Page 1 HD 1080 Car Camcorder Use only original DC 5V car charger User’s Guide <Version 01>...
Page 2: Table Of Contents
Content Content Page 1. Noticifications……………………………………. 2 ~ 3 2. Quick installation guideline- setup ……………. 3 ~ 4 3. Display review…………………………………... 5 ~ 7 4. Quick installation guideline - Installation……… 8 ~ 14 5. Setup Menu………………………………………. 15 ~ 16 6. Contents in package……………………………. 7.
Page 3: Noticifications
Camcorder. Please refer to below recommendations for safe use of the product: We recommend you to fully charge the battery before using your HD 1080 Car Camcorder for the first time. Charge the battery with the included DC 5V car charger by inserting it in the cigarette lighter for about 10 minutes.
Page 4: Quick Installation Guideline-Setup
Do not attempt to disassemble or repair by yourself. If any problem with the product is found, please contact with QQLinx’s customer service center, return the Car Camcorder (with included accessories) to the dealer where you bought your product, or deliver it to QQLinx maintenance department for inspection.
Page 5 Note: 1. The Car Camcorder supports micro SD/SDHC 32GB memory card. 2. Insert the memory card in correct direction, otherwise the Car Camcorder or the memory card may be damaged. 3. If the memory card cannot be detected by your Car Camcorder, please remove and re-insert the memory card, or replace with a new memory card.
Page 6: Display Review
3. Display Review DISPLAY HH:MM HH:MM:SS - 5 -...
Page 7 Zone ICON Description Recording Mode (Stand by) Recording Photo shot Loop Recording Period(1 min) Loop Recording Period(3 min) Loop Recording Period(5 min) Loop Recording Period(10 min) Recording Resolution(1080)DISPLAY Recording Resolution(720)DISPLAY Manual File Lock activated Auto File Lock activated Battery indicator(Full charged) Battery indicator (2/3 charged) Battery indicator (Low...
Page 8 Zone ICON Description External power Recording period HH:MM Time indicator HH:MM:SS Recording Memory Card detected - 7 -...
Page 9: Quick Installation Guideline- Installation
4. Quick Installation Guideline- Installation < Holder Installation> Top screw Top screw knob Knob (Knob 1) Latch Screw knob for Global axis (Knob 2) Sucking Disc  Clean the windshield with clean cloth where the Car Camcorder is to be attached. ...
Page 10 <Connection Installation > Step Description Screw the top screw on the holder to Car Camcorder’s screw hole on its upper side. Tips: 1. Turn knob1 clockwise to attach it to the screw hole on the top of your Car Camcorder. (Facing the Car Camcorder, turn knob1 clockwise.) - 9 -...
Page 11 Step Description Move your Car Camcorder to a proper location, press the plastic sucker on the preferred position on the windshield, then push out the latch to fix your Car Camcorder on the windshield. Tips: 1. Clean the windshield where the Car Camcorder is to be attached with soft, clean cloth.
Page 12 Step Description Release knob2 slightly, fine tune the shooting angle of your Car Camcorder to find a best angle of recording, and then turn knob2 clockwise to fix it. Tips: 1. Turn on your Car Camcorder without connecting the car charger, Camcorder stay in standby mode.
Page 13 Step Description Insert one end of the cable of car charger to your Car Camcorder’s USB power input and the other to the cigarette lighter. (Hide the cables in your car if possible) Tips： Insert the DC jack of your car charger to the DC input of your Car Camcorder.
Page 14 Insert the charger’s lighter connector into the cigarette lighter; the installation is completed. < Cabling of your Car Camcorder > - 13 -...
Page 15 Note：  Disconnection between car charger and cigarette lighter tends to occur due to different cigarette lighter positions among different car models and the vibration of the car during driving. This disconnection may lead to abnormal power On/Off switching.  How to cope with it:：...
Page 16: Setup Menu
5. Setup Menu Main Option Sub options Content  Video Review Playback  Photo Review Mode 1920x1080  Resolution 1280x720 1 min / 3 min /  Loop recording 5 min/ 10 min  Sound recording ON / OFF Recording ...
Page 17  Format YES / NO  Shake Power-ON OFF / Low / Sensitivity Normal / High  Shaking 1 min/ 3 min/ Power-ON Rec. 5 min Time English / Simplified  Language Chinese / Traditional Chinese  Default setting Cancel / Confirm ...
