Power-Soot Vac
Wet/Dry Vacuum Cleaner
MODEL 9487-0000
MODEL 9487-5220
OPERATING INSTRUCTIONS &
SERVICE MANUAL
Read all these instructions before operating this product and save these
instructions.
Thomas C. Wilson, Inc.
21-11 44th Avenue, Long Island City, New York 11101
Tel: (718)729-3360 Fax: (718)361-2872 http://www.tcwilson.com
Email: tcwilson@tcwilson.com
2 HP 115 volt 60 Hz
2 HP 220 volt 50 Hz
WARNING
SM-248A
Advertisement
Table of Contents
Summary of Contents for Thomas C. Wilson 9487-0000
-
Page 1: Operating Instructions
2 HP 220 volt 50 Hz OPERATING INSTRUCTIONS & SERVICE MANUAL WARNING Read all these instructions before operating this product and save these instructions. Thomas C. Wilson, Inc. 21-11 44th Avenue, Long Island City, New York 11101 Tel: (718)729-3360 Fax: (718)361-2872 http://www.tcwilson.com Email: tcwilson@tcwilson.com... -
Page 2: Safety Instructions
SM-248A SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock or injury: 1. Do not leave appliance plugged Unplug from outlet when not in use and before servicing. 2. Do not expose to rain. Store indoors. 3. Do not allow to be used as a toy. Close attention is necessary when used by or near children. 4. - Page 3 ABOUT THE VACUUM CLEANER SM-248A The Vacmobile style vacuum cleaner includes as standard equip- ment: 2 Rear Wheels 2 Hub Caps 2 Casters 2 Washers 1 10’ hose 1 Air Filter Assembly 4 Shaft Caps To Assemble: Remove and carefully set aside motor head and filter assembly. Tilt vacuum back to full rest on can handle. Insert and push casters into caster mount assemblies.
-
Page 4: Motor Head
SM-248A CARE & MAINTAINENANCE Air Filter Assembly The Air Filter Assembly with Never-Clog(R) Bag is the standard filter unit shipped with this vacuum cleaner. This fil- ter consists of a moleskin bag and metal frame, rubber gasket and dacron Never-Clog(R) Bag. This dacron filtration fabric is designed to trap the minute dirt and dust particles, minimizing the need for frequent replacement of the moleskin filter. - Page 5 SM-248A WET/DRY CARTRIDGE FILTER ASSEMBLY Caution: This filter MUST be in place at all times during vacuuming operations, both dry and wet. Never-Clog Dry Filter System 9487-8000 Filter Assembly 9487-6000 Filter Frame 9487-7000 Outer Filter 9487-4000 9487-2000 Wet Filter System #9487-0012 Floater Assembly (included)
-
Page 6: Parts List
PARTS LIST SM-248A Motorhead Assembly #9487-0110 For 115 volt, 60 Hz #9487-5221 For 220 volt, 50 Hz Item Part no. Description 9487-9801 Wire Assembly 9487-9802 Switch 9487-9803 Switch Plate 9487-9804 Dome Assembly 9487-9805 Strain Relief 9487-9806 Cord Set 9487-9807 Ground Screw 9487-9808 Gasket 9487-9809... -
Page 7: Parts List (Cont')
SM-248A PARTS LIST (CONT’) ITEM PART NO. DESCRIPTION 9487-9000 12 Gallon Steel Tank 9487-9900 12 Gallon Stainless Steel Tank 9487-9600 Handle 9487-0067 Bracket 9487-9310 Wheel Cap 9487-9300 Hub Cap 9487-9100 8” Wheel 9487-0556 Washer 9487-0787 Frame Assembly 9487-9200 Caster ACCESSORIES & TOOLS Vacuum Hose 10-ft 9488-0010 Moleskin Filter Bag... -
Page 8: Troubleshooting Guide
1. Blown fuse or tripped circuit. 1. Replace fuse or reset circuit. 2. Defective switch. Replace switch. Defective power cord. Replace power cord. Thomas C. Wilson, Inc. 21-11 44th Avenue, Long Island City, New York 11101 Tel: (800)230-2636 Ext.503 Fax: (718)361-2872 http://www.tcwilson.com E-mail: tcwilson@tcwilson.com...
