HSS Hire 578 Operating & Safety Manual

Multi-Output
For a multi-output PA system, simply link two or more
units in a chain. Having set up the first in the normal
way, connect it to the next using that unit' s
microphone lead – it plugs into the socket on the left
of the first unit' s connector panel. Up to 200 further
units can be added in a chain in this manner.

BASIC TECHNIQUES

PA System...
To work the MICROPHONE...
Slide the microphone switch forward for ON,
backward for OFF .
Hold the microphone no more than 150mm (6in) from
your mouth and turn the microphones control to
adjust the volume.
Always start with the volume turned right down
and make a test broadcast; gradually increasing the
volume to the desired level.
You will find it easier if you have someone moving
round the area to listen. Remember though, that the
volume may have to be readjusted in the course of your
event – the more people present, the louder the PA
needs to be.
Avoid pointing the microphone at
loudspeakers or the system will give out an
unpleasantly loud, high-pitched howl. For the best
results, position yourself either behind the
speakers or well off to one side.
To Add Music...
Simply connect the headphone socket to a personal
stereo system to the socket beneath
microphone' s windshield – using a 3.5mm – 3.5mm
'jack-jack' lead – this isn't supplied but, if you have any
problems, contact your local HSS Hire Shop for advice.
You can now control the music using the volume,
tone and other controls on the personal
stereo system.
You can also speak over the music by operating
the microphone in the normal way.
Loud Hailer...
To amplify your voice, simply squeeze the trigger
on the handle and speak. Some models have the
additional feature of a single tone siren, this
enables you to attract peoples attention. To
opperate the siren, simply flick the switch with your
thumb.
Hold the microphone no more than 50mm (2") from
your mouth and turn the rotary control to adjust
the volume.
Loud Hailer
Microphone
Volume
Control
9
8
the
VOLUME
Siren
Switch
the
Trigger
Always start with the volume turned down and
make a test broadcast; gradually increasing the
volume to the desired level.
You will find it easier if you have someone moving
round the area to listen. Remember though, that the
volume may have to be readjusted in the course of your
event – the more people present, the louder the volume
needs to be.
Avoid using the unit at high amplification in
AA confined spaces or the unit will give out an
unpleasantly loud, high-pitched howl.
Battery

FINISHING OFF

PA System...
Lift the case off its tripod and collapse this for transit.
Open the case, switch the unit OFF and unplug the
microphone – at the same time disconnecting the lead
of any personal stereo that you have used.
Now, pull the microphone lead back into the case
(locating its plug in the lid before sliding back the keyhole
cover) and pack away the microphone.
If you intend to re-use the PA system, recharge the
battery now (see box). If not, just pack the battery
charger back inside the case and close the lid,
making sure this is secure, ready for return to your local
HSS Hire Shop.
Whichever you are using...
Never use the PA system or Loud Hailer for
anything other than their intended purpose. If they
will no do what you want, contact your local HSS Hire
Shop for advice.
Always switch OFF and unplug the equipment
before making any adjustments to it.
Keep the equipment clean. You will find this less of a
chore if you clean up regularly, rather than wait unit the
end of the hire period.
When not in use, store the equipment somewhere
clean, dry and safe from thieves.
Contact your local
0990 282828
©HSS Hire Service Group Plc 1997 No. 578/01
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Operating & Safety Guide 578
Hire Shops
Portable PA
System & Loud
Hailer
Portable, tripod-mounted, 30 watt
PA System or Loud Hailer perfect
for fetes and similar events.
Code 90313/90312
