  • Page 1 Network Video Recorder USER MANUAL v1.1...
  • Page 3 CAUTION TO PREVENT ELECTRIC SHOCKS AND REDUCE RISK OF FIRE HAZARDS, DO NOT USE OTHER THAN SPECIFIED POWER SOURCE. To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the literature accompanying the appliance.

  • Page 5: Table Of Contents

    目 录 CHAPTER 1 Introduction ....................... 1 1.1 Precautions ........................1 1.2 Product Appearance ....................1 1.2.1 Front Panel ......................1 1.2.2 Rear Panel ......................2 1.3 Specification ......................... 4 CHAPTER 2 System User Manual ....................5 2.1 System Application ....................5 2.1.1 Starting up the NVR ..................
  • Page 6 2.3.4.1 User Instruction ................23 2.3.4.2 Local Settings ...................23 2.3.4.3 Remote Settings ................25 CHAPTER 3 System Installation ....................28...

  • Page 7: Chapter 1 Introduction

    CHAPTER 1 Introduction 1.1 Precautions 1. Before starting NVR, make sure that the voltage of the extra power supply is the same as the NVR's requirement (110V/220V), and the ground connection is working properly. 2. Power off the NVR before connecting or disconnecting accessories and peripherals.

  • Page 8: Rear Panel

    Name Power Indicator LED HDD Indicator LED Power On/Off Reboot USB Interfaces 1.2.2 Rear Panel 1. (1) Type A(4-ch) 9 12 11 8 10 (2) Type A(9/16-ch) 9 12 11 8 10 Name Name AC 220V/110V Power Input USB Interfaces 220V/110V Transfer Switch LAN 1 (For LAN or WAN Connection) Power On/Off...
  • Page 9 2. Type G(16-ch) 10 11 12 9 13 14 Name Name AC 220V/110V Power Input USB Interfaces 220V/110V Transfer Switch PS/2 Keyboard Interface Power On/Off PS/2 Mouse Interface VGA Output Line In HDMI Output Audio Out LAN 1 (For LAN or WAN Connection) Audio In LAN2/LAN3 RS 485 Interface...

  • Page 10: Specification

    1.3 Specification Type A Type G Model No. Video Input 4-ch 9/16-ch 16-ch Video compression MPEG-4/H.264 Record Resolution 1280x720 1280x720/1920x1080 Preview Resolution 1280x720/432x240 1920x1080/1280x720/432x240 Video Output VGA/HDMI Mouse interface 1 PS/2 Keyboard interface 1 PS/2 RS-485 Interface Audio Interface MIC IN/SPEAKER OUT/ LINE IN 4 RJ45 10M/100Mbps 2 RJ45 10M/100Mbps Network Interface...

  • Page 11: Chapter 2 System User Manual

    CHAPTER 2 System User Manual Different models of NVR are functionally similar，we take Type G as an example to introduce function in detail. 2.1 System Application 2.1.1 Starting up the NVR Press the Power button on the front panel. The Power indicator LED turn green indicating that the NVR begins to start up.
  • Page 12 2 3 4 system. It is required username and password to unlock the system. 7-PTZ Control Click Up,Down,Left and right arrows to control PTZ rotating. 8-Screen Mode Support 1/4/9/16 screen division. 9-Recording Status Different background color of channel icon stands for different recording status， Blue for recording and grey for out of recording.

  • Page 13: Playback

    2.1.3 Playback Click playback button to enter the playback interface. 1-Progress cursor Move the cursor to control playing progress. 2-Playback coordinate The abscissa represents the time of playing, and the ordinate the channel of camera. Choose the channel you that want to play by checking the corresponding channel number.

  • Page 14: Parameters Configuration

    4. choose the format of backup files ( “dvr”format files can be played with DVR player, “exe” format files can be played directly, just double click the file); 5. choose the path to backup . 9-Time positioned play To enter a specific time for playback. 10-EXIT 2.2 Parameters Configuration...

  • Page 15: Scheduled Record

    Select the camera you want to change IP on the left list. Click Set and input new IP. • Add to list Choose the IP address on the left list and then click Add to list to add the camera onto the NVR host.

  • Page 16: Users

    •Begin time/End time Set begin time and end time of recording. •Day Choose the day which you want to set in schedule. •Reset Delete record mode which you have set. •Set Choose record mode， begin time and end time, click Set to set new record mode. The lower list on the interface will show the record mode when successfully done.

  • Page 17: Network

    2.2.4 Network Click config button on the main interface, enter into the Network interface as shown. • Enable network Check the box to enable remote monitoring. • Socker Port The default socket port are 9000、9001、9002，you can change them to others， such as 9003、9004、9005.

  • Page 18: Reboot

    Notes： 1. When reinstall the NVR system, please delete the domain name first, otherwise the original domain name cannot be used. 2. 9000、9001、9002 can be changed，the number is better larger than 9000 to avoid conflicts with the other ports and have to be three sequential numbers, such as 9004,9005, 9006. 2.2.5 Reboot Click config button on the main interface, enter into the Reboot interface as shown.

