RCEP400WR
Weather Radio
Owner's Manual
Tour of the Weather Radio ....................................................... 1
Before You Start: Charge Up the Weather Radio ................ 2
Using AM/FM/Weather Band radio ....................................... 2
Flashlight .................................................................................... 2
Solar Panel .................................................................................. 3
Hand-Crank Charging .............................................................. 3
Mobile Phone Charging ............................................................ 3
Limited 12 Month Warranty ..................................................... 6
Radio-météo
Manuel du propriétaire
Présentation de la radio-météo ............................................. 7
Avant de commencer Charger la radio-météo..................... 8
Radios AM/FM/canal météo ................................................... 8
Torche électrique ...................................................................... 8
Panneau solaire ......................................................................... 9
Manivelle de chargement ........................................................ 9
Chargement de téléphone mobile .......................................... 9
Garantie limitée de 12 mois ...................................................... 12
Radio para informes
meteorológicos
Manual del Propietario
Recorrido del radio para informes meteorológicos ............. 14
Antes de comenzar: Cargue el radio ...................................... 15
Radios AM/FM/banda meteorológica ................................... 15
Linterna ....................................................................................... 16
Panel solar .................................................................................. 16
Carga por manivela ................................................................... 16
Carga del teléfono móvil .......................................................... 16
Garantía Limitada de 12 Meses ............................................... 19
Advertisement
Table of Contents
Summary of Contents for Champ RCEP400WR
-
Page 1: Table Of Contents
RCEP400WR Weather Radio Owner’s Manual Tour of the Weather Radio ............1 Before You Start: Charge Up the Weather Radio ....2 Using AM/FM/Weather Band radio ........2 Flashlight ..................2 Solar Panel .................. 3 Hand-Crank Charging .............. 3 Mobile Phone Charging ............3 Limited 12 Month Warranty ............. - Page 2 IMPORTANT SAFETY INSTRUCTIONS FCC Information This device complies with Part 15 of the FCC Rules. PLEASE READ AND SAVE THIS FOR Operation is subject to the following two conditions: (1) FUTURE REFERENCE this device may not cause harmful interference, and (2) this device must accept any interference received, Some of the following information may not including interference that may cause undesired...
-
Page 3: Tour Of The Weather Radio
Emergencies happen. Be prepared. The 5 in 1 multi-function weather radio has been designed to help you in unforeseen events. What’s in this package? 2.5mm cable Mini USB • USB Type A to mini USB cable (Fig. 1) • 2.5mm cable to USB cable (Fig. 2) • This user guide • Weather radio USB Type A USB cable (female) Figure 1 Figure 2 • Lanyard Tour of the Weather Radio... -
Page 4: Before You Start: Charge Up The Weather Radio
Before You Start: Charge Up the Weather Radio Before you use the Weather Radio for the first time, use the supplied USB to mini USB cable to charge its the battery completely. Here’s how: 1. Find the USB Type A to mini USB cable included in this package. Note: You can also use your own USB Type A to mini USB cable to charge the Weather Radio’s internal battery. -
Page 5: Solar Panel
Solar Panel The solar panel charges the Weather radio’s internal battery. It could take 15 to 20 hours under stronger sunlight. Hand-Crank Charging The hand crank charges the Weather radio’s internal battery. 1. Open the hand crank. 2. Grip the Weather radio with one hand the crank with the other. 3. Turn the handle rapidly (about 120 to 150 RPM). It will take about 100 minutes to recharge completely if battery was totally depleted. - Page 6 Note: The weather radio’s charging output is 5V +/- 0.2V. Make sure your mobile device is compatible with this voltage. 6. When you’re finished charging, disconnect the 2.5mm to USB cable from the weather radio and place the rubber cover over the jacks again. Then put the weather radio’s slide switch back in one of the AM, FM, or weather band positions (this helps the weather radio conserve battery power). Note: Phone talk time from charging varies from model to model. Mobile device charging is limited due to the size of the weather radio’s internal battery. Charging from the weather radio is intended for emergencies, to provide enough charge for an emergency call or to send an emergency text.
- Page 7 Approximate Mobile Phone Charging Times Weather Radio Status Approximate talk time Battery fully charged (Weather Radio battery) 10-15 minutes* When battery level decreased to a level that ≥ 14 minutes the lighting fades out/light intensity drops to 100LUX, and user handcranks it for 10 minutes (speed ≥ 120 rev/min) * Minutes will vary by phone type, operating system and settings.
-
Page 8: Limited 12 Month Warranty
LED: lifespan 50,000hrs Output power: DC 5V/500mA Weight: 323g Size: 129mm x 48mm x 62mm For additional support, call our Consumer Help Line at 1-888-217-7900, or visit Champ- Eprep.com Limited 12 Month Warranty Voxx Accessories Corp. warrants that for 12 months from date of purchase, it will replace this product if found to be defective in materials or workmanship. Return it to the address below for a replacement with a current equivalent. -
Page 10: Avant De Commencer Charger La Radio-Météo
© 2014 Voxx Accessories Corp. 3502 Woodview Trace, Suite 220 Indianapolis, IN 46268 RCEP400WR IB 00...
