherboard Layout ..........19 6-1-2. Connectors & Functions .......... 21 6-1-3. Jumper & BIOS/Utility Setting ......... 22 6-2. B68 Motherboard ............27 6-2-1. Motherboard Layout ..........27 6-2-2. Connectors & Functions .......... 28 6-2-3.
  • Page 9 The page is intentionally left blank. viii...

  • Page 10: Packing List

    Packing List 111. Standard Accessories System (with stand) Driver CD Power adapter Power cord RJ45-DB9 cable (x3) Cable cover...

  • Page 11: Optional Accessories

    112. Optional Accessories MSR module VFD module (with RJ-45 cable) Second display (with VGA cable) Wall mount kit...

  • Page 12: System View

    System View 211. Front & Side View Item No. Description Touch screen MSR module (optional) Rugged footprint Ventilation HDD door 212. Rear View with stand Item No. Description VFD dummy cover MSR dummy cover...

  • Page 13: I/O Ports View

    213. I/O Ports View C48 / B68 Motherboard f g h i j k Item No. Description Power button 2nd VGA Parallel USB x 4 COM 1, 2, 3, 4 (from right to left) Line-out Mic-in Cash drawer Power switch DC-IN C68 Motherboard f g h i j k...

  • Page 14: System Dimension

    214. System Dimension 361mm 248mm...

  • Page 15: System Assembly & Disassembly

    System Assembly & Disassembly 311. Stand Disassembly Loosen the thumb screw (x1) and slide the stand towards the IO panel to release it from the system. Reverse the steps above to attach stand to the system. 312. Power Adapter Replacement Power adapter is secured to the system stand by a holding bracket and screws. To attach power adapter, please follow the steps below.

  • Page 16: Hd Replacement

    313. HD Replacement Please remove the current HDD first. To remove the HDD from the System Power the system down. Remove the screw(x1) from the HDD door. Open the HDD door. While pinching the HDD bracket tabs pull the HDD from the system.

  • Page 17: Open The System

    To install a new HDD. Attach the HDD to the bracket until it clicks in place. Make sure to press the edges of the drive not the center to avoid damaging the drive. Finally slide the HDD into the slot till it clicks.

  • Page 18: Ram Replacement

    315. RAM Replacement Follow the steps in Chapter 3-4 to open the system. The RAM is located on the right side of the system (see picture). Installing a RAM module Slide the memory module into the memory slot and press down until it locks in place. Removing a RAM module To remove the module pull the ejector clips out of the side of the...

  • Page 19: Peripheral Installation

    Peripheral Installation 411. MSR Installation MSR module can be installed to either side of the system. Choose one side and follow the steps below. Make sure the unit is powered down before starting. Remove the screws (x2) to release the MSR dummy cover. Connect MSR cable to the connector on system side.

  • Page 20: Vfd Installation

    412. VFD Installation Follow steps in Chapter 3-1 to disassemble the system stand. Attach the VFD module to system by fastening the screws (x2). Route the cable through cable mangement on the system stand. Connect the RJ-45 cable to COM 4 on the systems IO panel. Make sure the system is powered off.

  • Page 21: Second Display Installation

    413. Second Display Installation Follow steps in Chapter 3-1 to disassemble the system stand. Connect one end of the VGA cable to 2nd Display. Route the cable through cable mangement on the system stand. Attach the 2nd Display to system by fastening the screws (x2). Connect the other end of the VGA cable to 2nd VGA port on system IO panel.

  • Page 22: Wall Mounting Kit Installation

    414. Wall Mounting Kit Installation The Wall mounting Kit includes a wall plate, a metal bracket, and one screw. (refer to Chapter 1-2 item d) Please follow the steps below. Secure the wall plate to the wall by fastening screws (x4). 2. Attach the metal bracket to the back of the system by fastening the screw (x1) as shown.

  • Page 23: Cable Cover Installation

    4. Fasten the screw (x1) through the metal bracket to secure the wall mount kit. 415. Cable Cover Installation There are two different cable covers. These can be utilized separately or togeth- er. When both are needed, please take care that they are installed in the correct order.

  • Page 24: Cash Drawer Installation

    416. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer. Register Location: 48Ch Attribute: Read / Write Size: 8bit...
  • Page 25 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...

  • Page 26: Specifications

    Specifications Model Name EVO-TP4A / EVO-TP4C Motherboard Intel Sandy Bridge CPU Intel Pinevew D525 1.8G Intel Atom N270 processor i3-2120 3.3G, L2 3M, 65W CPU Support L2 1M, dual core 13W 1.6GHz L2 512K Pentium G850 2.9G, L2 3M, 65W Celeron G530 2.4G, L2 2M, 65W Intel Q67 PCH (Processor Controller CPU with Graphic built-in+...
  • Page 27 Dimension (WxDxH) LCD 90 degree : 361 x 248 x 337 mm Weight (N.W./G.W.) 7kgs / 8kgs Mounting 100mm x100mm VESA mounting holes for Panel PC type Windows® XP Professional, Windows Windows® XP Professional, Windows Embedded POSReady 2009, Windows XP Embedded POSReady 2009, Windows XP OS Support Embedded, Windows XP Professional for...

