16" Snow THRoweR
SeT up, opeRaTion, and SeRvicing
visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
Save THiS manual.
©
Copyright
2010 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
68010
inSTRucTionS
®
. All rights reserved. No portion of this manual or any artwork
Advertisement
Table of Contents
Related Manuals for Chicago Electric 68010
Summary of Contents for Chicago Electric 68010
- Page 1 Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.
-
Page 2: Important Safety Information
Do not let the Power Cord curl cauTion, used in front of Snow Thrower. with the safety If using extension cord, use only alert symbol, indicates a outdoor-specific cable. hazardous situation which, if Page 2 For technical questions, please call 1-800-444-3353. SKU 68010... - Page 3 Thrower, or direct the discharge at Use the equipment in accordance windows or bystanders. with these instructions and in the manner intended for the particular type of equipment, taking into SKU 68010 For technical questions, please call 1-800-444-3353. Page 3...
- Page 4 Raynaud’s Disease should not use this tool. If you feel any symptoms related to vibration (such as tingling, Page 4 For technical questions, please call 1-800-444-3353. SKU 68010...
-
Page 5: Grounded Tools: Tools With Three Prong Plugs
Double insulated tools may be used low resistance path to carry electricity in either of the 120 volt outlets shown away from the user, reducing the risk SKU 68010 For technical questions, please call 1-800-444-3353. Page 5... -
Page 6: Extension Cords
“W-A” (“W” in Canada) to indicate it is acceptable for outdoor use. Make sure the extension cord is properly wired and in good electrical Page 6 For technical questions, please call 1-800-444-3353. SKU 68010... -
Page 7: Basic Specifications
For additional information regarding (10, 62) the parts listed in the following pages, refer to the Assembly Diagram near Impeller (38) the end of this manual. Belt Cover (24) SKU 68010 For technical questions, please call 1-800-444-3353. Page 7... -
Page 8: Operating Instructions
The Snow Thrower is equipped with and serviced by a qualified a Safety Switch (77). To activate technician. Switch, insert one finger into Switch’s opening and pull the Switch out (or Page 8 For technical questions, please call 1-800-444-3353. SKU 68010... -
Page 9: User Maintenance Instructions
Snow is easier to remove when it is freshly fallen and/or in the early morning hours before it has been warmed by the sun. SKU 68010 For technical questions, please call 1-800-444-3353. Page 9... -
Page 10: Cleaning, Maintenance, And Lubrication Schedule
Pulley (30) and Tension Wheel (21). Properly discard of the old belt. Fit the new Belt around the Impeller Pulley and Tension Wheel. Then reset the Belt Spring, tightening the tension on the new Belt. Page 10 For technical questions, please call 1-800-444-3353. SKU 68010... -
Page 11: Cleaning The Snow Thrower
Snow Thrower Scraper is worn. Replace Scraper (see Maintenance). leaves a small layer of snow behind. Follow all safety precautions whenever diagnosing or servicing the equipment or engine. SKU 68010 For technical questions, please call 1-800-444-3353. Page 11... -
Page 12: Parts List Diagram
If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Page 12 For technical questions, please call 1-800-444-3353. SKU 68010... -
Page 13: Assembly Diagram
7, 8, 9 65, 66 38 37 36 SKU 68010 For technical questions, please call 1-800-444-3353. Page 13... -
Page 14: Limited 90-Day Warranty
90 daY waRRanTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
