- Page 1 Performance Series 4-Channel Amplifier Kit For 2006-2013 Harley® Road Glide Fairing with Rear Speakers JMAA-3600HR06-RCR Installation and Operation Instructions...
-
Page 2: Product Description
Product Description 2 ohm load @ 14.4vdc. This exiting new J&M Performance Series 4-channel ampli- Amplifier mounts to the custom made metal mounting fier kit has been designed specifically for use in the 2006- bracket system. 2013 Harley® RoadGlide fairing, with the Harley HK radio Custom made plug-n-play wiring harnesses are included along with a second set of speakers (4 total) mounted in the with this amplifier kit, top quality heavy gauge power/ground... - Page 3 5. Remove both of the right-side radio mounting bolts. (Figure Fig. C remove 6. Remove the upper inboard speaker screw from the right- side J&M 7.25” speaker. (Figure C) If you are using 5.25” speakers, remove the top speaker screw from the right-side speaker.
- Page 4 10. Using the (2) remaining 6-32 screws, washers, and Fig. I lock-nuts, attach the amplifier to the already installed upper mounting bracket. (Figure I) Attach the lower mounting bracket to the lower right hand fairing mounting stud. (Figure J) Position the amplifier upward as much as possible and tighten all hardware.
-
Page 5: Specifications
Specifications JMAA-3600 Channel Separation >50dB Full Range Class D Amplifier Input Sensitivity 0.2 - 10v Output Power (RMS) Stereo @ 2ohms 4 x 90 watts Frequency Response -3dB 10Hz - 22kHz Thank you for the confidence you have shown in J&M Corporation by purchasing one of our innovative products. - Page 6 WARRANTY AND REPAIR INFORMATION TWO YEAR LIMITED WARRANTY In order to facilitate the servicing of this warranty, the Warranty Registration Form should be filled out and returned within 10 days of the date of purchase. However, return of the Warranty Registration Form is not a precondition of this warranty, and this Warranty will be observed by J&M CORPORATION whether or not the Warranty Registration Form is returned, on the condition that other satisfactory evidence of the date of the original purchase is provided to J&M CORPORATION.
