  • Page 1 User s Manual Bar code Scanner V 3.0...
  • Page 2 The prouducts we offer have another technology of infrared automatic sensor. User only need to put the bar code into the sensing area which in front of window , 650nm laser will be automatic activater. Then aimed at the bar code which need to scan , the scanner scan automatically , the information will transmit to the host compute system.

  • Page 3: Table Of Contents

    Auto-Induction Barcode Scanner Operation Instructions Barcode Scanner Interface Cable Installing and Removing Factory Setting Edition Information KB Mode RS232 Mode Multi-scan Functions no date be transmitted. Add The Barcode ID Character ， Spring Mode Of Barcode Read ， Buzzer Interface - KBW PC In Put Mode Transmit Speed ，...
  • Page 4 Barcode Symbol Enactment - 4 CODABAR UPC/EAN Barcode Symbol Enactment - 5 UPC/EAN Edit Barcode Enactment Macro/Special Keys Set up Barcodes Termination String Set Up Barcodes Using the Advanced Setting Mode To Set Up Barcode Scanner Set Up Category Edit Key Assignments Option Numbers And Descriptions F1 - Interface Options F2 - Code 39 Options...

  • Page 11: Edition Information

    COME BACK MANUFACTURER SETTING NOTE:ALL THE PARAMETER WILL COMEBACK THE MANUFACTURER SETTING DISPLAY THE EDITION INFORMATION K B W M O D E SERIAL MODE...

  • Page 12: Buzzer

    Multiscan Function 1 ADD BARCODE ID BEFOR OPEN BARCODE SEBEFORE CLOSE BARCODE TO ADD ID TO ADD ID AFTER OPER BARCODE AFTER CLOSE BARCODE TO ADD ID 　 　 TO ADD ID SCANNING MODE LASER/CCD MODE-SINGLE LASER/CCD MODE-RESET SCAN NO TRIGGER LASER/CCD MODE-MULTESCAN LASER/CCD MODE-MULTISCAN NO TRIGGER...

  • Page 13: Interface - Kbw

    Interface-KBW PC INPUT MODE WEDGE MODE-AUTODETECT WEDGE MODE-SCAN SET 2 　 　 　 　 PASS THRU TRANSMIT SPEED TRANSMIT SPEED-0 TRANSMIT SPEED-25 KBW LANGUAGE KEYBOARD COUNTRY-USA KEYBOARD COUNTRY 　 　 　-GERMAN KEYBOARD COUNTRY KEYBOARD COUNTRY -FRANCE -RESET...

  • Page 14: Hand Shake

    Interface-Serial-1 BAUD RATE SERIAL BAUD RATE-2400 SERIAL BAUD RATE-4800 SERIAL BAUD RATE-9600 SERIAL BAUD RATE-19200 　　　（DEFAULT) HAND SHAKE PROTOCD SERIAL HANDSHAKE-NONE SERIAL HANDSHAKE-XON/XOFF SERIAL HANDSHAKE-RTS/CTS SERIAL HANDSHAKE-ACK/NAK SERIAL HANDSHAKE TIMEOUT SERIAL HANDSHAKE TIMEOUT -5 SECONDS -2 SECONDS...

  • Page 15: Data Bit

    INTERFACE-SERIAL-2 DATA BIT SERIAL DATABITS-7 SERIAL DATABITS-8（DEFULT) END BIT SERIAL DAD BITS-1 SERIAL DAD BITS-2 PARITY CHECK SERIADL PARITY-NONE SERIADL PARITY-ODD SERIADL PARITY-EVEN SERIADL PARITY-MARK SERIADL PARITY-RESET SERIADL PARITY-SPACE...

  • Page 16: Barcode On/Off

    Barcode On/Off-1 C O D E 1 1 O N C O D E 1 1 O F F C O D E 1 1 C O D E 3 9 O N C O D E 3 9 O F F C O D E 3 9 C O D E 9 3 O N C O D E 9 3 O F F C O D E 9 3...

  • Page 17: Industrial 2 Of 5

    Barcode On/Off-2 Using the Advanced Setting Mode to setup the barcode scanner. First, connect the scanner to the computer, then start WORDPAD INDUTRIAL 2 OF 5 and scan the barcode shown below (labeled "Advanced Setting Mode"). Once it has been scanned, the setting can be configured using the keyboard.
  • Page 18 TERMINATION STRING SETUP BAR CODES Barcode Symbol Set Up-1 CODE11 STRING＃1-TERMINATION CHAR-CR STRING＃1-TERMINATION-LF CODE 11 ID CODE 11 ID CHARACTER-‘M’ CHARACTER-‘Z’ STRING＃1-TERMINATION-CR+LF STRING＃1-DISABLED ON CODE 11 LASER/CCD OFF CODE 11 LASER/CCD REDUNDANCY 　 　 　 　REDUNDANCY CODE39 STRING＃2-CODE 128 STRING＃2-CODE 128 CODE 39 SS CHAR-NONE CODE 39 SS CHAR-NONE‘+’...

  • Page 19: Code 128

    Barcode 　Symbol Set Up-2 MACRO/SPECIAL KEYS SERUP BAR CODES C O D E 9 3 CODE 93 ID CHARAC CODE 93 ID CHARAC MACRO＃1-DISABLED MACRO＃1-FIND‘1’AND TER-‘H’ TER-‘Z’ REPLACE WITH ONE OFF CODE 93 LASER/ ON CODE 93 LASER/ MACRO＃2-DISABLED MACRO＃1-FIND‘2’AND REPLACE CCD REDUNDANCY CCD REDUNDANCY WITH TWO FOR CODE 39 ONLY...

  • Page 20: Interleaved 2 Of 5

    Edit ant Set Up Barcodes Barcode Symbol Set Up-3 INTERLEAVED 2　 OF 5 EDIT＃1-STRIP 1 LEADING R E N E W 2 OF 5 ID CHARACTER-‘Z’ 2 OF 5 ID CHARACTER-‘I’ GH ARACTER ON A L L BA RCODES T HAT S TART W ITH‘12345’ ON 2 OF 5 LASER/CCD OFF 2 OF 5 LASER/CCD E D I T＃2 - S T R I P T H E L A S T...
  • Page 21 Barcode Symbol Set Up-4 Barcode Symbol Set Up-5 C O D A B A R U P C / E A N OFF COBDABAR LASER ON COBDABAR LASER EAN-13 ID CHARACTER-‘E’ EAN-13 ID CHARACTER-‘Z’ /CCD REDUNDANCY /CCD REDUNDANCY U P C / E A N ON UPC-E CHANG TO UPC-A OFF UPC-E CHANG TO UPC-A EAN-8 ID CHARACTER-‘D’...
