- Page 2 User Manual LCD1U-15-04/17-01/19-01 1U 15” / 17” / 19” Rackmount LCD Keyboard Drawer with USB KVM Switch...
-
Page 3: Table Of Contents
User Manual 1. Table Of Content 1. Table of Content 2. Read Before Installation 3. Introduction 4. Features 5. Package Contents 6. Optional Accessories 7. Peripheral Products 8. Important Safeguards 9. Structure Diagram 10. Dimension Diagram LCD1U15-04-8/-16-KVM-n-u LCD1U17-01-8/-16-KVM-n-u LCD1U19-01-8/-16-KVM-n-u P.10 11. -
Page 4: Read Before Installation
User Manual 2. Read Before Installation Technical Notes For Windows 98/98 SE systems HID (Human Interface Device) driver must be installed prior to using ● the USB KVM switch. To install the HID driver, first connect a USB keyboard and mice directly to computer (before installing KVM switch) then follow the Windows installation instructions, this will install the HID device driver and allow the use of the KVM switch. -
Page 5: Introduction
User Manual 3. Introduction The unit is a combination of keyboard, mouse and monitor into a drawer, with features such as flip-up design, adjustable brackets, built in LCD OSD to provide effective assistant for an administrator to control PC system. The unit provides cost effective for your limited IT budget over using CRT and rack mounting. -
Page 6: Package Contents
User Manual 5. Package Contents LCD Monitor Drawer with USB KVM Switch 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces 6 ft 2-in-1 KVM cable 8 Pieces Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. -
Page 7: Optional Accessories
User Manual 6. Optional Accessories KVM Cable 6ft / 10ft / 15ft USB 2-in-1 cable Cascade Cable 6ft USB Cascade cable Others Video Input 24V / 48V DC Power Supply 7. Peripheral Products Model Description 8-Port USB KVM switch 16-Port USB KVM switch CAT.5 USB KVM extender Rev. -
Page 8: Important Safeguards
User Manual 8. Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with a ●... -
Page 9: Structure Diagram
User Manual 9. Structure Diagram 1. Keyboard 2. Aluminium front panel 3. Class A active matrix TFT LCD panel 4. Rear metal case 5. LCD inverter 6. LCD membrane 7. Ball bearing telescopic slides with stopper 8. Adjustable mounting bracket 9. -
Page 10: Dimension Diagram
User Manual 10. Dimension Diagram 1U15”LCD KB Drawer with USB KVM LCD1U15-04-8/16-KVM-n-u 15” LCD Rev. : 1.0... -
Page 11: Lcd1U17-01-8/-16-Kvm-N-U
User Manual 10. Dimension Diagram 1U17”LCD Keyboard Drawer w/USB KVM LCD1U17-01-8/16-KVM-n-u 17” LCD Rev. : 1.0... -
Page 12: Lcd1U19-01-8/-16-Kvm-N-U
User Manual 10. Dimension Diagram 1U 19”LCD KB Drawer w/ USB KVM LCD1U19-01-8/16-KVM-n-u 19” LCD Rev. : 1.0 P.10... -
Page 13: Lcd Session
User Manual Session Rev. : 1.0 P.11... -
Page 14: Lcd Membrane Diagram
User Manual 11. LCD Session LCD Membrane Diagram Power Menu/Selection Right Exit Left MAIN MENU BRIGHT/CONTRAST AUTO ADJUST PHASE/CLOCK H/V POSITION MISC RESET Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ●... - Page 15 User Manual 11. LCD Session Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● Use the Left & Right button to adjust and button to “Brightness” ● 2. Contrast To adjust the contrast level of the input signal ●...
- Page 16 User Manual 11. LCD Session MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●...
