There must be an unobstructed line of sight to the front ofthe i-DS3plus main speaker when using the remote control.
Point the remote control at the front panel of the main speaker when pressing the buttons. For best results you should
be within 20 feet of the unit and no more than 45° off axis. Being in a brightly lit room can reduce the sensitivity of the
i-DS3plus to remote control commands.
Note: Eventually you'll need to replace the remote battery.lfthe remote doesn't reliably operate the i-DS3plus, put in a
new CR2025 3V lithium coin type battery.
Automatic Activation and Standby
The power switches on the back of the main speaker
0
and the subwoofer
~
can be left on. i-DS3
plus
has an
automatic power standby system. After a few minutes of inactivity the amplifiers go into standby mode. As soon as
i-DS3
plus
receives a signal from the iPod the amplifiers automatically turn on again. If the i-DS3
plus
won't be used for an
extended period of time, turn the power switches off.
Other Adjustments
Subwoofer Volume Control Adjustment
~
You may need to make further adjustments to the subwoofer volume control to produce a better blend with the main
speaker and produce a balanced, natural sound. Start with the subwoofer volume control at the middle of its rotation
range. Playa variety of source material-some music, a movie sound track with dynamic special effects, some spoken
dialog. Adjust the subwoofer volume control up and down a bit from the starting point until you have a setting that
produces a natural sound with all the various types of program material.
Wireless 10 Switches
0
~
Both the main speaker and the subwoofer have Wireless ID switches. The various switch settings change the frequency
of the wireless signal the main speaker sends to the subwoofer. The two switches must be set to the same channel.
Typically you'll never need to adjust these switches. What are they for? If you have more than one i-DS3plus system in your
house you can use different wireless ID Switch settings so the systems won't interfere with each other.
Connecting Other Equipment
Line Inputs
0
Other audio equipment, such as a portable CD player or older iPod models that do not have the universal docking
adapter, can be connected to the i-DS3
plus
through the Line inputs on the back of the main speaker. Typically you'll need
a cable that has a stereo 1/8-inch plug on one end to connect to the output of the device you are connecting to the
i-DS3plus The other end of the cable should have two RCA plugs that will connect to the i-DS3p lus line inputs.
Using the Video Output
0
If your iPhone/iPod can store video or photos you can view them on an external television when it is docked to the
i-DS3plus. There are two outputs - a composite output and an S-video output. Use which ever one is compatible with
your television. For the composite output, connect a standard RCA plug cable between the i-DS3
plus
and the composite
video input of your television. Typically the composite video input of a television is color coded yellow. To use the S-video
output you will need a special S-video cable to connect the i-DS3plus to the corresponding input on your television. Refer
to the manual for your television for information on this input and how to use it.
Maintenance and Service
The i-DS3
plus
enclosures may be cleaned using a soft cloth to remove fingerprints or to wipe off dust. All wiring
connections should be inspected and remade at least once a year.
In the event that your i-DS3plus ever needs service, contact your local Boston Acoustics dealer or visit
www.bostonacoustics.com/dealers for a list of dealers in your area.
7
