- Page 1 INSTRUCTION MANUAL WTLD018 Drill/Driver...
-
Page 2: Table Of Contents
Contents Warranty Warranty Power Tools Introduction 1 Year Repair Warranty. Environmental protection Register your warranty at www.automatictools.com.au Description of symbols All warranty conditions can be found on the www.automatictools.com.au website or email Specifications help@globalpowerbrands.com or call 1800 909 909 Safety instructions Additional safety instructions for drills Additional safety instructions for the charger Additional safety instructions related... -
Page 3: Introduction
Description of symbols Introduction The rating plate on your tool may show symbols. Your new AUTOMATIC power tool will more than satisfy These represent important information about the your expectations. It has been manufactured under product or instructions on its use. -
Page 4: Safety Instructions
General safety rules f) If operating the charger in a damp location is unavoidable, use a residual current device (RCD) WARNING. Read all safety warnings and all instructions. protected supply with a max 30mA cut off limit. Failure to follow the warnings and instructions may result in Use of an RCD reduces the risk of electric shock. -
Page 5: Additional Safety Instructions For Drills
4) Power tool use and care a) Ensure the switch is in the off position before inserting battery pack. Inserting the battery pack into a) Do not force the power tool. Use the correct power tool power tools that have the switch on invites accidents. for your application. -
Page 6: Additional Safety Instructions For The Charger
Additional safety instructions for the charger • Rags, cloths, cord, string and the like should never be left • Your AUTOMATIC tool with Lithium Ion batteries may around the work area. only be charged with the specific designed AUTOMATIC Lithium Ion battery charger purchased with the tool. • Support the work properly. IT IS DANGEROUS TO USE ANY OTHER BATTERY • If you are interrupted when operating the drill, complete CHARGER TO CHARGE YOUR TOOL. Do not attempt the process and switch off before looking up. -
Page 7: Additional Safety Instructions Related To The Battery Pack And Battery Safety
• Do not use the battery to power any device other than • To reduce the risk of an electric shock, unplug the the AUTOMATIC tool it was sold with. charger from the power supply before attempting to clean it. To clean tool or charger, wipe with a damp cloth. Use • Charge the battery only with the AUTOMATIC charger of any other cleaners is not recommended. -
Page 8: When To Charge The Battery
electricity is generated nor let the battery touch something condition and will not allow the pack to fall free from the that is statically charged. tool. If the clip is damaged or for any reason is not locking the pack in place Do Not continue to use. • The battery can be stored at temperatures between • Stop using the battery if it exhibits abnormal heat, odour, 0 - 40°... -
Page 9: Know Your Product
Know your product This drill is mainly used for drilling in wood or metal sheet and screwdriving. Use the tool and accessories only for intended applications. All other applications are expressly ruled out. 1. Keyless Chuck 2. Handle 3. Variable speed trigger switch with electric brake 4. -
Page 10: Unpacking
Due to modern mass production techniques, it is unlikely that in this manual. your AUTOMATIC Power Tool is faulty or that a part is missing. Another feature of the drill/battery pack is the low voltage If you find anything wrong, do not operate the tool until the cut out feature. -
Page 11: Battery Charging
Battery charging To obtain the best life for the battery IMPORTANT. Before attempting to charge the battery, Never allow the drill to come to a complete stand still check the charger and the battery to ensure the charging before recharging. The battery should be placed on charge equipment matches the battery supplied. -
Page 12: Battery Indicator Under No-Load
Battery Indicator Under No-load Orange Green Battery status indicator/description High: Battery is fully charged Medium: Battery Approx 50% charge capacity. Low: Battery has less than 30% charge capacity and should be charged. WARNING: Never use a damaged battery pack. 2 Speed gearbox Using the drill The 2 Speed Gearbox allows you Trigger switch to select a gear with the optimum Use the forward/reverse switch speed and torque to suit the (4) to select the direction of... - Page 13 Forward/reverse switch Temperature Cut Out Note. You can only change If the drill is constantly overloaded, or the drill is used the direction of rotation of the constantly at maximum rating in high ambient conditions, the battery cells may over heat causing the battery pack drill using the forward/reverse switch when the trigger is NOT to shut down.
-
Page 14: Drilling
Adjustable torque Ensure the bit is fully inserted, so that the chuck jaws grip the These drills are equipped with straight section of the bit. 24 torque settings plus one drill While holding the chuck collar setting which are controlled by the torque collar (8). All of in place, rotate the chuck clock-wise until the jaws tighten... -
Page 15: Chuck Replacement
Maintenance Drilling wood • C lamp a piece of scrap wood to the back of your work to • Store the tools, instruction manual and where necessary prevent splintering. the accessories in the original packaging. In this way you will always have all the information and parts ready All drilling operations to hand. • Mark off the centre of the hole using a centre punch or nail. • Do not throw used batteries into fire or water. There • Don’t force the drill, let it work at its own pace is a danger of explosion! Please hand in non-working • Keep the drill bit sharp. - Page 16 DISTRIBUTED BY; Global Power Brands International Pty. Ltd. PO Box 413 Mooroolbark VIC 3138 ABN. 39 131 999 914 Ph. 1800 909 909 help@globalpowerbrands.com...
