- Page 1 u i l d a n u a l D r o i d w o r x l e a l a n d...
- Page 2 Pre-Flight Safety Check Do’s and Dont’s Pre-build Checklist Assembly Instructions PART 1: LG / BODY PLATE ASSEMBLY MINI 4 – PARTS LIST PART 1: LG / BODY PLATE ASSEMBLY MINI 6 – PARTS LIST PART 2: AIRFRAME ASSEMBLY PART 2: ENGINE MOUNTING...
- Page 3 l i g h t o p e r a t i o n a n d s a F e t y...
- Page 4 This is a quick guide for those new to Multi-Rotor craft offering some basic safety and operational procedures...and are recommended standard operating procedures for those piloting Droidworx or any multi-rotor craft. Please read the instructions for the relevant Flight Control electronics before proceeding. Go to the web site of your flight control system and make yourself well acquainted with the correct procedure for the electronics installation and software operation.
- Page 5 Make sure that you have fully charged your transmitter and onboard battery packs. Make sure that the antenna of your Radio (TX) is up and correctly positioned; make sure the receiver (RX) for your craft is well positioned within the craft and secured and that the antenna is facing downward and to the back of your craft and not touching any part of the craft.
- Page 6 Droidworx NZ Limited does not assume any lyability, whether direct or indirect, from the use of the Mini 4 or 6. Droidworx NZ Limited shall not be liable for any direct, indirect, special, incidental, punitive, contingent or consequential damages to persons or...
- Page 7 ’ ’ s a n d o n t Never fly in strong wind – the operational safe wind speed for these craft is about 10-15 KPH. In the event of a crash or a hard landing, always check the craft for damage before taking off again. In this instance, you must also check that you do not have dirt or grit in the engines;...
- Page 8 B u i l d h e C k l i s t...
- Page 9 e q u i r e d o o l s 3mm Phillips Head Driver M4 Hex Driver M3 2.5mm Hex Screw Driver M3 Hex Driver M4 3mm Hex Screw Driver...
- Page 10 s s e M B l y n s t r u C t i o n s...
- Page 11 PART 1: LG / BODY PLATE ASSEMBLY MINI 4 – PARTS LIST Product Code Parts + Spares Product Code Parts + Spares 1101-0010 Top Hub 2506-0140 Machine Screw M3x6mm Pan Philips Center Plate Nyloc Nut M3 SS 1201-0010 2506-0170 1201-0030...
- Page 12 Slide a washer over the M3x20 socket Slide the nylon spacers over the head cap screw and slide into the screws. corresponding holes of the landing gear / body plate as shown in the picture below. Fit a second landing gear / body plate on top...
- Page 13 Add screws, washers and nyloc nut to ...add nylon washers and finish with hold the engine mount plate in place. a M3 nyloc nut. Do not fasten the There are no spacers needed. Leave screws yet. all your screws fastened loosely. Now slide the engine mount plate onto the landing gear/body assembly Repeat step 1 - 7 to assemble the...
- Page 14 PART 1: LG / BODY PLATE ASSEMBLY MINI 6 – PARTS LIST Product Code Parts + Spares Product Code Parts + Spares 1101-0020 Top Hub 2506-0140 Machine Screw M3x6mm Pan Philips 1201-0020 Center Plate 2506-0170 Nyloc Nut M3 SS Universal Flight Controller Adapter Plate...
- Page 15 Slide a Washer over the M3x20 Socket Fit a second Landing Gear / Body Head Cap screw and slide into the Plate on top... corresponding holes of the Landing Gear / Body Plate as shown in the picture below. Slide the Nylon Spacers over 3 of the 4 screws.
- Page 16 ...and finish with a M3 Nyloc Nut. Now tighten all screws. Before fastening the screws..slide the Engine MountPlate onto the Landing Gear/Body Assembly with the Repeat step 1 - 7 to assemble the chamfered holes facing downwards. remaining 5 Landing Gear / Body Plate sections.
- Page 17 PART 2: AIRFRAME ASSEMBLY Attaching your Landing Gear / Body Plate to the Mini 4 Airframe follows the same principles as the Mini 6 does. Althought some parts (Center Plate, Hub, ...) look slightly different, the set-up is exactly the same. For that...
- Page 18 Place the Universal Flight Controller Fit the M3x6mm Machine Screws into Adapter Plate on top and fix with the holes of the Mini 6 Center Plate . another four M3x6mm Machine Screws. Notch indicates front of craft! Slide 4 of the 6 Landing Gear / Body setups into the corresponding slots of the Center Plate.
- Page 19 Turn your set-up upside down, slot the Put one of the Top Hubs onto the inner Top Hub onto the Landing Gear Flight Controller Adapter Plate before Assemblies as shown in the picture sliding the remaining 2 Landing Gear / below.
- Page 20 Repeat step 10 until all connections of ...and tighten with a Socket Head Cap the Mini Landing Gear Assembly are Screw M3x20mm and a M3 Nyloc Nut. securely fastened. Your set-up should now look like this. The last step is to fasten the Landing...
- Page 21 PART 2: ENGINE MOUNTING – PARTS LIST Product Code Parts Your Mini Airframe Engine Mount Screws M3x6mm 2506-0120 Engine...
- Page 22 Take a moment to familiarise yourself ...use the screws delivered with the with the engine mount disk on your engine to mount onto the craft. Mini6 Airframe. There are multiple engine mount options available for a wide range of different engines for your craft.
- Page 23 Your mounted engine should now look like this...