-
Page 17: Resolution Settings
User Manual 11. LCD Session Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 P.15... -
Page 18: Kvm Session
User Manual Session Rev. : 1.0 P.16... -
Page 19: Front View
User Manual 12. KVM Session Front View Bank No. Selected Channel Bank Button Online Channel Channel Select Button Shift Button LED Indication Selected Channel - Displayed channel on monitor & red in LED. Channel select button - Press to select channel from 1 – 8. Shift button - Press &... -
Page 20: Rear View
User Manual 12. KVM Session Rear View Cascade Channel Port Power Port LCD1U-15-04/17-01/19-01-8-KVM-n-u LCD1U-15-04/17-01/19-01-16-KVM-n-u -connect to external 12V DC power adapter. DC Power -connect to additional KVM switch for channel Cascade Port expansion. - connect to monitor, PS/2 keyboard & mouse. -
Page 21: Installation Steps
User Manual 12. KVM Session Installation Steps Before installation, please make sure all computers are turned on and its operating system are running properly with keyboard and mouse. Connect the 2-in-1KVM cable to the one of your server. USB Type A Male connector to the USB Port ●... -
Page 22: Cascading
User Manual 12. KVM Session Cascading Using a USB KVM cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the USB KVM switch to reset the USB KVM switch. Bank 1 USB Cascade cable Bank 2... -
Page 23: Start Up
User Manual 13. Start Up The channels that have PC connected and it is switch on will have a green LED on that channel. The red LED will indicate the selected channel. 7 segments LED will display the bank number. Press channel button to select the channel. -
Page 24: Hotkey Command Operation
User Manual 13. Start Up Hot-key Command Operation Calling OSD Menu Scroll Scroll Space Bar Switch to Previous Port (powered on PC only) Scroll Scroll £ Switch to Next Power On Port (powered on PC only) Scroll Scroll ¤ Switch to Previous Bank First digit of Port Number: Scroll Scroll... - Page 25 User Manual 13. Start Up HotKey Command Operation Switch to Next Bank Scroll Scroll PgDn Enable / Disable beeper sound Scroll Scroll The default Beeper function is ON and beeper control is only for Note: available for Scan Mode. Auto Scan for Powered on PC Scroll Scroll Reset to factory Default Setting...
-
Page 26: Kvm Osd Operation
User Manual 13. Start Up KVM OSD Operation When using the keyboard arrow key to move the cursor, the keypad Note: arrow key (Up, Down, Right, Left) is unable to work at this menu. “MAIN CONTROLS” - OSD Menu of USB KVM switch To pop up MAIN CONTROLS—OSD menu of USB KVM switch, ●... - Page 27 User Manual 13. Start Up LANGUAGE Menu LANGUAGE CHOOSE A LANGUAGE : ENGLISH Mouse Operation : Move mouse and click the left button to choose a language, and click left ● key again to save. Keyboard Operation : Press é ê...
- Page 28 User Manual 13. Start Up PORTNAME Menu Bank Session PORTNAME Bank SYSTEM 01 ☼ SYSTEM 02 ☼ SYSTEM 03 ☼ SYSTEM 04 PC Name Session ☼ SYSTEM 05 ☼ SYSTEM 06 ☼ SYSTEM 07 ☼ SYSTEM 08 SYSTEM 09 Use “Tab” key to select session like Bank, PC, OSD, SCAN, CHANGE PASS- WORD, CONSOLE ON/OFF, etc…...
- Page 29 User Manual 13. Start Up TIMEVIEW Menu TIMEVIEW SCAN : OSD TIME means the display period of OSD windows or PC system name on your monitor. You can modify it from 05 sec to 99 sec. The factory default value is 10 sec... SCAN TIME means the scan interval from one PC port to next PC port.
- Page 30 User Manual 13. Start Up SECURITY Menu SECURITY ENTER PASSWORD _ _ _ _ _ _ _ _ ENTER NEW PASSWORD _ _ _ _ _ _ _ _ RETYPE NEW PASSWORD _ _ _ _ _ _ _ _ To CHANGE PASSWORD for avoiding all PC systems to be intruded by the ●...
- Page 31 User Manual 13. Start Up FINDPORT Menu FINDPORT ENTER NAME : _ _ _ _ _ _ _ _ _ _ “FINDPORT“ option helps you to find the PC system by its name. Enter PC system name and press ENTER, it will search the matching PC ●...
- Page 32 User Manual 13. Start Up CONSOLE Menu CONSOLE ENABLE DISABLE ENABLE – any user can use the console ● DISABLE – user is not allowed to use the console port, unless password ● is entered.When password is entered already and pass the KVM switch authentication, the CONSOLE will be set to ENABLE.
-
Page 33: Faq
User Manual 14. FAQ Keyboard or mouse dose not work or not be compatible with the PC. Please make sure the keyboard or mouse works when directly plug into the computer. If the problem persists, please try another keyboard or mouse. Mouse doesn’t work in Auto Scan mode You can press any key on the keyboard or the front button on the face plate for returning standard mode and then use the Keyboard or Mouse again. -
Page 34: Technical Specification
User Manual 15. Technical Specifications Item Specification KVM Channel Port 8 port / 16 port KVM Channel Interface HDDB 15 pin Female USB Port : Type A Female PC Computer Interface VGA : HDDB 15pin Female Cascade Port Connector HDDB 15pin Female KVM Cable Connection 2-in-1 HDDB 15-pin KVM Cable (CB-6/ 10/ 15) PC selection... - Page 35 User Manual 15. Technical Specifications Item Description LCD Screen 15” TFT Manufacturer South Korea LCD Origin Panel 15” TFT 17” TFT 19” TFT 1,024 x 768 1,280 x 1,024 1,280 x 1,024 Resolution 300 cd/m2 350 cd/m2 500 cd/m2 Brightness 16.2 Million 16.2 Million 16.7 Million...