  • Page 28: Jumper Setting

    Jumper Setting 611. C48 Motherboard 61111. Motherboard Layout PWR1 MINI_PCIE JP12 JP12 CN24 CN23 RJ45_2 JP10 JP10 JP19 JP19 CN22 RJ11_1 CN21 CN15 CN20 CN17 CN18 CN19 SKT1 JP14 JP14 CN16 CN14 CN13 CN27 CN31 SATA2 JP18 JP20 JP20 JP18 RJ45_1 CN11 CN26 SATA1...
  • Page 29 DDR3_A2 C48 V2.1 BOTTOM LAYER...

  • Page 30: Connectors & Functions

    61112. Connectors & Functions Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN18 MIC IN CN20/JP10 System Indicator CN22 USB Port CN23 PS2 KEYBOARD...

  • Page 31: Jumper & Bios/Utility Setting

    61113. Jumper & BIOS/Utility Setting COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 Cash Drawer Power Setting Function...
  • Page 32 System Indicator Function JP10 ▲Disable Enable Inverter Selection Function JP14 ▲ CCFL CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’.
  • Page 33 COM3 & COM4 Power Setting For C48, COM3/COM4 power adjustment must be made by BIOS/Utility and Jumper. Since COM3/COM4 default is “None“ meaning no power, power must be on through BIOS prior to physical jumper change. BIOS/Utility setup Press <DEL> key to enter BIOS SETUP UTILITY when system boot up.
  • Page 34 LCD ID Setting Several configurations are applied to different sizes of panel. Please refer to the followings to complete relevant settings. • Jumper Setup LVDS Resolution Output Interface Bits Channel 800 x 600 Single 1024 x 768 Single 1366 x 768 Single 1st: LCD Panel 2nd: VGA port 800 x 600 Single...
  • Page 35 4. To switch on the power, select "+12V". Please save the change before exiting BIOS to avoid data lost. • Intel Graphics Driver Setting Right click Desktop. Select the "Graphics Properties" and enter the menu. 2. Make sure the Display Device matches the image. Intel Graphics Driver Output Interface Connector &...

  • Page 36: B68 Motherboard

    612. B68 Motherboard 61211. Motherboard Layout JP11 JP12 Version: B68 v1.1...

  • Page 37: Connectors & Functions

    61212. Connectors & Functions Connector Purpose BAT1 CMOS Battery Base ( Use CR2023) Power On Button Power LED SATA1 HDD Power Connector SATA2 HDD Power Connector LCD Interface Connector For External Touch Connector Inverter Connector CN10 Card Reader Connector CN12 LAN LED CN14 Speaker &...

  • Page 38: Jumper Setting

    61213. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 & COM4 Power Setting Function 5 7 9 11...
  • Page 39 Cash Drawer Power Setting Function JP11 +12V ▲+19V (for 24V Cash Drawer) VGA Power Setting Function ▲No Power +12V System Reset Function JP12 ▲System Normal System Reset ▲ = Manufacturer Default Setting...
  • Page 40 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel LVDS 1366 x 768 Single Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 800 x 600 Single Panel LVDS...

  • Page 41: C68 Motherboard

    613. C68 Motherboard 61311. Motherboard Layout PWR1 CN18 PWR3 MINI_PCIE1 RJ45_1 CN19 RJ11_1 CN15 JP14 CN21 CN16 JP10 JP13 DDR3_A1 SATA2 RJ45_2 FAN_CPU1 CN10 CN11 SATA1 SKT1 JP11 JP12 USB1 CN14 USB2 CN12 CN13 CN17 PRN1 CN20 FAN_SYS1 JP15 Version: C68 v1.0...

  • Page 42: Connectors & Functions

    61312. Connectors & Functions Connector Purpose CN1/2 SATA power Connector LVDS Connector LVDS INVERTER Connector SATA HDD LED Connector DVI Connector BATTERY Connector FT STATUS INTERFACE CN10/11 USB Port(Internal) CN12 Card Reader Connector(COM6) CN13 RF Connector CN14 COM5 for Touch CN15 SPEAKER & MIC Connector (Internal) CN16 PS2 Keyboard Connector CN17...

  • Page 43: Jumper Setting

    61313. Jumper Setting Power Mode Setting Function ▲ATX Power AT Power COM2 RS232/485/422 Setting Function JP10 JP13 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422...
  • Page 44 Inverter Selection Function ▲ CCFL ME Update Function ▲Lock Un-lock Hardware Reset Function ▲System Normal System Reset USB Touch Power Setting for CN11 Connector Function JP11 ▲+5VSB ▲ = Manufacturer Default Setting...
  • Page 45 CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’. (refer to the jumper shown below) 3. Connect the power cable to the system, and power on the system: in ATX mode: press the power button and it will fail power on in AT mode: turn on system power 4.
  • Page 46 4. To switch on the power, select "Power". Please save the change before exiting BIOS so as to go for physical jumper adjustment. COM3/COM4 Jumper setup Function JP12 ▲+5V COM3 +12V COM4 ▲+12V...
  • Page 47 LCD ID Setting LVDS Output Panel# Resolution Bits Channel Interface LVDS 800 x 600 Single Panel LVDS 800 x 600 Single Panel LVDS 1024 x 768 Single Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 1366 x 768 Single Panel LVDS...

  • Page 48: Appendix: Drivers Installation

    Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.
