Page 1: Installation Guide
Installation Guide Sympodium® ID350/ID370 Interactive Pen Display... - Page 2 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this “Class B” digital device that have not been expressly approved by SMART Technologies Inc. could void the user’s authority to operate the equipment.
-
Page 3: Important Information I
Where use is prohibited, turn off the interactive pen display to prevent the possibility of it interfering with or causing other electronic devices to malfunction. SMART doesn’t accept any liability for direct or consequential damages. - Page 4 • Don’t hit or drop the interactive pen display or subject it to intense shock or vibration. • If the interactive pen display requires replacement parts, use parts that are specified by SMART Technologies Inc. Important Information 99-00724-00 REV B0...
-
Page 5: Table Of Contents
Connecting the Interactive Pen Display..................... 4 Integrating a Monitor or a Projector ......................4 Attaching the Pen ............................5 Installing SMART Board Software ......................6 Matching the Resolution ..........................7 Adjusting the Screen ..........................8 Orienting the Screen ..........................9 Securing the Interactive Pen Display....................... - Page 6 Customer Support Training ..............................25 Contacting SMART Technical Support....................25 General Inquiries ............................. 25 Warranty ..............................25 Registration ............................. 26 Sending Feedback ..........................26 Obtaining More Information on SMART Products ................... 26 Index Table of Contents 99-00724-00 REV B0...
-
Page 7: Overview
Overview The Sympodium® interactive pen display works with your computer and SMART Board™ software to create an interactive presentation environment. Both the ID350 and the ID370 include dynamic and interactive tools for creating presentations and lessons. You can control applications and create notes using the tethered pen, all while facing the audience. -
Page 8: The Pen Tool, Function And Display Control Buttons
Use the pen tool buttons to control the function of the pen tool. You can select from different digital ink colors and an eraser button. • Use the function buttons to perform a right-click and to access specific SMART Board tools, such as Notebook™ software. •... -
Page 9: Installing The Interactive Pen Display
Keep the computer keyboard and the mouse close to the interactive pen display, because the pen won’t function until you install SMART Board software and open SMART Board tools. You should also keep your computer within 19 1/2' (6.0 m) of the unit. This distance protects against signal degradation that occurs with a longer USB cable. -
Page 10: Changing The Angle Of The Interactive Pen Display
Changing the Angle of the Interactive Pen Display You can adjust the stand to change the angle of the interactive pen display. NOTE: For information on how to remove or install the stand, see page 10. To change the angle of the interactive pen display 1. -
Page 11: Attaching The Pen
To connect a projector or monitor to the interactive pen display 1. Connect a VGA (RGB) video cable (not supplied) to the RGB Video OUT receptacle on the interactive pen display. 2. Connect the other end of the cable to the Video Input receptacle on your projector or monitor. For details about the projector’s connectors, see the instructions that came with your projector. -
Page 12: Installing Smart Board Software
Installing SMART Board Software Your interactive pen display comes with a SMART Board software CD, which you can use to install SMART Board software on your computer. NOTE: You’ll need to use the computer’s keyboard or mouse to perform the installation, as your screen is not touch sensitive until you install and open the SMART Board tools. -
Page 13: Matching The Resolution
Because the SMART Board tools must be running before you can use the interactive pen display, ensure the SMART Board tools open automatically when you turn on the computer. When you install SMART Board software, select the option to start the SMART Board tools automatically when you start your computer. -
Page 14: Adjusting The Screen
Adjusting the Screen If the interactive screen receives a signal with appropriate horizontal and vertical frequencies, it automatically adjusts the horizontal and vertical position, phase and pitch settings. However, you can fine-tune the screen display settings by using adjustment buttons on the interactive pen display. -
Page 15: Orienting The Screen
1. (Windows operating systems) Press the SMART Board icon in the system tray, and press Orient. (Mac computers) Press and hold the SMART Board icon in the Dock, and press Open Orient. 2. Follow the on-screen instructions. For more details, see the SMART Board software online Help. -
Page 16: Securing The Interactive Pen Display
Securing the Interactive Pen Display You can secure the interactive pen display by attaching a cable (not supplied) between the security slot that’s built into the back of the unit and an immovable object. NOTE: This figure shows an ID370, but the security slot is in a similar position on the ID350. -
Page 17: Other Integrations
For example, you can integrate your interactive pen display with a projector and a SMART Board interactive whiteboard. NOTE: If you want to use a video cable longer than 50' (15 m), you must boost the video signal with a video distribution amplifier. - Page 18 Installing the Interactive Pen Display 99-00724-00 REV B0...
