Assembly Instructions

and User's Manual
22in ANTIQUED CHIMINEA
FSMVPT6002
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE
OR OPERATE THIS PRODUCT.
Adult assembly required
Keep the screws and parts out of reach of children.
For customer service, please call 1-888-922-2336 or E-mail:
customer.service@academy.com
Business hours: Monday through Friday 7:00am to 10:00pm; Sunday 9:00am to
8:00pm. Central standard Time.
(Made in China)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSMVPT6002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mosaic FSMVPT6002

  • Page 1: Assembly Instructions

    Assembly Instructions and User’s Manual 22in ANTIQUED CHIMINEA FSMVPT6002 Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required Keep the screws and parts out of reach of children.

  • Page 2: Table Of Contents

    Table Of Contents Table of Contents .....................1 Warnings ......................1 Hardware and Part List..................3 Assembly......................5 Care and Maintenance..................8 Warranty......................9 Warnings WARNING For Outdoor Use Only. Wear gloves during assembly. WARNING Improper installation, adjustment, alteration or maintenance may result in property damage or injury.
  • Page 3 Warnings Do NOT burn charcoal briquette, lump charcoal, manufactured logs, driftwood, trash, leaves, papers, cardboard, plywood, painted or stained or pressure treated wood. Avoid using softwoods such as pine or cedar that can throw sparks. Do NOT alter this fire pit in any manner. Do NOT use this fire pit until COMPLETELY assembled and all parts are securely fastened and tightened.

  • Page 4: Hardware And Part List

    HARDWARE AND PARTS...
  • Page 5 Parts List Lift Handle Chiminea Cover Chiminea Flue Chiminea Top Mesh Screen Chiminea Bottom Stand Tray Poker Hardware AA M6 x 8mm Bolt BB M6 x 18mm Bolt CC M6 x 25mm bolt M6 nut Tools Required (Not included) Adjustable open end wrench Philips screwdriver Note: Make sure to check for parts before assembly if Not contact customer service.

  • Page 6: Assembly

    Assembly Instructions Step 1: Connect the lift handle (A) to the chiminea cover(B) using one M6 nut (DD). Step 2: Connect the stand (G) to chiminea bottom (F) by using M6 x 18mm bolts (BB) and M6 nuts (DD). Repeat this step for the rest of the stands. Do not tighten the bolts and nuts at this step.
  • Page 7 Assembly Instructions Step 4: Connect the mesh screen (E) to chiminea bottom (F) using M6 x 25mm bolts (CC) and M6 nuts (DD). Step 5: Connect the chiminea top (D) to the mesh screen (E) using M6 x 25mm bolts (CC) and M6 nuts (DD).
  • Page 8 Assembly Instructions Step 6: Connect the chiminea flue (C) to chiminea top (D) using M6 x 18mm bolts (BB) and M6 nuts (DD). Step 7: Place the assembled chiminea cover (B) onto the chiminea flue (C). Place the fire poker (I) next to the chiminea.

  • Page 9: Care And Maintenance

    Care and Maintenance Lighting 1. Make sure there is only a small amount of ash in the bottom of the chiminea 2. Place a layer of dry kindling or a natural fire-starter onto the center of the chiminea bottom. 3. Place above that a layer of dry seasoned hardwood lengths no more than 3/4 the length of the chiminea bottom.

  • Page 10: Warranty

    Warranty This product is covered by a one year (1) warranty against manufacturer’s defects. Manufacturer’s warranty does not cover: Acts of nature, fire, freezing, abusive use, normal fading, stains, rust, or freight and handling. Need help? Call our number at: (888) 922-2336 customerservice@academy.com...