Page 18: Contents In Package
6. Contents in Package 5.User’s Manual x 1 1. Main Unit x 1 2. Cigarette power x 1 6. Quick Installation Guide x 1 3. Camcorder Holder x 1 4.8GB micro SD Memory card x 1 - 17 -...
Page 19: Product Specifications
7. Product specifications Light sensor HD 2.0Mega Pixel CMOS Device color Black Camera angle Wide-angle 113 degrees Memory support MicroSD / SDHC (Max. 32GB) Video format Dynamic resolution HD 1280x720 / HD 1920x1080 (cam) (30 frames per second) Static resolution 4032x3024(12M) / 3264x2448(8M) (camera) 2592x1944(5M) / 2048x1536(3M)
Page 20 G-sensor Manual settable: OFF / Low / Normal sensitivity / High G-sensor recording Manual settable: 1 / 3 / 5 min Date /Time display Year / Month / Day , Hr / Min / Sec Auto recording Fast start up enabling Auto power off after Instant power off / 15 sec / 30 sec...
Page 21: Buttons And Appearance
8. Buttons and Appearance < TOP > < FRONT > - 20 -...
Page 22 < SIDE > < BOTTOM > < DISPLAY > - 21 -...
Page 23 Description： Mark Description Content Reserved Output video via HDMI real HDMI output time Holder base Connect with sucking disc 1. Power supply 2. Connect to PC Lens 6G Lens (2M sensor) Microphone Sound recording Reset Default setting Memory card For micro SD card slot Power ON/OFF switch...
Page 24 Mark Description Content Standby mode ： Recording ON/ OFF Record button Menu mode：Enter/ Confirm Enter Menu Mode Mode button In Menu mode, the button is for options select Stand by：Red light up Recording：Red light flashing Charging：Green light up Full charged：Green light off LED Indicator Ex.
Page 25: Product Features
9. Product Features  HD 1080 Resolution  113 Degree wide angle lens  6G Lens  2M Sensor CMOS  2.5”LCD  Explosion-proof high-temperature rechargeable lithium battery  Photograph resolution up to 4032x3024  Fast recording activation after power up ...
Page 26 10. FAQ and Trouble Shooting <Recording>  Q: Why my Car Camcorder does not start recording automatically after the car is started? A: 1) Make sure your Car Camcorder is turned on after engine ignition. 2) If your Car Camcorder is turned on, try removing and re-inserting your memory card once.
Page 27 are fully inserted in correct connectors. 5) Please make sure there is enough free space left in the memory card.  The Car Camcorder stops recording unexpectedly and resumes after a while. A: 1) It is due to the “Motion Detect” function starts/pauses your recorder.
Page 28 3) Please use memory card of level C6 or higher. 4) Try copying your recorded files to the computer before playing them.  Fuzzy images can be found in recorded files after proper installation of Car Camcorder. A: 1) Make sure the windshield is clear. Dirty or greasy window glass will lead to images of poor quality.
Page 29 2) It is recommended to leave this function in off mode, as certain delay time is required to switch back to recording mode and events occurred during the delay time may be missed from recording.  How can I use the motion detection function? A: 1) Open the motion detection menu, turn on this function, and exit the menu.
Page 30  The memory card is set to the highest speed and a “speed too slow” message still appears. A: 1) Meanings of “High Speed” vary among the memory card’s suppliers, as memory write and read speed changes with card formatting. 2) If the problem remains after the card is formatted with your Car Camcorder, please format your micro SD card with a computer in “normal...
Page 31 <Installation>  How can I retrieve recording files from my Car Camcorder to a computer? A: 1) Remove the memory card from the Car Camcorder and insert it in your computer’s card reader. (The drive code of your reader varies.) 2) Insert the included USB cable in the USB ports of your Car Camcorder (USB slot) and computer (USB slot) respectively.
Page 32  How can I attach the holder to the windshield glass? A: 1) Clean the windshield where the Car Camcorder is to be attached. 2) Adjust your Car Camcorder‘s recording angle and fix it properly. 3) Please do not remove the Car Camcorder from the windshield as the sucking disc may attract dirt and dust and lead to poor connection to the glass.
