Summary of Contents for M&A Classmate PC

  • Page 1 Technology Companion PC...
  • Page 2 Technology Companion PC Preface Copyright 2008 All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if...

  • Page 3: Table Of Contents

    Technology Companion PC Table of Content ....1 TTENTION EACHERS ARENTS AND DULT UPERVISORS AGENCY REGULATORY NOTICES ...........3 ...................4 ODIFICATIONS ..........4 ONNECTIONS TO ERIPHERAL EVICES SAR E .................4 XPOSURE ............4 ECLARATION OF ONFORMITY ................4 UROPEAN OTICE ................5 ANADIAN OTICE ..........5 TTACHMENT IMITATIONS TATEMENT ..............6...
  • Page 4 Technology Companion PC ..................35 ECURITY ..................36 ETUP ..................38 ETUP ..............39 AMERA PPLICATION ................41 ROUBLESHOOTING ................42 O SPEAKER OUTPUT ............42 OUND CANNOT BE RECORDED .....43 HE HARD DRIVE IS MAKING ABNORMAL WHINING NOISES ......43 HE HARD DISK DRIVE HAS REACHED ITS CAPACITY ........43 HE HARD DISK TAKES LONGER TO READ A FILE ..43...

  • Page 5: Attention : Teachers , Parents And Adult Supervisors

    Technology Companion PC Emphasize to student that this device is an educational tool and not a toy. The computer, power supply, battery pack or power cord should not be dropped, crushed, stepped on or otherwise abused. This product is intended for school age children, ages 6 and Ensure students understand the safe and proper handling of power cord and power supply.
  • Page 6 Technology Companion PC Caution students to avoid using device in wet conditions and to protect the unit when carrying in wet conditions. When cleaning the unit, clean only with a slightly damp soft cloth. Do not pour liquid onto the unit. Do not clean while computer is “on”...

  • Page 7: Agency Regulatory Notices

    Technology Companion PC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio...

  • Page 8: Modifications

    RFI/EMI connector hoods to maintain compliance with FCC Rules and Regulations. SAR Exposure Second generation Intel-powered classmate PC refresh has been tested for and found to be in compliance with FCC RF Exposure Limit. During extended periods of use the integrated antenna located at the top left corner of the display screen should be positioned at least 20cm from users or nearby persons.

  • Page 9: Canadian Notice

    Technology Companion PC EN55024: 1998+A1: 2001+A2: 2003 IEC61000-4-2: 2001 ED. 1.2 IEC61000-4-3: 2006 ED. 3.0 IEC61000-4-4: 2004 ED. 2.0 IEC61000-4-5: 2005 ED. 2.0 IEC61000-4-6: 2006 ED. 2.2 IEC61000-4-8: 2001 ED. 1.1 IEC61000-4-11: 2004 ED. 2.0 EN 300 328-2, EN 300 328-1, EN 301 489-1, EN 301 489-17 (ETSI 300 328, ETSI 301 489) Electro-magnetic Compatibility and Radio Spectrum Matter.

  • Page 10: Power Cord Requirement

    Technology Companion PC The equipment must also be installed using an acceptable method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be coordinated by a representative designated by the supplier.

  • Page 11: Battery Pack Safety

    Technology Companion PC Japan All components of the cord set (cord, connector, and plug) must bear a “PSE” in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord are: (1) 0.75 conductors, (2) Type VCT or VCTF, and (3) 3-conductor. The cord set must have minimum rated current capacity of 7 The attachment plug must be a two-pole, grounded type with a Japanese Industrial Standard C8303 (15 A, 125 VAC)
  • Page 12 Technology Companion PC Do not dispose of the battery pack in fire or water.

  • Page 13: Lithium Battery Warning / Bridge Battery Warning

    Technology Companion PC To avoid risk of fire, burns, or damage to your battery pack, do not allow a metal object to touch the battery contacts. Handle a damaged or leaking battery with extreme care. If you come in contact with the electrolyte, wash the exposed area with soap and water.
  • Page 14 Technology Companion PC Der Arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 betragt 70dB (A) oder weniger. Zum Netzanschlua dieses Gerates ist eine geprufte Leitung zu verwenden. Fur einen Nennstrom bis 6A und einem Gerategewicht groBer 3kg ist eine Leitung nicht leichter als (1)H05VV-F, 3G, 0.75mm (2)2X0.75 mm conductors einzusetzen.

  • Page 15: Getting To Know The Basics

    Technology Companion PC Congratulations on your purchase of Intel-powered classmate PC. Second generation Intel-powered classmate PC refresh features the latest advances in portable computing technology. Second generation Intel-powered classmate PC refresh modular design provides maximum expandability without compromising portability. Opening the LCD Panel...

