Worksaver SG-26A Owner's Operation Manual

Stump grinders for tractors

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

OWNER'S /

OPERATOR'S

MANUAL

MODEL NO.'s

SG-26A

SG-36A

CAUTION

For Safe Operation

Read Rules And

Instructions Carefully

SI NO LEEINGLES, PIDA AYUDA

A AIGUIEN QUE SI LO LEA

PARA QUE LE TRADUZCA LAS

MEDIDAS DE SEGURIDAD.

THE FOLLOWING SAFETY PRECAUTIONS SHOULD BE THOROUGHLY UNDERSTOOD

1. Select an area for assembly that is clean and free of any

debris which might cause persons working on the

assembly to trip.

2. Do not lift heavy parts or assemblies. Use crane, jack,

tackle, fork trucks or other mechanical devices.

3. Preview the assembly instructions in your operator's

manual before proceeding further.

4. If the assembly instructions call for parts or assemblies to

be blocked up, use only blocking material that is in good

condition and is capable of handling the weight of the

assembly to be blocked. Also insure that the blocking

material is on a clean, dry surface.

5. Never put hands, or any part of body, under blocked up

assemblies if at all possible.

Safety Instructions

Tractor Preparation

Operating Instructions

CAUTION

BEFORE ATTEMPTING TO BEGIN ASSEMBLING THIS MACHINE

STUMP GRINDERS

for

TRACTORS

6. After completing assembly, thoroughly inspect the

machine to be sure that all nuts, bolts, hydraulic fittings

or any other fastened assemblies have been thoroughly

tightened.

7. Before operating the machine, thoroughly read the

operation section of your operator's manual.

8. Before operating, read the maintenance section of your

operator's manual to be sure that any parts requiring

lubrication, such as gearboxes, are full, to avoid any

possible damage.

9. Before operating equipment – If you have any

questions regarding the proper assembly or

operation, contact your dealer or representative.

Assembly & Mounting

Maintenance

Repair Parts

Table of Contents

Need help?

Do you have a question about the SG-26A and is the answer not in the manual?