-
Page 19: Using The Interactive Pen Display
• the tethered pen and pen tool buttons function like the SMART pen tray tools on the interactive whiteboard Touching the Interactive Screen You can manipulate objects, select items, and create and remove digital ink by touching the screen with the tethered pen. - Page 20 NOTE: You can write notes over computer applications only if the SMART Board tools are running on the computer. You’ll know the SMART Board tools are running if you can see the SMART Board icon in the system tray or the Dock.
-
Page 21: Using The Eraser
Notebook software – an application that helps you organize, save and share your notes. • SMART Keyboard – a virtual keyboard that floats over your active application and lets you enter typed text at the cursor location. NOTE: You can reconfigure the Keyboard button. For details on customizing this button, see the SMART Board software online Help. - Page 22 Using the Interactive Pen Display 99-00724-00 REV B0...
-
Page 23: Maintaining The Interactive Pen Display
Maintaining the Interactive Pen Display This chapter tells you how to keep the Sympodium interactive pen display clean and replace the pen tip when it wears down. Cleaning the Screen You should clean the interactive screen once a week because dirt and dust can stick to the screen. To clean the screen, use an antistatic cloth. - Page 24 2. Insert a new tip straight into the barrel of the pen. Push the tip firmly until it stops. Maintaining the Interactive Pen Display 99-00724-00 REV B0...
-
Page 25: Troubleshooting
If the power indicator is off, make sure that: • the interactive pen display’s power cable is connected properly. • the interactive pen display is turned on. If the power indicator still doesn’t illuminate, contact SMART Technical Support (page 25). 99-00724-00 REV B0 Troubleshooting... -
Page 26: Checking The Status Of The Interactive Pen Display
Checking the Status of the Interactive Pen Display The Status indicator shows whether the pen is interacting with the display. Status Indicator NOTE: This figure shows an ID370, but the indicators are in a similar location on the ID350. STATUS POWER If the Status Indicator is... -
Page 27: Control And Writing Problems
If the pointer doesn’t accurately follow the movement of the pen, orient the interactive pen display (page 9). Before you can write on the screen in digital ink, SMART Board tools must be running the attached computer. You’ll know that the SMART Board tools are running if you can see the SMART Board icon in the system tray or the Dock. - Page 28 Troubleshooting 99-00724-00 REV B0...
-
Page 29: Waste Electrical And Electronic Equipment Regulations
WEEE recycling agency for recycling and disposal advice. Your SMART product required the extraction and use of natural resources for its production. It may contain hazardous substances. By disposing of electrical and electronic equipment appropriately, you lower the impact of these substances upon health and the environment and reduce the pressure on natural resources. - Page 30 Waste Electrical and Electronic Equipment Regulations 99-00724-00 REV B0...
-
Page 31: Customer Support
Contacting SMART Technical Support SMART’s Technical Support team welcomes your call. However, you may first want to contact your local reseller if you experience any difficulty with your SMART product, as they may be able to solve the problem without delay. -
Page 32: Registration
Registration A User Registration Card was included with your SMART product. To help us serve you, fill in and mail this card to SMART Technologies Inc. or register online at www.smarttech.com/registration. Sending Feedback You can help us improve our technical documentation by e-mailing your comments to TechnicalDocumentation@smarttech.com. -
Page 33: Index
Saving your Notes ID370, see Interactive Pen Display Screen, see Interactive Screen Installing Securing the Interactive Pen Display Interactive Pen Display SMART Board Software SMART Board Software SMART Technical Support Installing the Stand Status Indicator Integrating a Monitor or Projector... - Page 34 WEEE Regulations Writing on the Screen Index 99-00724-00 REV B0...
- Page 35 SMART Technologies Inc. 1207 – 11 Avenue SW, Suite 300 Calgary, AB T3C 0M5 CANADA Support +1.403.228.5940 or Toll Free 1.866.518.6791 (Canada/U.S.) Support Fax +1.403.806.1256 support@smarttech.com www.smarttech.com 99-00724-00 REV B0...
