Sundance HD Edition Aerial Kit Contents List
Congratulations on your purchase of a DSLRPros Sundance HD Edition Aerial Kit.
Inside your P2 Tough Case you will find the following items with numbers that
correspond to the kit image on the following page.
1. DJI Phantom 2 With 3-Axis Gimbal Pre-Installed
2. Assorted A/C Power Cables With International Plug Adaptors
3. A/C Power Cable For TXS-8 Pro LiPo Charger
4. DSLRPros TXS-8 Pro LiPo Charger with Balance Board and Necessary Cabling
5. 2 Sets Of 4 9" Propeller Blades (Carbon Fiber and Plastic Blades Are Not To
Be Used Together)
6. Set of 4 Propeller Guards and Propeller Guard Screws
7. Futaba Transmitter
8. LiPo Battery For Futaba Transmitter
9. Deluxe DSLRPros Radio Tx Lanyard
10. LiPo Battery Capacity Checker
11. 3 DJI Smart Flight Batteries (1 Shown)
12. 1 DJI Charging for Smart Flight Battery
13. 1 Additional Charging Block for DJI Smart Flight Battery
14. DJI Smartphone Mount
15. HDMI Cable For GoPro To DJI Lightbridge Air System
16. Set of 2 DJI Lightbridge Air System Paddle Antennas & Air System Antennas
17. Set of 2 Antennas For DJI Lightbridge Ground System
18. DJI Lightbridge Ground System
19. DJI Lightbridge Transmitter Mount
20. DSLRPros LiPo Battery Guard Bag
21. Assorted Cables For DJI Lightbridge System (Please Refer To Your Lightbridge
Manual For Detailed Explanations For Each Of These Cables)
Assorted Power Cables and International Plug Adaptors (Please Refer
22.
To Your Lightbridge Manual For Detailed Explanations For Each Of These
Power Cables)
Advertisement
Summary of Contents for DSLR Pros Sundance HD Edition Aerial Kit
- Page 1 Sundance HD Edition Aerial Kit Contents List Congratulations on your purchase of a DSLRPros Sundance HD Edition Aerial Kit. Inside your P2 Tough Case you will find the following items with numbers that correspond to the kit image on the following page.
- Page 3 PLEASE READ ALL TOPICS BEFORE POWERING ON FOR FIRST TIME New pilots should NOT fly the Phantom with the Gimbal attached until they have had at least 10 hours of flight practice. Refer to the Zenmuse H3-3D operator's manual for installation and removal instructions (found on www.dji.com).
- Page 4 Turning On Your Transmitter and Phantom 2 • Always turn on your transmitter before turning on your craft. To turn on our transmitter press the power switch to the "on" position. Make sure your throttle is all the way down and the toggle switches are in the uppermost position before turning on your transmitter.
- Page 5 • Power On Self Test: Red Green Yellow Flashing • Initialization: Alternating Green and Yellow Flashing • Ready To Fly: Consistent Green Flashing • Signal Loss: Consistent Yellow Flashing • 1st Low Battery Indication: Slow Red Flashing • 2nd Low Battery Indication: Rapid Red Flashing •...
- Page 6 charger that is not a LiPo battery charger. Incorrect charging can cause damage the battery that may result in severe damage to persons and surroundings. • Left Stick: Located on the left hand side of the transmitter, pressing up and down on the throttle controls vertical movements.
- Page 7 DSLRPros Carbon Fiber Props are NOT self-tightening. Gimbal Installation & Removal It is highly recommended that new pilots remove the lower half of the gimbal before flight practice so that in the event of a crash while learning to fly the Phantom the Zenmuse H3-3D will not be damaged.
- Page 8 Updating Your Software It is recommended that you periodically check for software updates using the DJI assistant software application. When upgrading the firmware on either the transmitter or the craft, be sure to disconnect the gimbal from the craft. Upgrading your software with the gimbal's ribbon cable still attached can permanently damage the gimbal.
- Page 9 It is recommended that you use the Balance(BAL) setting when charging LiPo batteries. DSLRPros 2600mAH LiPo battery is 2 Cell(2S) and chargers at NO more than 2Amps. Using the DJI Lightbridge Your HD kit comes with the DJI Lightbridge digital video downlink system. This system allows for High Definition video to be transmitted to your ground station, allowing you to see what you are shooting in Full HD on your smartphone or tablet device.
- Page 10 • Smooth: This mode transmits a better quality image but has an increased lag time and lower range than Real Time. • Full HD: This mode offers the highest quality image (1080i) but has the highest lag time and smallest range. More information regarding the proper use of the DJI Lightbridge App (including a detailed breakdown of control systems and displays can be found in your DJI Lightbridge manual.
- Page 11 SE Toggle Switch (GPS, ATTI, ATTI): This is your flight mode control. The lowest ATTI position can be set to trigger "FAILSAFE" as an advanced feature. See you DJI Phantom "Advanced NAZA Assistant Manual" for further details. SA Toggle Switch (OFF, COURSE LOCK, HOME LOCK): This is your Intelligent Orientation Control or IOC. This mode is not enabled by default.
- Page 12 Phantom 2 Flight Procedures It is recommended that you follow this procedure when flying your craft. Be certain that the WiFi function on your GoPro is off. If you see a flashing blue light on your GoPro, this means the WiFi function is on and must be turned off before starting your craft.