  • Page 19: Document Management

    • Disks for storing media files Show disk's information. • Format Disk Click to format the choosen disk. • Video Directory • Snapshot Directory • Backup Directory NVR system supports recycle recording on multi-hard disks, choose the harddisk you need to save recording files in. If you choose more than one harddisk, recording files will be saved one by one, when the first one is full, files will be automatically saved in the second one, then the third one.

  • Page 20: Adjustment

    2.2.8 Adjustment Click config button on the main interface, enter into the Adjustment interface as shown. •Select Camera Select the camera you want to setup. •Digital shutter There are 6 levels for option. By default, it is 1. You can choose 1/4 to avoid shadow when there is high-speed movement.

  • Page 21: Motion Detection

    2)Software switch：Switch according to the brightness of Image. 3)Combine：Switch according to both hardware and software. 2.2.9 Motion Detection Click config button on the main interface, enter into the Motion Detection interface. • Motion Detection Areas Select one camera channel and then set the areas you need for motion detection. You can set multi-zone areas.

  • Page 22: Ptz

    • Auto stop Auto stop alarm. • Manual stop Double click the screen to stop the alarm. 2.2.10 PTZ Click config button on the main interface, enter into the PTZ interface as shown. •PTZ Control Click Up,Down,Left and right arrows to control PTZ rotating. •Zoom •Focus •Iris...

  • Page 23: Decoder

    Click the preset name, the dome camera will turn to certain position. Click Cruise, the dome camera will auto-rotate among added presets. • Preset ID Input ID for new preset. • Name Input name for the preset. • Interval(sec) The time in seconds to dwell between switching of presets. •...

  • Page 24: Alarm

    •Add to list Select one decoder on the left list, click Add to list. All added decoders will be shown in the right list. •Reset IP Select one decoder on the left list, input new IP, click Reset to make it valid. •Delete Delete the added decoder.
  • Page 25 • Select camera Select the camera you want to setup. • Short-circuit When there is short-circut, alarm will be working. • Break Alarm When there is break alarm,alarm will be working. • Enable Snapshot Check the box, NVR will take a snapshot once the alarm triggering. •...

  • Page 26: Remote View

    2.3 Remote view 2.3.1 Network Structure System Network is as shown. 2.3.2 Network Setting Remote access to the host through a fixed IP and Dynamic Domain Name. • LAN users can access through fixed IP or dynamic domain name. • ADSL users can access only through dynamic domain name .

  • Page 27: Ie Remote Monitoring System

    2) Register a dynamic domain name through NVR software , please refer to 2.2.4. After successful registration, you could Monitoring host through dynamic domain name. 2.3.3 Using IE Remote Monitoring System Please set the security of IE correctly before remote view，steps are as follows： 1)Right click the icon internet explorer on the desktop，click property in the menu；...
  • Page 28 3) Click on figure B to get figure A again,Enter IP, User,Password of other NVR servers. Then you could monitor several NVRS under the same IE. • Playback local files remotely Click button，coming to open DVR file dialog box, find a "*.DVR" file and play Remarks：...

  • Page 29: Central Monitoring System

    2.3.4 Central Monitoring System 2.3.4.1 User Instruction 1. Please put the file dvr_caption_en.ini under the directory of C:\windows. 2. Please open the folder RCMS system, and double click RCMS.exe to run the system. Remarks: Please do not open the dvr_caption_en.ini file at random, it will easily lead to characters changed to be irrecognizable because different coder or other reasons.
  • Page 30 4.Create a Group. Click Manage Group and click ADD and then input group name, such as “Group 1” and then click OK. 5.Add the server. Please click Add Server, input the server name and input host's (NVR) IP address or domain name (such as 192.168.10.34) at first. Then select the group (such as“Group 1”) for the server.

  • Page 31: Remote Settings

    the specific server name, then click login server to get connected. 7.You will see the picture as follows. Please click OK and you will get connection to the server. 8.After the connection is built, Please right click the specific server name again and click View All ,then you will get the video of the remote server.
  • Page 32 2.Please go to Document Manage item, you will see interface as follows: Please select the server name you want to back up. Then do as follows. a.Select the camera you want to back up. b.Select the date and time for back up. c.Select the directory for back up.
  • Page 33 2.When the updating process finishes, the NVR would restart. It means NVR is updated successfully. -27- User manual of NVR...

  • Page 34: Chapter 3 System Installation

    CHAPTER 3 System Installation 1.Download mapping file of the NVR system; 2.Extract files and install ifw_en_trial (using the default options), and you will get shortcut of Image for windows on the desktop； 3.Insert Pen drive to the computer, and format it; 4.Double click Image for Windows on the desktop；...
  • Page 35 7. Select the mapping file you have download and then click Next; 8. Select the Destination directory(the Pen drive )，and then click Next； 9.Click Yes； -29- User manual of NVR...
  • Page 36 10. Check Set Active and Restore First Track， click Next，and then click Start; 11.Click Close after finishing restoring，unmount Pen drive，then insert the Pen drive into NVR，and then start up NVR； User manual of NVR -30-...
  • Page 37 12. The system will autoamtic install when starting up，Please input Y and press enter when it comes out: “Are you sure to be continue ?(y or n):)” 13.NVR will shutdown when successfully installing, remove Pen drive and then start up NVR. Notes：...
