TO ALTER THE SET
TEMPERATURE
The SET temperature should be adjusted to a
level at which you are comfortable, (try the
preset 20°C to start and adjust if necessary).
Depressing either the + or – button will
activate SET mode and SET room temperature
will be displayed.
The SET temperature can now be adjusted up
or down in steps of 1°C by pressing the + or –
buttons, between a range of 5°C to 30°C.
Pressing a button once will change the
temperature 1°C, holding a button will make
the setting 'run'. If the selector pin at the rear of
the Digistat has been removed (see installation
instructions) the range is limited from 16°C to
30°C.
The Digistat will revert to displaying actual
room temperature 5 seconds after, the
temperature setting is changed and buttons are
released.
BATTERY REPLACEMENT
30 days before the batteries need replacing, a
battery symbol will flash in the right hand side
of the display.This signifies that 2 x 1.5V type
AA alkaline batteries will be needed to
replace the existing ones.The battery
compartment is situated at the bottom of the
unit (press to unlatch and slide down). Ensure
new batteries are installed correctly.When
batteries are replaced the SET temperature
may revert to 20°C and will therefore need
resetting to the desired level.
After 30 days, only a continuous battery symbol
will be displayed and the unit will remain OFF.
SET
CONFORMS TO THE ESSENTIAL REQUIREMENTS
OF THE FOLLOWING DIRECTIVES:
89/336/EEC – Electromagnetic compatibility
73/23/EEC – Low voltage directive
Invensys Controls Europe
Customer Service Tel: 0845 130 5522
Customer Service Fax: 0845 130 0622
Technical Helpline Tel: 0845 130 7722
Website: www.draytoncontrols.co.uk
Email: customer.care@invensyscontrols.com
An Invensys product
Drayton
Digistat
Digital room
thermostat
Installation and
operating instructions
090 677 ISS B
1
Advertisement
Table of Contents
Related Manuals for Drayton Digistat 1
Summary of Contents for Drayton Digistat 1
-
Page 1: Operating Instructions
Drayton TO ALTER THE SET TEMPERATURE The SET temperature should be adjusted to a Digistat level at which you are comfortable, (try the preset 20°C to start and adjust if necessary). Depressing either the + or – button will activate SET mode and SET room temperature Digital room will be displayed. - Page 2 Installation and operating instructions disconnection of the mains supply. GENERAL DESCRIPTION Digistat 1 is a highly accurate electronic room thermostat designed for use in REPLACING EXISTING ROOM THERMOSTAT normal operating environments. When installed on new or existing central Before any existing room thermostat is removed, note the position and colour heating systems it provides the benefits of greater comfort and economy.The...
Need help?
Do you have a question about the Digistat 1 and is the answer not in the manual?
Questions and answers
When the batteries need changing on the thermostat, do I have to reset the thermostat and put in all the settings, date and time again? This thermostat is new and I cannot find the answer
