Quicksilver Preamplifier Operating Instructions page 3

LINE STAGE:
Bandwidth
Gain
Input Impedance
Output Impedance =
Maximum Input
Maximum Output
Tube Complement =
PHONO STAGE
Bandwidth
Gain
Maximum Input
Tube Complement =
POWER SUPPLY:
Storage
Output Voltage
Tube Complement =
Dimensions:
Weight:
Quicksilver Audio warranties your preamplifier for a period of 3 years from the date of pur-
chase (90 days on tubes.) Parts and labor are provided free of charge as long as the failure was
not caused by misuse, accident or negligence. Shipping to the factory is not included.
Retain at least one packing carton in case a unit needs to be returned for service.
Quicksilver Audio Full Function Preamplifier
SPECIFICATIONS
= 1Hz to 650KHz
= 27 db
100K Ω -
=
20Hz to 20KHz
12.5 Ω
= 30volts RMS,
20Hz to 20KHz
= 65volts RMS,
20Hz to 20KHz
1-12AX7, 1-12AU7,
1-12FQ7
= 20 Hz to 20KHz
= 39 db at 1 KHz
= 500mv
1 -12AX7, 1 -12FQ7
= 122 joules
= 400 and 620 volts
1 -5AR4
Chassis 17"x11",
Front panel 19" x 5.25"
21 pounds
WARRANTY
Quicksilver Audio
5635 Riggins Court, Unit 15
Reno, NV 89502
(775) 825-1514 / Fax 825-1552
www.quicksilveraudio.com
