B&B Spectre LTE Quick Start Manual

Product Overview

Cellular
Antenna
Connector
802.15.4e
Antenna
Connector
LEDs
Cellular
Antenna
Connector
3G/LTE Routers
Reset Switch
802.15.4e
Antenna
Connector
Power LED
LEDs
Reset Switch
RT Routers
1
Your router will not work unless the antennas are attached
Power
and power is supplied. Some models also require installed,
activated SIM cards.
Powering the router with no antenna attached can
Ethernet/WAN Port
damage the router.
3G/LTE Routers
SIM card 1
Aux Ports
USB Port
Cellular
SIM card 2
antenna
to "DIV".
RT Routers
I/O Port
Power
Ethernet/WAN Port
2
Some service providers require installed,
activated SIM cards in order to establish
Aux Ports
communications. For the corresponding
router models, open the SIM card holder
by pressing the small button to the right
USB Port
of the SIM card holder.
3
The router has built-in protection
I/O Port against reverse polarity. Apply
+10 to +30 V DC, or connect the
included AC power adapter.
Attach Antennas
802.15.4e
Cellular
antenna to
antenna
"AUX".
to "ANT"
1
802.15.4e
antenna to
"AUX".
Insert SIM card
Attach Power
4 Connect Ethernet
You will use an Ethernet connection to
configure the router and to
communicate with it.
Configure the Router
5
You may configure the router via a web browser or Telnet.
Default Router IP Address = 192.168.1.1
Default Username = root
Default Password = root
Detailed configuration data is included on your installation
CD and also on our web site.
.
Set Up Mobile Connection
6
(Cellular Routers Only)
3G
– Click "Mobile WAN" under "Configuration".
Select your carrier under the primary SIM card drop
down menu. Enter APN and credentials given from your
provider. Apply changes.
Note: Sprint requires extra steps. Please see
Configuration Manual section "Sprint CDMA network
connection" for instructions.
Common APN Examples
Verizon: No APN required
AT&T: isp.cingular or wap.cingular
Sprint: No APN required
T-Mobile: epc.tmobile.com
Rogers: internet.com
TELUS: sp.telus.com
LTE
– Click "Mobile WAN' under 'Configuration".
Enter APN and Credentials given from your provider.
Apply Changes.
Common APN Examples
Verizon: vzwinternet
AT&T: broadband