  • Page 16: Front View

    3. Be sure the system is turned off or in suspend mode before you close the display panel. With the LCD screen open, you will see several features important for operating your Intel-powered classmate PC. Front View CCD Camera Use this camera for any video conferencing application.

  • Page 17: System & Power Status Indicators

    Companion PC LED Status Indicator The LED Status Indicator displays the operating status of your Intel-powered classmate PC. When a certain function is enabled, a LED will light up. The following section describes the indication. System & Power Status Indicators...
  • Page 18 Technology Companion PC Power/Suspend Button • Press momentarily to turn on the system. • Press and hold for at least 4 seconds to turn off the system. • Press the power/suspend button again to return from the suspend mode. • Persistent green light indicates the Power is ON Keyboard The keyboard is used to enter data.

  • Page 19: Left Views

    Technology Companion PC Left Views Ventilation Grill The fan grill is where air is exchanged to dissipate the internal heat. Do not completely block this airway. Stereo Headphone Jack The stereo headphone jack (3.5 mm diameter) is where you connect the headphones or external speakers.

  • Page 20: Right View

    Technology Companion PC Microphone Jack The microphone jack (3.5 mm diameter) is where you connect a microphone. USB 2.0 Port This port conforms to the latest USB2.0 plug-and-play standards. Right View USB 2.0 Ports This port conforms to the latest USB2.0 plug-and-play standards.
  • Page 21 Technology Companion PC Ethernet / LAN Port When using a LAN, please use an EMI Shielding Cable to minimize an inteference when transmitting. Power Jack (DC-in) The DC-out jack of the AC Adapter connects here and powers the computer. Power Indicator This LED will blink in green color once the AC adapter is connected.

  • Page 22: Bottom View

    Technology Companion PC Kensington Lock This security lock provides the best options for physical security of computer in preventing the computer from being stolen. Bottom View Battery Release Latch Slide this latch to release the battery from its compartment. Battery Compartment This compartment contains the battery pack of your system.

  • Page 23: Started

    AC adapter. Do not use a different adapter to power the computer and other electrical devices. Whenever possible, keep the AC adapter plugged into the Intel- powered classmate PC and an electrical outlet to recharge the battery.
  • Page 24 Companion PC Never turn off or reset your Intel- powered classmate PC while the hard disk is in use; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your Intel-powered classmate PC before turning it back on;...

  • Page 25: To Install The Battery Pack

    Technology Companion PC einem vom Hersteller empfohlenem ahnlichen Typ. Entsorgung gebrauchter Batterien navh Angaben des Herstellers. To Install the Battery Pack:...

  • Page 26: To Remove The Battery Pack

    Companion PC To Remove the Battery Pack: Lithium-Ion Battery Your Intel-powered classmate PC uses a Lithium-Ion battery pack that provides power when you don’t have access to an AC outlet. You must charge the battery pack for at least six hours before using it for the first time.

  • Page 27: Battery Low-Power Warning

    Very Low battery condition occurs at 5 percent power remaining. The orange battery status LED indicator blinks and the system beeps at 4-second interval. When the Intel-powered classmate PC warns you of its low battery condition, you will have about three to five minutes to save your current work.

  • Page 28: Checking The Battery Level

    Technology Companion PC System will not charge battery when temperature exceeds 40C. Checking the Battery Level You can check the remaining battery power in Operating System battery status indicator. Prolonging the Battery’s Life and Usage Cycles There are ways you can prolong the use of battery. Use the AC adapter wherever AC wall outlet is available.

  • Page 29: Standby Suspend

    five to 20 seconds. Second generation Intel-powered classmate PC refresh power button can be set to turn off the system or activate the suspend...

  • Page 30: Using Second Generation Intel - Powered Classmate Pc Refresh

    Technology Companion PC The LCD screen display can be adjusted by the following key combinations. Fn + F9 Decreases Display Brightness. Fn + F10 Increases Display Brightness. LCD Care LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: When you are not using the computer, keep the LCD screen closed to protect it from dust.

  • Page 31: Touchpad Precautions

    Technology Companion PC Graphic Action System Control Symbol Fn + F1 Turns the Wired LAN module off or on. When the Wired LAN function is enabled, the LED status indicator shows green light. Fn + F2 Enables or Disables the Wire LAN function. Fn + F3 Enters the Suspend Mode.
  • Page 32 PC. If this key combination does not shut down the Intel-powered classmate PC, you can reset the computer by using the Intel- powered classmate PC’s power button. Should the computer lock up for some reason, pressing this button powers the Intel-powered...

  • Page 33: Bios Setup And Security Feature

    Technology Companion PC The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings.
  • Page 34 Technology Companion PC Legend Alternate Function Displays the General Help window. It can be enabled from anywhere in the BIOS. Jumps to the Exit menu or returns to the Main menu from a submenu. Selects the menu item to the left. ←...

