Summary of Contents for amparos M5
-
Page 1: User Manual
GSM/GPRS/GPS/LBS M5-Tracker User Manual... - Page 2 Any change will be integrated in the latest release. The manufacturer assumes no responsibility for any errors or omissions in this document. GPS-M5 / Free and Save 052014 Copyright by AMPAROS...
-
Page 3: Table Of Contents
5.17 Speak ....................... 14 5.18 Data logging ..................... 15 5.19 Data load ....................15 5.20. SOS Alert ....................16 5.21. Shock Sensor Alarm ................16 5.22. Geo-fence ....................17 5.23. Multi-area management ................17 GPS-M5 / Free and Save 052014 Copyright by AMPAROS... - Page 4 5.39 Modes switch between “SMS” and “GPRS” ..........24 5.40 Setup monitor center number ..............25 5.41 Web platform and APP tracking ............... 25 Cautions ......................25 Faults & The solutions ..................26 GPS-M5 / Free and Save 052014 Copyright by AMPAROS...
-
Page 5: Summary
perfect travel companion for luggage, valuables, etc mobile alarm system for hotel rooms, cottages, tents, etc. AMPAROS Am Lindbruch 107 41470 Neuss GERMANY Telefon: +49 (0) 2137.7960487 Telefax: +49 (0) 2137.7960488 Email: kontakt@amparos.de GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 6: Hardware Description
3. Hardware Description 3.1 Side 3.2 Front Speaker GSM,GPS, USB Port Power indicator Call contact SOS Button JIAN 3.3 Side SIM Card ON/OFF GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 7: Specifications
Battery Standby 240hours Storage Temp. -40°C to +85°C Operation Temp. -20°C to +70°C EN 55022:2010 EN 61000-3-2:2006 Certificate NO.: BST13110411Y-1EC-1 A1:2009+A2:2009 Test Report No.: BST13110411Y-1ER-1 EN 61000-3-3:2008 Made in China EN 55024:2010 GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 8: Usage
5.3.3 In 10 or 40 seconds, the unit will begin to work after acquire the GSM signals as well as the GPS signals. 5.3.4 When this unit receives GPS signals normally, you can use it and do any setting as the instructions of this manual. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 9: Initialization
Only after setting the authorization phone number can receive SMS alarm and call the authorization phone number by SOS button on tracker. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 10: Set The Contacts
“contact three ok”. 5.7.5 Send SMS “nocontact +password”to delete the three phone number in the meantime. If need to modify the three phone number can resend the correspond command to replace directly. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 11: The Function Of Buttons
5.9.1 If there is no authorized number, when any number dials up the unit, it will report a Geo-info; If there is already an authorized number, then it will not respond when an unauthorized number calls it up. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 12: Auto Track Continuously
"Distance ok", and then tracker will locate upon both the pre-set time and distance. E.G: Send "distance123456 0050", it means distance is 50 meters; the number must be 4 digits Arabic numbers. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 13: Location Based Service (Lbs)
SMS mode, but the LAC in message is the current new position, the location can be seen by input the LAC code in the menu “Manual Track” of web platform www.AMPAROS.de, you can also send command “address+password” to tracker to get the newest absolute address and GPS coordinates as well;... -
Page 14: Gps Drift Suppression
Send SMS “speak+password” to the unit, and it will reply “speak ok!”. Call the device again, it will pick up automatically without pressing any button of the device, can speak now. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 15: Data Logging
For Example: send SMS: “load123456 20110425” to the tracker device, means to load the tracking data of 25th April 2011 to monitoring platform. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 16: Sos Alert
Second level: Alarm will be triggered after detect 8 times vibration in 2 seconds, send command" sensitivity+password+space+2". Third level: Alarm will be triggered after detect 25 times vibration in 5 seconds, send command" sensitivity+password+space+3". GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 17: Geo-Fence
Send SMS command:"noarea+password+space+area name", tracker will reply:"noarea ok". 5.23.3 Rename and set distance Send SMS command "rename+password+space+old name;new name, distanceM" to tracker, if name is not repeated and area doesn't cover others, GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 18: Movement Alarm
“move OK”. In case of such a movement (the default distance is 200m), it will send SMS “Move+ latitude & longitude” to the authorized numbers at interval of 3 minutes. 5.24.2 Cancel: Send SMS “nomove+password” to deactivate the movement alarm. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 19: Over Speed Alarm
5.27.GPS blind Spot alert This function deactivates default, send “gpssignal+password+space+on”, it will send alert SMS “no gps+last valid latitude/longitude before lost signal” to authorized phone numbers. Send SMS “gpssignal+password+space+off” to deactivate. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 20: Sleep Mode
For example, set the phone number of the service provider of the simcard in the tracker, when charge remind message coming in, tracker will forward it to authorized phone number. 5.29.2 Cancel: Send SMS command "noforward+password" GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 21: Charges Inquiry
5.32 Check IMEI Send SMS command "imei+password" to the unit. E.g. Send SMS command "imei123456" to the tracker device, an IMEI number in 15 digits will reply to your cell phone. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 22: Terminal (Local) Time Setting
, operate according the instructions. Note: Correct password is needed every time you configure the tracker. 5.37 GPRS setting User must send SMS via cell phone to set up APN,IP and port before starting GPRS. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 23: Setting Up Apn
5.37.2.3 For instance, send SMS “up123456 t-mobile tm” to the tracker, and if succeeded, the tracker returns “user, password OK” Note: 123456 is tracker device password, t-mobile is the user name for GPRS login, tm is the password for GPRS login. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 24: Less Gprs Traffic
SMS.( 123456 is default password，85.214.34.86 is IP，1167 is port – AMPAROS tracking). Note: The IP and port information are on our website: www.AMPAROS.de 5.38 Less GPRS traffic 5.38.1 Tracker will change to less GPRS traffic mode after parking 5 minutes, GPRS disconnect and connect again when alarm being triggered or detect vibration. -
Page 25: Setup Monitor Center Number
3. Don’t put the unit in overheated or overcooled places. 4. Handle carefully. Don’t vibrate or shake it violently. 5. Don’t disassemble or refit the unit. 6. Please read the user manual carefully before using the device. GPS-M5 / Free and Save 052014 Copyright by AMPAROS... -
Page 26: Faults & The Solutions
Password incorrect or wrong sms commands SMS reply fail format Call without SMS reply or Authorized number is wrong or without setting any authorized number cannot receive alarm SMS service@AMPAROS.de GPS-M5 / Free and Save 052014 Copyright by AMPAROS...
