Page 1
GPS/Radio Collar, and a battery charger for use with both Display unit and Collar. The RoamEO system works by having the RoamEO GPS Collar obtain a fix from several GPS satellites in orbit, and transmitting those coordinates via radio to the PuPpod display unit, which will provide a bearing/direction to your dog and a range/distance from 1 to 3 miles away.
3. If indoors, it may require a few minutes to acquire a GPS lock. To improve your ability to gain a GPS fix, stand as close to a window as possible so that RoamEO has at least a partial view of the sky. It is unlikely...
Page 3
Indoor Mode: ( pg 21 ) ( pgs 13, 14, 15, 18 ) LCD Screen ( pgs 10, 19, 20, 20 ) Powering up the RoamEO Collar and PuPpod Display The RoamEO Collar and PuPpod hand-held Display unit are powered...
Page 4
To insert a RoamEO Battery into the PuPpod Display Unit, flip up the metal ring on the back of the Display unit, turn the ring counter-clockwise,...
Page 5
Registering the RoamEO Collar to the PuPpod Display A RoamEO collar needs to be registered to the PuPpod in order for the two components to work as a system. This process may have already been accomplished if the two components were purchased as a system.
Page 6
Locating your Dog with the PuPpod Display Once your RoamEO Collars have been registered, you now should take your RoamEO Collar and PuPpod Display unit outside to obtain a GPS lock. A series Segmented of five dots will strobe Directional...
Page 7
Display normally uses it’s own unique input from GPS satellites to compare the location of the RoamEO Collar on your dog, and its own GPS location. However, if you want to simply monitor your dogs outside while remaining inside your house (with no access to a GPS signal), the PuPpod display can help you monitor your dogs.
Page 8
To establish an Indoor Mode GPS location, take your PuPpod Display unit outside. Press and hold the bottom button until the house outline and house interior alternatively flash. Release the button; the PuPpod display unit will automatically search for an accurate GPS fix.
Page 9
Top Button Function Button/Power: turns the unit on and off; holding the Top Button down for 5 seconds turns the PuPpod unit off. Pressing the Top Button will also turn on the backlighting for 30 seconds. Middle Button Function Middle Button/Collar selection and registration...
Page 10
GPS lock on rolled. When the the selected collar RoamEO Collar is and the handheld enrolled, the paws (when not in Indoor are illuminated Mode).
Page 11
- The Collar GPS - The Collar radio - The collar battery Icon: Illuminated indicator: Illuminated level Icon: Shows when a radio packet the battery level of when the collar has a GPS lock. Will from the selected the selected collar. show only when collar is received.
FCC Compliance This device complies with Part 15 of the U.S. Federal Communications Commission (FCC) Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference that may cause undesired operation. Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
