TERK Technologies TV-3 User Manual

TERK TECHNOLOGIES CORPORATION
T V 3
M O D E L : T V- 3
Features & Benefits:
• Adjustable, ultra low noise amplifier helps to boost
distant signals, or turn down the boost to prevent
stronger signals from overpowering the desired channel.
• Patented TERK Bypass system allows the signal to
bypass the amplifier when it is turned off to help prevent
signal loss for optimum results.
• Built-in Video Selector switch allows you to switch
between broadcast TV and a video source, such as DVD,
VCR or a video game.
• Includes both VHF and UHF capability for reception
of channels 2 through 69
• 6 ft. long 75 Ohm coaxial cable allows the antenna to be
installed on even the largest rear projection televisions
• Includes VHF/UHF band separator and 75-300 Ohm
matching transformer for easy hook-up to any
television set
• Non-skid silicon base ensures maximum stability on
any set-top
Technical Information:
VHF & UHF
DSS Satellite TV Compatible
Amplifier Gain:
VHF: 15dB adjustable
UHF: 15dB adjustable
Power Supply: AC to DC adapter 110V
Output Impedance:
75 Ohms (75-300 Ohm
matching transformer included)
Operating Bandwidth:
VHF: 54 MHz-216 MHz (Channels 2-13)
UHF: 470 MHz-806 MHz (Channels 14-69)
AUX: 54 MHz-1000 MHz
63 MALL DRIVE, COMMACK, NY 11725
Dimensions:
Base: 8"L x 4-1/4"D
Height of base: 2"
Height of base (including UHF loop): 9"
Length of dipoles: Closed 7-1/2", Open 44"
At TERK Technologies we strive to offer the highest quality products to
our consumers. The specifications are subject to change without notice.
©2001 TERK TECHNOLOGIES CORP.
TEL: 800.942.8375 FAX: 516.543.8088
DS-AM-ADV-07/01
www.terk.com
