Table of Contents:
Section 1: Model Nomenclature
Model Nomenclature ..............................................................2
Warnings, Cautions, and Notes ..............................................2
Introduction, Inspection, Definition, Unit Protection ............3
Overview, Considerations, Installation Steps ...................4 - 6
AHTR Electric Heat Electrical Data .........................................6
AHTR101B / 10kW ......................................................................7
AHTR151B / 15kW ......................................................................8
AHTR201B / 20kW ......................................................................9
AHTR101B / 10kW ....................................................................10
AHTR151B / 15kW ....................................................................11
AHTR201B / 20kW ....................................................................12
Installation, Operation & Maintenance:
Field-Installed Electric Heater for
RXT Series Units
P/N: 2300100902
Guide Revision Table:
August 2010
Date
By
Page
KT
All
Note
First Published
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Roth AHTR Series
-
Page 1: Table Of Contents
Installation, Operation & Maintenance: Field-Installed Electric Heater for RXT Series Units P.O. Box 245 Syracuse, NY 13211 www.roth-america.com P/N: 2300100902 888-266-7684 Table of Contents: Guide Revision Table: Section 1: Model Nomenclature Date Page Note Model Nomenclature ..............2 August 2010 First Published Section 2: Safety Labeling and Signal Words Warnings, Cautions, and Notes ..........2... -
Page 2: Model Nomenclature
“DANGER” Indicates an immediate hazardous situation which, if not avoided, WILL result in death or serious injury. “Note:” Used to highlight suggestions which will result in enhanced installation, reliability, or operation. Roth AHTR Series Elec Heat IOM, August 2010... -
Page 3: Section 3: Introduction
⚠ WARNING ⚠ OVERVIEW This instruction covers the physical installation of the AHTR Series electric heat kits when ELECTRICAL SHOCK HAZARD installed with the RXT Series Geothermal Heat FAILURE TO FOLLOW THIS WARNING Pump unit. -
Page 4: Section 4: Installation
1. Shut OFF electrical power at unit disconnect switch or service panel. This instruction covers the physical installation of the AHTR Series electric heat kits when 2. Remove the upper front panel from unit installed with the RXT Series Geothermal Heat and locate filler plate. - Page 5 9. Mark an “X” in the appropriate box for the = 1,023 seconds. If only 8 to 9 minutes heater on the unit rating plate. is desired between stages, place all Roth AHTR Series Elec Heat IOM, August 2010 AHTR Series Elec Heat IOM, August 2010...
-
Page 6: Section 5: Electrical Data
Mult. 2 41.7 52.1 AHTR151b Mult. 1 3.75 18.0 22.5 11.25 Mult. 2 36.1 45.1 Mult. 1 41.6 52.0 Mult. 2 41.6 52.0 AHTR201b Mult. 1 48.1 60.0 Mult. 2 48.1 60.0 Roth AHTR Series Elec Heat IOM, August 2010... -
Page 7: Section 6: Wiring Diagrams Ahtr101B / 10Kw
Section 6: Wiring Diagrams - AHTR101b / 10kW Roth AHTR Series Elec Heat IOM, August 2010 AHTR Series Elec Heat IOM, August 2010... -
Page 8: Ahtr151B / 15Kw
Section 6: Wiring Diagrams - AHTR151b / 15kW Roth AHTR Series Elec Heat IOM, August 2010... -
Page 9: Ahtr201B / 20Kw
Section 6: Wiring Diagrams - AHTR201b / 20kW Roth AHTR Series Elec Heat IOM, August 2010 AHTR Series Elec Heat IOM, August 2010... -
Page 10: Section 7: Parts Lists Ahtr101B / 10Kw
Section 7: Parts List - AHTR101b / 10kW Roth AHTR Series Elec Heat IOM, August 2010... -
Page 11: Ahtr151B / 15Kw
Section 7: Parts List - AHTR151b / 15kW Roth AHTR Series Elec Heat IOM, August 2010 AHTR Series Elec Heat IOM, August 2010... -
Page 12: Ahtr201B / 20Kw
Section 7: Parts List - AHTR201b / 20kW Roth AHTR Series Elec Heat IOM, August 2010... - Page 13 Roth AHTR Series Elec Heat IOM, August 2010 AHTR Series Elec Heat IOM, August 2010...
- Page 14 AHRI certification is shown as the Roth brand under the Enertech Manufacturing certification reference number **Roth Industries geothermal heat pumps are shown as a multiple listing of Enertech Manufacturing’s ETL certification *** Roth geothermal heat pumps are listed as a brand under Enertech Manufacturing’s Energy Star ratings...