Questions and answers

Summary of Contents for Worksaver SG-26A

Page 1 OWNER’S / OPERATOR’S MANUAL MODEL NO.’s SG-26A SG-36A CAUTION For Safe Operation STUMP GRINDERS Read Rules And Instructions Carefully TRACTORS SI NO LEEINGLES, PIDA AYUDA A AIGUIEN QUE SI LO LEA Safety Instructions Assembly & Mounting PARA QUE LE TRADUZCA LAS...
Page 2: Table Of Contents
Like all mechanical products, it will require cleaning and upkeep. Lubricate the Stump Grinder as specified. Use only genuine Worksaver, Inc. service parts. Substitute parts will void the warranty and may not meet stan- dards required for safe and satisfactory operation. Record the model and serial number of your Stump Grinder...
Page 3: Warranty
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Worksaver have been used in connection with the unit, if, in sole judge- ment of Worksaver such use affects its performance, stability, or reliability.
Page 4: Specifications
STUMP GRINDER SPECIFICATIONS SUBJECT MODEL SG-26A MODEL SG-36A Mounting Cat. I - 3 pt. Cat. I / II - 3 pt. Recommended hp / Flow Req’d 22 - 45 PTO 45 - 100 PTO # Hyd. Remote Outlets Reg. Weight of Unit 660 lbs.
Page 5: Checklists
CHECKLISTS DELIVERY CHECKLIST DAILY CHECKLIST ■ ■ Inspect the stump grinder thoroughly after assembly to Check that stump grinder is properly and securely be certain it is set up properly. The following checklist is attached to tractor. a reminder of points to inspect. Check off each item as it ■...
Page 6: Safety Information
To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded opera- tor who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
Page 7 SAFETY INSTRUCTIONS (continued) EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufacturers build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
Page 8 SAFETY INSTRUCTIONS (continued) PREPARATION Never operate the tractor or stump grinder until you have read and completely understand this manual, the tractor operator’s manual, and each of the safety messages found on the safety signs on the tractor or stump grinder.
Page 9 SAFETY INSTRUCTIONS (continued) STARTING AND STOPPING SAFETY PTO powered stump grinder’s operating power is supplied from tractor PTO. Refer to your tractor manual for PTO engagement and disengagement instructions. Always operate PTO at 540 RPM. Know how to stop trac- tor and stump grinder quickly in case of an emergency.
Page 10 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Always stop the power unit, set brake, shut off the engine, remove the ignition key, lower implement to the ground and allow grinding wheel to come to a complete stop before dismounting. Never leave equipment unat- tended with the power unit running.
Page 11 SAFETY INSTRUCTIONS (continued) OPERATIONAL SAFETY (continued) Stop stump grinder and power unit immediately upon striking an obstruction. Turn engine off, remove key, inspect and repair any damage before resuming operation. The guards, flaps, driveline shields, and gearbox shields should be used and maintained in good working condition.
Page 12 SAFETY INSTRUCTIONS (continued) TRANSPORT SAFETY Comply with state and local laws governing highway safety and movement of farm machinery on public roads. The use of flashing amber lights is acceptable in most localities. However, some localities prohibit their use. Local laws should be checked for all highway lighting and marking requirements. When driving the tractor and equipment on the road or highway under 20 mph (32 kph) at night or during the day, use flashing amber warning lights and a slow moving vehicle (SMV) identification emblem.
Page 13 SAFETY INSTRUCTIONS (continued) MAINTENANCE SAFETY Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. Before working on this machine, drive to a level area, disengage the PTO, lower implement (or if working underneath, raise and block securely), shut off the engine, set the brakes, and remove the ignition keys. Remove hydraulic pressure prior to doing any maintenance.
Page 14 SAFETY INSTRUCTIONS (continued) STORAGE SAFETY Following operation, or when unhooking, stop the tractor, set the brakes, lower ram to lowest position and engage transport lock pin, shut off the engine, relieve hydraulic pressure and remove the ignition keys. Store the unit in an area away from human activity. Do not park equipment where it will be exposed to livestock for long periods of time.
Page 15: Safety Signs
SAFETY SIGNS WARNING 540 RPM SPEED RANGE ONLY HIGHER PTO SPEEDS CAN CAUSE PERSONAL INJURY AND EQUIPMENT FAILURE 101101 BE CAREFUL! Use a clean, damp cloth to clean safety decals. Avoid spraying to close to decals when using a pressure washer; high-pressure water can enter through very small scratches or under edges of decals causing them to peel or come off.
Page 16 SAFETY SIGNS (continued) BE CAREFUL! Use a clean, damp cloth to clean safety decals. Avoid spraying to close to decals when using a pressure washer; high-pressure water can enter through very small scratches or under edges of decals causing them to peel or come off.
Page 17: Preparation Instructions - Tractor
INSTRUCTIONS TRACTOR REQUIREMENTS CAUTION AND PREPARATION —————————————————— Be sure your tractor is in good condition. Read all The models SG-26 and SG-36 PTO driven stump the safety precautions and make sure all tractor grinders are designed to mount on tractors that have a 3 operators are familiar with the safety rules of pt.
Page 18: Assembly Instructions - Tractor
INSTRUCTIONS (continued) TRACTOR 3 PT. ASSEMBLY PTO DRIVELINE INSTALLATION —————————————————— AND MOUNTING —————————————————— On new stump grinders, check PTO driveline for correct length for use with your tractor. (Read page 18.) CAUTION Most swinging drawbars will have to be moved to a To avoid bodily injury caused by accidental falling forward position or removed.
