Summary of Contents for ETSI Mobile WiFi

  • Page 1: Quick Start

    Quick Start is a trademark of ETSI.
  • Page 2 Thank you for purchasing the Mobile WiFi. This Mobile WiFi brings you a high speed wireless network connection. This document will help you understand your Mobile WiFi so you can start using it right away. Please read this document carefully before using your Mobile WiFi.

  • Page 3: Application Scenarios

    Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can all access the Internet through Mobile WiFi. The specific connection procedure depends on the operating system of the Wi-Fi device or computer. Establish a connection according to your device's specific instructions.
  • Page 4 Scenario 1: Accessing the Internet Using an LTE, 3G, or 2G Network The Mobile WiFi uses your operator's LTE, 3G, or 2G network to access the Internet. LTE/3G/2G...
  • Page 5 Scenario 2: Accessing the Internet Using a Wi-Fi Network When you use the Mobile WiFi in Wi-Fi coverage areas, for example, an airport, cafe, hotel, or your home, the Mobile WiFi can access the Internet via Wi-Fi networks, helping save your LTE, 3G, or 2G network usage.
  • Page 6 Appearance  Power button  Screen  Micro USB port  MENU button  Lanyard hole...

  • Page 7: Network Type

    Screen Home screen  Roaming R: Data roaming turned on.  Signal strength : Signal strength from weak to strong.  Network type Internet WLAN on 0 B/2GB 2G/3G/4G: Connected to a 2G/3G/LTE network.  : Connected to WLAN.  ...
  • Page 8  New messages.  Number of new messages.   Network connection status Internet connection is set up.  Internet WLAN status Internet WLAN turned on.  Traffic statistics Data usage this month  Monthly data usage limit  Note: To set the start date of the monthly data usage statistics and data usage limit, go to ...
  • Page 9 Menu screen Back  Back Info Return to the previous screen. Internet WLAN  Options 5G/2.4G  Operation tips Press the MENU button to scroll down, and press the Down Menu button to confirm your selection. Update screen  New software Updates are available.

  • Page 10: Ssid And Wireless Network Encryption Key

    SSID and Wireless Network Encryption Key When a Wi-Fi device establishes a connection to the Mobile WiFi for the first time, you may need to enter the default Service Set Identifier (SSID) and wireless network encryption key. The default SSID and encryption key are printed on the Mobile WiFi label.
  • Page 11 To view the current SSID and wireless network encryption key on the screen: Press the MENU button to display the menu. Back Info Internet WLAN 5G/2.4G Down Menu Press the MENU button to scroll to Info. Back Info Internet WLAN 5G/2.4G Down Menu...
  • Page 12 Press the button to enter Info. Back SSID: XXXXXXXXXX XXXX PWD: XXXXXX IP: XXXXXXXX Down Menu...

  • Page 13: Getting Started

    Getting Started Installing Install the SIM card, microSD card, and battery according to the illustration. Note: The microSD card is an optional accessory. If no microSD card is included in the package, please purchase one separately.

  • Page 14: Charging The Battery

    Charging the Battery If the Mobile WiFi has not been used for a long time or if the battery is fully depleted, the Mobile WiFi may not power on immediately after the charger is plugged in. Please charge the battery for a while before attempting to power on the Mobile WiFi.
  • Page 15 For details about the specific charger model, contact an authorized dealer. Method 2: Charge the device through a computer connection Use the data cable provided with your device to connect the Mobile WiFi to the computer.
  • Page 16 Supplying Power to Devices You can connect the Mobile WiFi to the AF10, and then connect the AF10 to other devices, such as a mobile phone, MP3 player, MP4 player, or Bluetooth headset. In this case, the Mobile WiFi works as a charger and supplies power to those devices.
  • Page 17  Mobile WiFi. If your Mobile WiFi malfunctions or cannot be properly powered off, press and hold  button for at least 10 seconds to forcibly power off your Mobile WiFi. Please turn the fast boot function off when you are on an airplane.

  • Page 18: Connecting To The Internet

    The Mobile WiFi's management parameters have been preset according to your operator's requirements. If data is transmitted, the Mobile WiFi will automatically connect to the Internet. If data is not transmitted for a period of time, the Mobile WiFi will automatically disconnect from the network connection.

  • Page 19: Using A Wi-Fi Network

    Using a Wi-Fi Network Ensure that the Internet WLAN function is enabled. The Mobile WiFi automatically connects to a Wi-Fi hotspot set by your service provider or yourself. When the Mobile WiFi is connected to a Wi-Fi network, and the Wi-Fi hotspot SSID are displayed on the screen.

  • Page 20: Logging In To The Web Management Page

    Logging In to the Web Management Page Make sure the connection between the Mobile WiFi and the Wi-Fi device or computer is working normally. Open the browser, and enter http://192.168.8.1 in the address box. Note: If the IP address conflicts with other IP addresses on the network, the IP address of the Mobile WiFi automatically changes.

  • Page 21: Verifying The Pin

    Wi-Fi turnoff function. If this function is enabled and if no Wi-Fi devices access the Mobile WiFi for a period of time, the Wi-Fi turns off automatically. You can press any button to turn the Wi-Fi on again.
  • Page 22 Press the button to turn Internet WLAN on or off. Note: Alternatively, you can log in to the Mobile WiFi's web management page to enable or  disable Internet WLAN. After the Internet WLAN function is enabled, up to nine Wi-Fi devices can be ...

  • Page 23: Restoring To Factory Settings

    The Mobile WiFi is then restored to its factory settings. Note: After you carry out this operation, the Mobile WiFi's personal configuration parameters will all be deleted. All configurations on the web management page will be restored to the factory settings.
  • Page 24 Otherwise, verify that your wireless network adapter is working properly. Select the wireless network connection with the Mobile WiFi's SSID and click Connect. Note: If the wireless network connection is encrypted, enter the correct wireless network ...
  • Page 25 Wait a moment for the wireless network connection icon to appear in the system tray in the lower right corner of the computer screen. The wireless network connection is then established.
  • Page 26 Example 2: Connecting to a Game Console (for example, PSP) through Wi-Fi On the PSP, turn on the WLAN. Choose Settings > Network Settings. Select Infrastructure Mode. Select New Connection, and enter the connection name. Select Scan to search for wireless networks.
  • Page 27 save settings. Select Test Connection to test whether the network connection is successful. You can now open the browser and access the network.
  • Page 28 Note: Wi-Fi devices, such as an iPhone, iPod touch, PS3 and NDSi, can all access the Internet through the Mobile WiFi. For specific operations, refer to the Wi-Fi device's user manual.
  • Page 29 Tips When the Mobile WiFi is in use for an extended period of time, it will become warm and may overheat. Should this happen, the Mobile WiFi will automatically close the network connection and turn off to protect itself from damage. If this occurs, place the Mobile WiFi in a well ventilated space to allow the heat to dissipate, then turn it on and continue to use it as normal.