  • Page 35: Main Setup

    Technology Companion PC Main Setup Under this menu, you may change time/date and view basic processor and system memory information. Due to various configurations on this model, your system may show different information. System Time: Type in the current time, in HH:MM:SS format. System Date: Type in the current date, in MM/DD/YY format.

  • Page 36: Advanced Setup

    Technology Companion PC Advanced Setup...
  • Page 37 Technology Companion PC...
  • Page 38 Technology Companion PC Communication: See Below. Item Selections / Description Sub-menu Card Reader Enable/Disable Enable or disable the Card Reader function.

  • Page 39: Security

    Technology Companion PC Security Supervisor Password: Install or Change the Password. User Password: Install or Change the Password. Using Password Protection Two Levels of Password Protection are available. The BIOS provides both a Supervisor and a User password. If you try to activate both passwords, the Supervisor password must be set first.

  • Page 40: Boot Setup

    Technology Companion PC Boot Setup...
  • Page 41 Technology Companion PC Boot Settings Configuration: See Below. Item Selections / Description Sub-menu Quick Boot Disabled [Enabled]: The system skips certain tests Enabled while booting. This shortens the boot-up time. [Disabled]: The system performs full tests while booting. Quiet Boot Disabled When Enabled, the system will display Enabled...

  • Page 42: Exit Setup

    Technology Companion PC 3rd Boot Network: Realtek Set the type of device for the third drive Device Boot Agent BIOS attempts to boot from. 4th Boot USB; Generic- Set the type of device for the third drive Device Multi BIOS attempts to boot from. Exit Setup Save Changes and Exit: After you have completed the BIOS settings, select this item to save all settings, exit BIOS Setup...

  • Page 43: Web Camera Application

    Technology Companion PC This application offers video conferencing capabilities to work and communicate in real-time with one or more participants through streaming video, from any location. Press the “Camera” icon key to display the “NMG Webcam” screen display. Your image will immediately display on the small screen.
  • Page 44 Technology Companion PC Open Folder Click on this function to locate the files you captured image files or recorded video files. Snapshot Use this function to captured the image file of the other party when you on video conferencing. Record Use this function to start recording on the video files when you are starting a video conferencing.

  • Page 45: Troubleshooting

    Technology Companion PC Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.

  • Page 46: No Speaker Output

    Technology Companion PC defaults. Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work. If external devices such as USB camera, scanner or printer do not function correctly when connected to the system, it is usually the device’s own problem.

  • Page 47: The Hard Drive Is Making Abnormal Whining Noises

    Technology Companion PC Check the hard disk indicator LED. When you access a file, the LED lamp should light up momentarily. The new HDD may be defective or is not compatible. If your computer has been subjected to static electricity or physical shock, you may have damaged the disk drive.

  • Page 48: The Built-In Touch Pad Performs Errotically

    Technology Companion PC The built-in touch pad performs errotically Make sure there is no excess perspiration or moisture on your hand when using the touch pad. Keep the surface of the touch pad clean and dry. Do not rest your palm or wrist on the surface of the touch pad while typing or using the touch pad.

  • Page 49: The Ethernet Adapter Does Not Appear To Operate In The 100Mbps Transmission Mode

    Technology Companion PC Check to see if other workstations connected to the same hub or concentrator is working. The Ethernet adapter does not appear to operate in the 100Mbps transmission mode Make sure the hub you are using supports 100Mbps operation.

  • Page 50: The Usb Device Does Not Work

    Technology Companion PC The USB device does not work Make sure the cable is fully connected. Make sure you have installed the necessary device drivers. Contact the device vendor for additional support.

  • Page 51: Specification

    Technology Companion PC • Intel® ATOM N270 processor 1.6GHz • 512K SLB73 FSB@533MHZ Memory • DDR2 400/533 SO-DIMM DRAM module • 256, 512 MB and 1GB • SO DIMM 200-pin socket * 1 Core Logic • Intel® 945GSE • ICH7-M Audio Codec •...
  • Page 52 Technology Companion PC • Wi-Fi 802.11 b/g with open mesh support • Single antenna Keyboard • Integrated QWERTY keyboard W/ Hot key 77 KEY K/B Pointing Device • PS/2 Touch Pad with Left and Right Click Button and scrolling Bar Camera (Optional) •...
  • Page 53 Technology Companion PC • 20V/40W • Supports 2pin and 3 pin power cord BIOS • Support PnP & ACPI 2.0 • Support external USB flash memory card boot up. Physical Outline • Dimension: 241mm W x 198.5mm H x 40.5mm D (Without PU bag and without handle) •...