Page 19 PTO shaft. Pull on driveline section to be sure than minimum overlap, do not use. Contact authorized that yoke locks into place. Worksaver dealer. 3. Hold driveline sections parallel to each other to determine if too long. Each section should end approximately 3”...
Page 20 If your tractor does not have a flow control, contact WARNING Worksaver, Inc. for a restrictor orifice fitting to reduce the flow. This will minimize the heat build up in the tractor When attaching PTO yoke to tractor PTO shaft, it is closed center hydraulic system.
Page 21: Operating Instructions
OPERATING INSTRUCTIONS GENERAL SAFETY PRE-OPERATION CHECKLIST —————————————————— —————————————————— Only qualified people familiar with this manual should (OWNER RESPONSIBILITY) operate this machine. Operator should wear hard hat, safety glasses, and safety shoes. It is recommended that ____ Review and follow safety rules and safety signs on tractor be equipped with Roll-Over Protective System pages 5 through 15.
Page 22 OPERATING INSTRUCTIONS (continued) and ready to start cutting, raise the PTO speed to 540 WARNING RPM and maintain throughout stump cutting opera- tion. ALWAYS operate the PTO at 540 RPM. This is Wear required personal protective equipment. Wear necessary to maintain proper wheel speed to obtain a close-fitting clothing and confine long hair.
Page 23 OPERATING INSTRUCTIONS (continued) OPERATION Sometimes trees will grow around stones or other (continued) —————————————————— objects. If this is the situation, remove the foreign object if possible. If it is a steel object, this must be 8. If the stump is large, raise the cutter wheel, slow the removed as it will break the carbide cutting teeth tractor engine rpm, raise the 3 pt.
Page 24 OPERATING INSTRUCTIONS (continued) OPERATING TIPS EXTENDING USEFUL LIFE OF CUTTING TEETH Different types of stumps (tree variety) will cut different- ly. (i.e. – a Pine stump will cut different than an Oak As the cutting teeth become dull they generally perform stump.) Older stumps where the tree was cut several better grinding softer woods.
Page 25 OPERATING INSTRUCTIONS (continued) REMOVING STUMP GRINDER CUTTING FEED RATE – PTO MODELS FROM TRACTOR The cutting feed rate is controlled by the hydraulic pres- —————————————————— sure relief valve connected to the 2” X 24” hydraulic cylin- Properly park tractor, shut off engine, and disengage der.
Page 26: Owner Maintenance & Lubrication
OWNER SERVICE LUBRICATION INFORMATION The information in this section is written for operators —————————————————— who possess basic mechanical skills. Should you need help, your dealer has trained service technicians The chart gives the frequency of lubrication in operat- available. For your protection, read and follow all safety ing hours, based on normal conditions.
Page 27 OWNER SERVICE (continued) ROTATING CUTTING TEETH G. Screw the slotted nut back on the threads of the gear- —————————————————— box output shaft to keep from losing the nut and to The cutting teeth on the outer edge and side of the cut- protect the threads on the shaft.
Page 28 OWNER SERVICE (continued) SLIP CLUTCH ADJUSTMENT FIELD ADJUSTMENT —————————————————— The slip clutch is designed to slip, protecting the gear- If necessary, adjust nut on any spring that is unequal. box and driveline, should the cutting wheel strike an Adjust all eight spring retaining nuts 1/3 of a turn (2 flats obstruction.
Page 29: Trouble-Shooting
TROUBLE-SHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Stump grinder wheel 1. Dull teeth. Rotate or replace teeth. raises during cut 2. Foreign object in stump. Check – remove object if possible. Tractor stalls 1. Too large of cut. Reduce cut depth or reposition power unit so wheel only cuts part of stump.
Page 30 TROUBLE-SHOOTING (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Teeth wear too fast 1. Cutting in sandy conditions. Don’t grind below ground more than necessary. 2. Cutting in rocky conditions. Remove rocks from around stump. 3. Operator not raising wheel when Raise wheel slightly before returning returning to “start”...
Page 31 TROUBLE-SHOOTING (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Hydraulic hose failure 1. Power unit hydraulic relief pressure Check power unit hydraulic system setting is very high and may cause and adjust relief valve. hydraulic hose failure. 2. Hoses are worn or frayed. Replace hose.
Page 32 TROUBLE-SHOOTING (continued) PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Gearbox noisy 1. Rough gears. Run in or change gears. 2. Worn bearings. Replace bearing. 3. Low oil in gearbox. Check level and add oil. Gearbox leaking 1. Damaged oil seal. Replace seal. 2.
Page 33: Parts Lists
SG-26A / SG-36A STUMP GRINDER HYDRAULIC DIAGRAM & PARTS LIST...
Page 34 SG-26A STUMP GRINDER PARTS DRAWING...
Page 35 SG-26A STUMP GRINDER PARTS LIST * NOTE: Order 811600 for repair kit containing (12) twelve carbide teeth, bolts & washers...
Page 36 SG-36A STUMP GRINDER PARTS DRAWING...
Page 37 SG-36A STUMP GRINDER PARTS LIST * NOTE: Order 811600 for repair kit containing (12) twelve carbide teeth, bolts & washers...
Page 38 SG-26A GEARBOX PARTS DRAWING & LIST...
Page 39 SG-36A GEARBOX PARTS DRAWING & LIST...
Page 40 SG-26A PTO SHAFT PARTS DRAWING & LIST...
Page 41 SG-36A PTO SHAFT PARTS DRAWING & LIST...
Page 42 PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION: A HOLIDAY 1. PART NUMBER FROM ACCIDENTS 2. PART DESCRIPTION 3. MODEL NUMBER 4. NAME OF ITEM MAY 2013 WORKSAVER, INC. P.O. BOX 100 LITCHFIELD, IL 62056-0100 (217) 324-5973 WEB: http:// www.worksaver.com E-MAIL: sales@worksaver.com WS-SG001-OG...
